AS 1100.101-1992 [ Current ] Technical drawing, Part 101: General principles

standard by Standards Australia, 11/16/1992

Full Description

Sets out the basic principles of technical drawing practice, and covers terminology and abbreviations used in technical drawings; materials, sizes and layout of drawing sheets; types and thicknesses of lines; types and dimensions of letters, numerals and symbols; drawing scales; projectioning; sectioning; dimensioning and geometry tolerancing and the conventional representation of features and parts. Appendices provide information on the development of pictorial drawings and geometry tolerancing.

Product Details

Edition: 2nd Published: 11/16/1992 ISBN(s): 0726278068 Number of Pages: 232 File Size: 1 file , 1.9 MB Product Code(s): 10133787, 10133754, 10133771
