AS 1100.201-1992 [ Current ] Technical drawing, Part 201: Mechanical engineering drawing

standard by Standards Australia, 11/16/1992

Full Description

Sets out recommendations for mechanical engineering drawing practice. Provides information on surface texture and welding, and the simplified representation of pipelines. Provides details on springs, gears, splines, rolling element bearings, seals and knurling. Appendices provide guidance on the tolerance of machined components and castings.

Product Details

Edition: 2nd Published: 11/16/1992 ISBN(s): 072627805 Number of Pages: 72 File Size: 1 file , 610 KB Product Code(s): 10089483, 10089493, 10089478
