ASME B30.5-2014
M00049857
New product
ASME B30.5-2014 Mobile and Locomotive Cranes
standard by ASME International, 12/31/2014
Full Description
Within the general scope defined in Section I,American National Standard B30.5 applies to crawlercranes, locomotive cranes, wheel-mounted cranes, andany variations thereof that retain the same fundamentalcharacteristics. The scope includes only cranes of theabove types that are basically powered by internal combustionengines or electric motors. Side boom tractorsand cranes designed for railway and automobile wreckclearance, digger derricks, cranes manufactured specificallyfor, or when used for, energized electrical line service,knuckle boom, trolley boom cranes, and craneshaving a maximum rated capacity of one ton or less areexcluded.Special adaptions to the general types of machinescovered by this Volume, where applicable, fall underthis scope.
Some basic machine types within this scope are usedalternatively for lifting service and for applications notconsidered to be lifting service. All of the requirementsof this Volume are applicable to such machines whenused for lifting service. However, at a minimum,Section 5-1.11, Chapter 5-2, and Section 5-3.1 of thisVolume apply to machines when used in other thanlifting service.
In stock
More info
Mobile and Locomotive Cranes
Safety Standard for Cableways, Cranes, Derricks, Hoists, Hooks, Jacks, and Slings
AN A MERICAN NA TIONAL S T AND ARD
ASME B30.5-2014
(Revision of ASME B30.5-2011)
ASME B30.5-2014
(Revision of ASME B30.5-2011)
Mobile and Locomotive Cranes
Safety Standard for Cableways, Cranes, Derricks, Hoists, Hooks, Jacks, and Slings
AN AMERICAN NA TIONAL S T AND ARD
Two Park Avenue • New York, NY • 10016 USA
Date of Issuance: December 31, 2014
The next edition of this Standard is scheduled for publication in 2019. This Standard will become effective 1 year after the Date of Issuance.
ASME issues written replies to inquiries concerning interpretations of technical aspects of this Standard. Interpretations are published on the ASME Web site under the Committee Pages at https://cstools.asme.org/ as they are issued. Interpretations will also be included with each edition.
Errata to codes and standards may be posted on the ASME Web site under the Committee Pages to provide corrections to incorrectly published items, or to correct typographical or grammatical errors in codes and standards. Such errata shall be used on the date posted.
The Committee Pages can be found at https://cstools.asme.org/. There is an option available to automatically receive an e-mail notification when errata are posted to a particular code or standard. This option can be found on the appropriate Committee Page after selecting “Errata” in the “Publication Information” section.
ASME is the registered trademark of The American Society of Mechanical Engineers.
This code or standard was developed under procedures accredited as meeting the criteria for American National Standards. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.
ASME does not “approve,” “rate,” or “endorse” any item, construction, proprietary device, or activity.
ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assumes any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.
Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.
ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.
No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,
without the prior written permission of the publisher.
The American Society of Mechanical Engineers Two Park Avenue, New York, NY 10016-5990
Copyright © 2014 by
THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS
All rights reserved Printed in U.S.A.
CONTENTS
Foreword .............................................................................. Committee Roster ..................................................................... B30 Standard Introduction ............................................................. Summary of Changes .................................................................. | v vii ix xii |
Chapter 5-0 Scope, Definitions, Personnel Competence, and References ............... | 1 |
Section 5-0.1 Scope of B30.5 ........................................................ | 1 |
Section 5-0.2 Definitions ............................................................ | 1 |
Section 5-0.3 Personnel Competence ................................................ | 7 |
Section 5-0.4 References ............................................................ | 7 |
Chapter 5-1 Construction and Characteristics ........................................ | 8 |
Section 5-1.1 Load Ratings and Technical Information ............................... | 8 |
Section 5-1.2 Stability (Backward and Forward) ..................................... | 13 |
Section 5-1.3 Boom Hoist, Load Hoist, and Telescoping Boom Mechanisms ........... | 14 |
Section 5-1.4 Swing Mechanism .................................................... | 15 |
Section 5-1.5 Crane Travel .......................................................... | 15 |
Section 5-1.6 Controls .............................................................. | 16 |
Section 5-1.7 Ropes and Reeving Accessories ........................................ | 16 |
Section 5-1.8 Cabs .................................................................. | 20 |
Section 5-1.9 General Requirements ................................................. | 21 |
Section 5-1.10 Structural Performance ................................................ | 22 |
Section 5-1.11 Cranes Used for Other Than Lifting Service ............................ Section 5-1.12 Translations of Safety-Related Information and Control Designations ....................................................... | 22 23 |
Chapter 5-2 Inspection, Testing, and Maintenance.................................... | 24 |
Section 5-2.1 Inspection — General ................................................. | 24 |
Section 5-2.2 Testing ............................................................... | 25 |
Section 5-2.3 Maintenance .......................................................... | 26 |
Section 5-2.4 Rope Inspection, Replacement, and Maintenance ....................... | 27 |
Chapter 5-3 Operation.............................................................. | 30 |
Section 5-3.1 Qualifications and Responsibilities ..................................... | 30 |
Section 5-3.2 Operating Practices ................................................... | 34 |
Section 5-3.3 Signals ............................................................... | 38 |
Section 5-3.4 Miscellaneous ......................................................... | 38 |
Figures | |
5-0.2.1-1 Commercial Truck-Mounted Crane — Telescoping Boom ............... | 2 |
5-0.2.1-2 Commercial Truck-Mounted Crane — Nontelescoping Boom ........... | 2 |
5-0.2.1-3 Crawler Crane ........................................................ | 2 |
5-0.2.1-4 Crawler Crane — Telescoping Boom ................................... | 2 |
5-0.2.1-5 Locomotive Crane .................................................... | 3 |
5-0.2.1-6 Wheel-Mounted Crane (Multiple Control Stations) ..................... 5-0.2.1-7 Wheel-Mounted Crane — Telescoping Boom (Multiple Control Stations) .................................................... | 3 4 |
5-0.2.1-8 Wheel-Mounted Crane (Single Control Station) ........................ 5-0.2.1-9 Wheel-Mounted Crane — Telescoping Boom (Single Control Station, Rotating) ........................................... | 4 4 |
5-0.2.1-10 Wheel-Mounted Crane — Telescoping Boom (Single Control Station, Fixed) .............................................. | 5 |
iii
5-1.1.3-1 | Work Areas ........................................................... | 10 |
5-1.6.1-1 | Telescopic Boom Crane Control Diagram .............................. | 17 |
5-1.6.1-2 | Nontelescopic Boom Crane Control Diagram ........................... | 18 |
5-1.7.3-1 | Dead Ending Rope in a Socket ........................................ | 20 |
5-2.4.2-1 | Core Failure in 19 7 Rotation-Resistant Rope ........................ | 27 |
5-3.2.1.5-1 | Examples of Typical Unequal Outrigger Extension Positions ............ | 36 |
5-3.3.4-1 | Standard Hand Signals for Controlling Crane Operations .............. | 39 |
5-3.4.5.1-1 | Danger Zone for Cranes and Lifted Loads Operating Near Electrical Transmission Lines ........................................ | 42 |
Tables | ||
5-1.1.1-1 | Crane Load Ratings ................................................... | 8 |
5-3.4.5.1-1 | Required Clearance for Normal Voltage in Operation Near High-Voltage Power Lines and Operation in Transit With No Load and Boom or Mast Lowered ................................... | 44 |
Nonmandatory Appendix
A Critical Lifts 47
iv
FOREWORD
This American National Standard, Safety Standard for Cableways, Cranes, Derricks, Hoists, Hooks, Jacks, and Slings, has been developed under the procedures accredited by the American National Standards Institute (ANSI). This Standard had its beginning in December 1916 when an eight-page Code of Safety Standards for Cranes, prepared by an ASME Committee on the Protection of Industrial Workers, was presented at the annual meeting of the ASME.
Meetings and discussions regarding safety on cranes, derricks, and hoists were held from 1920 to 1925, involving the ASME Safety Code Correlating Committee, the Association of Iron and Steel Electrical Engineers, the American Museum of Safety, the American Engineering Standards Committee (AESC) [later changed to American Standards Association (ASA), then to the United States of America Standards Institute (USASI), and finally to ANSI], Department of Labor — State of New Jersey, Department of Labor and Industry — State of Pennsylvania, and the Locomo- tive Crane Manufacturers Association. On June 11, 1925, AESC approved the ASME Safety Code Correlating Committee’s recommendation and authorized the project with the U.S. Department of the Navy, Bureau of Yards and Docks, and ASME as sponsors.
In March 1926, invitations were issued to 50 organizations to appoint representatives to a Sectional Committee. The call for organization of this Sectional Committee was sent out October 2, 1926, and the committee organized November 4, 1926, with 57 members representing 29 national organizations. Commencing June 1, 1927, and using the eight-page code published by ASME in 1916 as a basis, the Sectional Committee developed the “Safety Code for Cranes, Derricks, and Hoists.” The early drafts of this safety code included requirements for jacks but, due to inputs and comments on those drafts, the Sectional Committee decided in 1938 to make the requirements for jacks a separate code. In January 1943, ASA B30.2-1943 was published addressing a multitude of equipment types and in August 1943, ASA B30.1-1943 was published just addressing Jacks. Both documents were reaffirmed in 1952 and widely accepted as safety standards.
Due to changes in design, advancement in techniques, and general interest of labor and industry in safety, the Sectional Committee, under the joint sponsorship of ASME and the Bureau of Yards and Docks (now the Naval Facilities Engineering Command), was reorganized on January 31, 1962, with 39 members representing 27 national organizations. The new committee changed the format of ASA B30.2-1943 so that the multitude of equipment types it addressed could be published in separate volumes that could completely cover the construction, installation, inspection, testing, maintenance, and operation of each type of equipment that was included in the scope of ASA B30.2. This format change resulted in the initial publication of B30.3, B30.5, B30.6, B30.11, and B30.16 being designated as “Revisions” of B30.2 with the remainder of the B30 volumes being published as totally new volumes. ASA changed its name to USASI in 1966 and to ANSI in 1969, which resulted in B30 volumes from 1943 to 1968 being designated as “ASA B30,” “USAS B30” or “ANSI B30” depending on their date of publication.
In 1982, the Committee was reorganized as an Accredited Organization Committee, operating under procedures developed by ASME and accredited by ANSI. This Standard presents a coordi- nated set of rules that may serve as a guide to government and other regulatory bodies and municipal authorities responsible for the guarding and inspection of the equipment falling within its scope. The suggestions leading to accident prevention are given both as mandatory and advisory provisions; compliance with both types may be required by employers of their employees. In case of practical difficulties, new developments, or unnecessary hardship, the administrative or regulatory authority may grant variances from the literal requirements or permit the use of other devices or methods, but only when it is clearly evident that an equivalent degree of protection is thereby secured. To secure uniform application and interpretation of this Standard, administrative or regulatory authorities are urged to consult the B30 Committee in accordance with the format described in Section IX of the Introduction, before rendering decisions on disputed
points.
v
Safety codes and standards are intended to enhance public safety. Revisions result from commit- tee consideration of factors such as technological advances, new data, and changing environmental and industry needs. Revisions do not imply that previous editions were inadequate.
The ASME B30.5-2007 edition added responsibilities to be assigned in the work site organization. The 2011 edition included minor revisions and the addition of the Nonmandatory Appendix A on critical lifts. This 2014 edition incorporates many global B30 changes including the addition of personnel competence and translation requirements as well as other revisions made throughout the document.
This edition of the B30.5 Volume was approved by the B30 Committee and by ASME, and was approved by ANSI and designated as an American National Standard on September 5, 2014.
vi
ASME B30 COMMITTEE
Safety Standard for Cableways, Cranes, Derricks, Hoists,
Hooks, Jacks, and Slings
(The following is the roster of the Committee at the time of approval of this Standard.)
STANDARDS COMMITTEE OFFICERS
L. D. Means, Chair
R. M. Parnell, Vice Chair
K. M. Hyam, Secretary
N. E. Andrew, ThyssenKrupp Steel USA, LLC
STANDARDS COMMITTEE PERSONNEL
M. J. Quinn, Alternate, Morrow Equipment Co., LLC
C. M. Robison, Alternate, UT Battelle / Oak Ridge National Laboratory
G. Austin, Terex Corp.
T. L. Blanton, NACB Group, Inc.
R. Ohman, Alternate, Verde Concept, Inc.
P. A. Boeckman, The Crosby Group, Inc.
C. E. Lucas, Alternate, The Crosby Group, Inc.
R. J. Bolen, Consultant
C. E. Cotton, Alternate, Navy Crane Center
M. E. Brunet, Manitowoc Cranes/The Manitowoc Crane Group
L. Calta, Alternate, Manitowoc Crane Group
Closson, Craft Forensic Service
B. A. Pickett, Alternate, Forensic Engineering & Applied Science Institute
R. M. Cutshall, Savannah River Nuclear Solutions
R. T. Bolton, Alternate, Savannah River Nuclear Solutions
J. A. Danielson, The Boeing Co.
P. W. Boyd, Alternate, The Boeing Co.
L. D. Demark, Sr., Equipment Training Solutions, LLC
D. F. Jordan, Alternate, BP America
D. Eckstine, Eckstine & Associates
H. G. Leidich, Alternate, Leidich Consulting Services, Inc.
R. J. Edwards, NBIS
A. J. Egging, National Oilwell Varco
R. Stanoch, Alternate, Consultant, National Oilwell Varco
E. D. Fidler, The Manitowoc Co., Inc.
G. D. Miller, Alternate, Manitowoc Cranes
J. A. Gilbert, Associated Wire Rope Fabricators
J. L. Gordon, Acco Chain & Lifting Products
N. C. Hargreaves, Consultant, Terex Hargreaves Consulting, LLC
C. E. Imerman, Alternate, Link-Belt Construction Equipment Co.
G. B. Hetherston, E. I. DuPont
B. Greenwood, Alternate, Navy Crane Center
M. Hyam, The American Society of Mechanical Engineers
D. C. Jackson, Tulsa Winch Group
S. D. Wood, Alternate, Link-Belt Construction Equipment Co.
M. M. Jaxtheimer, Navy Crane Center
S. R. Gridley, Alternate, Navy Crane Center
P. R. Juhren, Morrow Equipment Co., LLC
R. M. Kohner, Landmark Engineering Service
D. Duerr, Alternate, 2DM Associates, Inc.
A. J. Lusi Jr., Lumark Consulting LLP
E. K. Marburg, Columbus McKinnon Corp.
J. R. Burkey, Alternate, Columbus McKinnon Corp.
L. D. Means, Means Engineering & Consulting
D. A. Henninger, Alternate, Bridon American
M. W. Mills, Liberty Mutual Group
D. L. Morgan, Critical Lift Consultant, LLC
T. C. Mackey, Alternate, WRPS Handford, a URS Co.
W. E. Osborn, Ingersoll Rand
S. D. Wood, Alternate, Link-Belt Construction Equipment Co.
R. M. Parnell, ITI-Field Service
W. C. Dickinson Jr., Alternate, Crane Industry Services, LLC
J. T. Perkins, Engineering Consultant
J. R. Schober, Alternate, American Bridge Co.
E. Richardson, U.S. Department of The Navy
Kennedy, Alternate, Navy Crane Center
D. W. Ritchie, Dave Ritchie Consultant, LLC
L. K. Shapiro, Alternate, Howard I. Shapiro & Associates
J. W. Rowland III, Consultant
D. A. Moore, Alternate, Unified Engineering
J. C. Ryan, Boh Bros. Construction Co.
A. R. Ruud, Alternate, Atkinson Construction
D. W. Smith, STI Group
S. K. Rammelsberg, Alternate, CB&I
W. J. Smith Jr., Nations Builder Insurance Service
J. Schoppert, Alternate, NBIS Claims & Risk Management
R. S. Stemp, Lampson International, LLC
E. P. Vliet, Alternate, Turner Industries Group
R. G. Strain, Advanced Crane Technologies, LLC
J. Sturm, Sturm Corp.
P. D. Sweeney, General Dynamics Electric Boat
B. M. Casey, Alternate, General Dynamics Electric Boat
J. D. Wiethorn, Haag Engineering Co.
M. Gardiner, Alternate, Haag Engineering Co.
R. C. Wild, C. J. Drilling, Inc.
E. B. Stewart, Alternate, U.S. Army Corps of Engineers
D. N. Wolff, National Crane/Manitowoc Crane Group
J. A. Pilgrim, Alternate, Manitowoc Crane Group
vii
HONORARY MEMBERS
J. W. Downs, Jr., Downs Crane and Hoist Co.
J. J. Franks, Consultant
J. M. Klibert, Lift-All Co., Inc.
R. W. Parry, Consultant
P. S. Zorich, RZP Limited
J. C. Ryan, Chair, Boh Bros Construction Co.
R. J. Bolen, Consultant
G. B. Hetherston, Alternate, E. I. DuPont
B30.5 SUBCOMMITTEE PERSONNEL
D. L. Morgan, Alternate, Critical Lift Consultant, LLC
D. W. Ritchie, Dave Ritchie Consultant, LLC
M. Gardiner, Alternate, Haag Engineering Co.
M. E. Brunet, Manitowoc Cranes/The Manitowoc Crane Group
A. L. Calta, Alternate, Manitowoc Crane Group
L. D. Demark, Sr., Equipment Training Solutions, LLC
A. J. Lusi Jr., Alternate, Lumark Consulting LLP
D. Eckstine, Eckstine & Associates
W. J. Smith Jr., Alternate, Nations Builder Insurance Service
E. D. Fidler, The Manitowoc Co., Inc.
G. Austin, Alternate, Terex Corp.
D. A. Henninger, Bridon American
L. D. Means, Alternate, Means Engineering & Consulting
R. M. Kohner, Landmark Engineering Service
J. W. Rowland III, Consultant
R. S. Stemp, Lampson International, LLC
T. Sicklesteel, Alternate, Sicklesteel Cranes, Inc.
J. Sturm, Sturm Corp.
E. P. Vliet, Turner Industries Group
D. F. Jordan, Alternate, BP America
R. C. Wild, C. J. Drilling, Inc.
J. Schoppert, Alternate, NBIS Claims & Risk Management
D. N. Wolff, National Crane/Manitowoc Crane Group
J. A. Pilgrim, Alternate, Manitowoc Crane Group
S. D. Wood, Link-Belt Construction Equipment Co.
C. E. Imerman, Alternate, Link-Belt Construction Equipment Co.
P. W. Boyd, The Boeing Co.
J. D. Cannon, U.S. Army Corps of Engineers
M. J. Eggenberger, Bay Ltd.
H. A. Hashem, Saudi Aramco
B30 INTEREST REVIEW GROUP
M. W. Osborne, E-Crane International USA
G. L. Owens, Consultant
A. G. Rocha, Belgo Bekaert Arames
W. Rumburg, Crane Consultants, Inc.
J. Hui, School of Civil Engineering, People’s Republic of China
A. Mattoli, Prowinch, LLC
C. C. Tsaur, Institute of Occupational Safety on Health, Taiwan
B30 REGULATORY AUTHORITY COUNCIL
C. Shelhamer, Chair, New York City Department of Buildings
A. O. Omran, Alternate, NYC Department of Buildings
G. Beer, Iowa OSHA
L. G. Campion, U.S. Department of Labor/OSHA
W. L. Cooper, Arizona Department of Occupational Safety and Health
W. J. Dougherty Jr., City of Philadelphia
C. Harris, City of Chicago — Department of Buildings
K. M. Hyam, The American Society of Mechanical Engineers
J. L. Lankford, State of Nevada/OSHA
A. Lundeen, State of Washington, Department of Labor and Industries
D. G. Merriman, New York State Department of Labor, Division of Safety & Health/PESH
G. E. Pushies, Michigan Occupational Safety and Health Administration
C. R. Smith, Pennsylvania Department of State, Bureau of Professional and Occupational Affairs, Crane Board Member
C. N. Strib
