ASME A17.1/ CSA B44-2013 Handbook
M00050033
New product
ASME A17.1/ CSA B44-2013 Handbook Handbook on Safety Code for Elevators and Escalators, Safety Code for Elevators
Handbook / Manual / Guide by ASME International, 05/01/2014
Edward A. Donoghue, CPCA
Full Description
ASME A17.1-2013/CSA B44-13-one of ASME's most popular safety standards-addresses elevators, escalators, dumbwaiters, moving walks and material lifts. It provides requirements applying to the design, construction, installation, operation, testing, inspection, maintenance, alteration and repair of these conveyances.This living landmark has been defining safety in elevators, escalators and related equipment since 1921. A17.1 has been harmonized with CSA B44 to provide one comprehensive solution for jurisdictions throughout North America.
Major changes for the 2013 edition include:Requirements for wind turbine elevatorsRequirements for outsinde emergency elevatorsA new feature called Elevator Evacuation Operation (EEO) which allows for the use of elevators evacuationAn extensive update to the seismic requirementsUpdated requirements related to the maintenance control programA17.1 is to be used in conjunction with other volumes of ASME's A17 series of safety standards. Careful application of these A17 safety standards will help users to comply with applicable regulations within their jurisdictions, while achieving the operational and safety benefits to be gained from the many industry best-practices detailed within these volumes.
Intended for anyone engaged in the safety of elevators, escalators and related conveyances, including those responsible for: design, engineering and manufacture; installation, operation, testing, maintenance, alteration and repair; inspection; plans, contracts, administration, insurance and liability; property, facilities and plant management; and emergency response.
In stock
More info
2013 Edition
ASME A17.1/CSA B44
Handbook
ASME A17.1-2013, Safety Code for Elevators and Escalators
CSA B44-13, Safety Code for Elevators
Edward A. Donoghue, cpca
Copyright c 2014 by the American Society of Mechanical Engineers.
No reproduction may be made of this material without written consent of ASME.
2013 Edition
2013 Edition
ASME A17.1/CSA B44
Handbook
ASME A17.1-2013, Safety Code for Elevators and Escalators
CSA B44-13, Safety Code for Elevators
Edward A. Donoghue, CPCA
Two Park Avenue • New York, NY • 10016 USA
No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,
without the prior written permission of the publisher.
Copyright © 2014 by
THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS
All rights reserved Printed in U.S.A.
CONTENTS
Introduction vii
Foreword viii
Acknowledgments xii
Summary of Code Changes xiii
Part 1 General 1
Scope 1
Purpose and Exceptions 1
Definitions 3
Part 2 Electric Elevators 5
Scope 5
Construction of Hoistways and Hoistway Enclosures 5
Pits 21
Location and Guarding of Counterweights 27
Vertical Clearances and Runbys for Cars and Counterweights 29
Horizontal Car and Counterweight Clearances 34
Protection of Space Below Hoistways 41
Machinery Spaces, Machine Rooms, Control Spaces, and Control
Rooms 41
Equipment in Hoistways, Machinery Spaces, Machine Rooms,
Control Spaces, and Control Rooms 52
Machinery and Sheave Beams, Supports, and Foundations 59
Guarding of Equipment and Standard Railing 67
Protection of Hoistway Openings 67
Hoistway-Door Locking Devices and Electric Contacts, and Hoistway Access Switches 93
Power Operation of Hoistway Doors and Car Doors 103
Car Enclosures, Car Doors and Gates, and Car Illumination 124
Car Frames and Platforms 142
Capacity and Loading 151
Car and Counterweight Safeties 155
Speed Governors 168
Ascending Car Overspeed and Unintended Car Movement
Protection 174
Suspension Means and Their Connections 188
Counterweights 197
Buffers and Bumpers 198
Car and Counterweight Guide Rails, Guide-Rail Supports, and
Fastenings 205
Driving Machines and Sheaves 208
Terminal Stopping Devices 227
Operating Devices and Control Equipment 240
Emergency Operation and Signaling Devices 307
Layout Data 358
Identification 358
Part 3 Hydraulic Elevators 359
Scope 359
3.1 Construction of Hoistways and Hoistway Enclosures 359
iii
3.4 | Bottom and Top Clearances and Runbys for Cars and Counterweights .................................................. | 360 |
3.6 | Protection of Spaces Below Hoistway ................................ | 362 |
3.7 | Machinery Spaces, Machine Rooms, Control Spaces, and Control Rooms ........................................................... | 362 |
3.11 | Protection of Hoistway-Landing Openings ........................... | 363 |
3.14 | Car Enclosures, Car Doors and Gates, and Car Illumination .......... | 363 |
3.15 | Car Frames and Platforms .......................................... | 363 |
3.16 | Capacity and Loading .............................................. | 363 |
3.17 | Car Safeties, Counterweight Safeties, Plunger Gripper, and Governors ................................................... | 364 |
3.18 | Hydraulic Jacks ..................................................... | 368 |
3.19 | Valves, Pressure Piping, and Fittings ................................ | 372 |
3.21 | Counterweights ..................................................... | 374 |
3.22 | Buffers and Bumpers ............................................... | 374 |
3.23 | Guide Rails, Guide-Rail Supports, and Fastenings .................... | 374 |
3.24 | Hydraulic Machines and Tanks ...................................... | 374 |
3.25 | Terminal Stopping Devices .......................................... | 375 |
