Safety Standard for Conveyors and Related Equipment

AN AMERICAN NA TIONAL S T AND ARD

ASME B20.1-2012

(Revision of ASME B20.1-2009)

ASME B20.1-2012

(Revision of ASME B20.1-2009)

Safety Standard for Conveyors and Related Equipment

AN AMERICAN NA TIONAL S T AND ARD

Three Park Avenue • New York, NY • 10016 USA

Date of Issuance: May 15, 2012

The next edition of this Standard is scheduled for publication in 2015. This Standard will become effective 1 year after the Date of Issuance.

ASME issues written replies to inquiries concerning interpretations of technical aspects of this Standard. Interpretations are published on the ASME Web site under the Committee Pages at https://cstools.asme.org/ as they are issued.

Errata to codes and standards may be posted on the ASME Web site under the Committee Pages to provide corrections to incorrectly published items, or to correct typographical or grammatical errors in codes and standards. Such errata shall be used on the date posted.

The Committee Pages can be found at https://cstools.asme.org/. There is an option available to automatically receive an e-mail notification when errata are posted to a particular code or standard. This option can be found on the appropriate Committee Page after selecting “Errata” in the “Publication Information” section.

ASME is the registered trademark of The American Society of Mechanical Engineers.

This code or standard was developed under procedures accredited as meeting the criteria for American National Standards. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.

ASME does not “approve,” “rate,” or “endorse” any item, construction, proprietary device, or activity.

ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assumes any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.

Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.

ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.

No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,

without the prior written permission of the publisher.

The American Society of Mechanical Engineers Three Park Avenue, New York, NY 10016-5990

Copyright © 2012 by

THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS

All rights reserved Printed in U.S.A.

CONTENTS

Foreword iv

Committee Roster vi

Summary of Changes vii

Introduction 1

1. Scope 1

2. Reference to Other Codes 1

3. Intent 1

4. Definitions 2

5. General Safety Standards 7

6. Specific Safety Standards 9

iii

FOREWORD

The first edition of the Safety Standard for Conveyors, Cableways, and Related Equipment was sponsored by the National Conservation Bureau and the American Society of Mechanical Engineers (ASME). It was approved by the American Standards Association (now known as the American National Standards Institute) (ANSI) as American Standard B20.1-1947.

In 1950, the Sectional Committee B20 was reorganized under the sponsorship of the Accident Prevention Department of the Association of Casualty and Surety Companies and ASME. Four Subcommittees were formed to make specific recommendations for revisions. These were

Subcommittee No. 1: Scope and Intent Subcommittee No. 2: Nomenclature and Definitions Subcommittee No. 3: Portable Conveyors Subcommittee No. 4: Conveyors in General

Section 5, Definitions, was based on the conveyor industry dictionary, Conveyor Terms and Definitions, as prepared by the Technical Committee (now the Engineering Conference) of the Conveyor Equipment Manufacturers Association (CEMA).

The second edition of this Standard, dated April 1955, was submitted in draft form to the Sectional Committee for approval and distributed to industry in general for criticism and comment. Approval was then given by the Sectional Committee, the sponsors, and the American Standards Association. The Standard was designated as American Standard B20.1-1957 on December 4, 1957. In 1967, the third edition of the Safety Standard for Conveyors and Related Equipment was submitted in draft form to representatives of industry for comment. It was subsequently approved by the Sectional Committee, the sponsors, and ANSI for issuance as American National Standard

B20.1-1972 on February 17, 1972.

The fourth edition of the Safety Standard for Conveyors and Related Equipment was undertaken in 1973 to assist the Office of Safety and Health Standards, U.S. Department of Labor, which indicated interest in the Standard.

A change in format from a specification standard to a performance standard was deemed necessary. Simply stated, the Standard describes what end result should be achieved without the limiting specification usually given by a design and without the inclusion of finite material selection or dimensions.

The fourth edition was subsequently approved by the B20 American National Standards Committee, the Secretariat, and ANSI for issuance as American National Standard B20.1-1976 on June 14, 1976.

In accordance with the policy of ANSI, the B20 Committee began working on a revision of B20.1-1976 in February 1980. The fifth edition was approved by the B20 Committee, the sponsor (ASME), and ANSI for issuance as American National Standard B20.1-1984 on March 13, 1984. Per the procedures outlined and implemented in the fifth edition, the sixth edition was approved by the B20 Committee, the sponsor (ASME), and ANSI for issuance as American National Standard B20.1-1987 on March 11, 1987. The seventh edition was approved for issuance as an American National Standard on March 26, 1990. The eighth edition was approved for issuance as an

American National Standard on August 9, 1993.

The ninth edition was a compilation of changes occurring in the 1993 edition, B20.1a-1994, and B20.1b-1995. It was approved for issuance as an American National Standard on May 23, 1997. The 2000 edition was a compilation of changes from the B20.1a-1997 and B20.1b-1998 addenda.

It was approved for issuance as an American National Standard on December 14, 2000.

Following approval by the B20 Committee and ASME, and after public review, ASME B20.1-2003 was approved by ANSI on October 9, 2003. The 2003 edition was a revision to B20.1-2000.

ASME B20.1-2006 was approved by ANSI on September 7, 2006. The 2006 edition was a revision to B20.1-2003.

ASME B20.1-2009 was approved by ANSI on February 2, 2009. This 2009 edition was a revision to ASME B20.1-2006.

iv

ASME B20.1-2012 was approved by ANSI on March 28, 2012. This 2012 edition is a revision to B20.1-2009.

This Standard shall become effective 1 year from the date of issuance.

Safety standards for mechanical power apparatus are published in ANSI B15.1-2000 (R2008) Safety Standard for Mechanical Power Transmission Apparatus. Safety standards for lockout and tagout procedures are published in ANSI Z244.1-1982 (R1993), Safety Requirements for Lock Out/ Tag Out of Energy Sources and OSHA Standard Number 29 CFR 1910.147, The Control of Hazardous Energy (Lockout/Tagout). The use of recommendations and guidelines as published by CEMA, Safety Label Brochure No. 201 and Guidelines for Vertical Reciprocating Conveyors, published by the Conveyor Product Section of The Material Handling Institute in conjunction with ASME B20.1 is encouraged, as are the above-mentioned standards.

The values stated within this Standard are in both SI and U.S. Customary units, with the latter placed in parentheses. These units are essentially interchangeable, and, depending on the country, as well as industry preferences, the user will determine which values are to be regarded as the standard.

Safety codes and standards are intended to enhance public safety. Revisions result from committee consideration of factors such as technological advances, new data, and changing environmental and industry needs. Revisions do not imply that previous editions were inadequate.

v

ASME B20 COMMITTEE

Safety Standard for Conveyors and Related Equipment

(The following is a roster of the Committee at the time of publication of this Standard.)

STANDARDS COMMITTEE OFFICERS

R. W. Parry, Chair

M. R. Webster, Vice Chair

R. Mohamed, Secretary

STANDARDS COMMITTEE PERSONNEL

M. S. Adel, Autoquip Corp.

T. M. Berger, Martin Sprocket & Gear

A. C. Bhalerao, Bechtel Corp.

T. Brandlein, Oxbow Carbon & Minerals Corp.

J. Campbell, Alliant Corp.

D. W. Duff, Material Handling Consulting, LLC

J. J. Galante, Southworth Product Corp.

F. J. Loeffler, Jr., Loeffler Engineering Group

M. McGettigan, Dematic Corp.

R. Mohamed, The American Society of Mechanical Engineers

J. B. Parker, Cargill, Inc.

R. W. Parry, Consultant

W. E. Phillips, Jr., CNA

R. A. Reinfried, Conveyor Equipment Manufacturers Association

E. A. Sefcik, Darrott

M. R. Webster, Pflow Industries, Inc.

B. R. Whitman, Honorary Member, Consultant

A. Youtz, Andy Youtz, LLC

vi

ASME B20.1-2012 SUMMARY OF CHANGES

Following approval by the ASME B20 Committee and ASME, and after public review, ASME B20.1-2012 was approved by the American National Standards Institute on March 28, 2012.

ASME B20.1-2012 includes the following changes identified by a margin note, (12).

conveyor, pipe; conveyor, sandwich; conveyor, square belt; conveyor, teardrop; conveyor, tube; and skirtboard added

9 6.1.1 Subparagraphs (a)(6), (a)(7), and (a)(8) added

15 6.22 Added

vii

INTENTIONALLY LEFT BLANK

viii

ASME B20.1-2012

SAFETY STANDARD FOR CONVEYORS AND RELATED EQUIPMENT

(12)

(12)

INTRODUCTION

Accidents resulting from the manual handling of materials have been reduced by the use of conveying and other forms of mechanical handling equipment. A further reduction in the accident rate can be gained by following safe practices in the design, construction, installation, operation, and maintenance of such equipment.

The design and installation of conveyors and con- veyor systems should be supervised by qualified engi- neers. Likewise, the operation and maintenance of conveyors and systems should be supervised by trained personnel.

The purpose of this Standard is to present certain guides for the design, construction, installation, opera- tion, and maintenance of conveyors and related equipment.

Those portions of this Standard relating to mainte- nance and operation procedures are fully as important as those relating to design and installation. The best design features may be negated by faulty maintenance and operating practices. It is important that operating and maintenance personnel be instructed in recognizing hazards and pertinent safety precautions.

Operation and maintenance instructions in this Safety Standard are intended for general applications. The equipment manufacturer and/or installer should be consulted for specific operating or maintenance instructions.

1. SCOPE

   This Standard applies to the design, construction, installation, maintenance, inspection, and operation of conveyors and conveying systems in relation to hazards. The conveyors may be of the bulk material, package, or unit-handling types, where the installation is designed for permanent, temporary, or portable operation.

   This Standard shall apply, with the exceptions noted below, to all conveyor installations.

   This Standard specifically excludes any conveyor designed, installed, or used primarily for the movement of people. This Standard does, however, apply to certain conveying devices that incorporate within their support- ing structure workstations or operator’s stations specifi- cally designed for authorized operating personnel.

   This Standard does not apply to conveyors such as underground mine conveyors for which specific stan- dards are already in effect, or to equipment such as industrial trucks, tractors, trailers, automatic guided vehicles, tiering machines (except pallet load tierers), cranes, hoists, power shovels, power scoops, bucket drag lines, trenchers, platform elevators designed to carry passengers or an operator, manlifts, moving walks, mov- ing stairways (escalators), highway or railroad vehicles, cableways, tramways, dumbwaiters, material lifts, industrial scissors lifts, pneumatic conveyors, robots, or integral machine transfer devices. Some of the foregoing have specific standards.

   The provisions of this Standard shall apply to equip- ment installed 1 yr after the date of issuance.




2. REFERENCE TO OTHER CODES

   Certain other codes and standards have been cited as references in this Standard. Reference to them does not constitute inclusion of the complete text of such codes or standards as a part of this Standard.

   This Safety Standard for conveyors is supplementary to any law or code covering fire or health regulations.




3. INTENT

   The intent of this Standard is to provide for safe opera- tion and maintenance of conveying equipment.

   Suggestions for improvement of this Standard may be submitted to the Secretary of the B20 Committee, ASME, Three Park Avenue, New York, NY 10016-5990.

   Proposals should be written in accordance with the following format:

   1. Specify page and paragraph designation of the pertinent standard.

   2. Indicate suggested change (addition, deletion, revision, etc.).

   3. Briefly state reason and/or evidence for suggested change.

   4. Separately submit suggested changes if more than one paragraph is affected.

The B20 Committee will consider each suggested change at its first meeting after receipt of the suggested change(s).

The B20 Committee will render an interpretation of any requirement of the Standard. Interpretations will be
