AN INTERNA TIONAL C ODE

2007 ASME Boiler & Pressure Vessel Code

2007 Edition July 1, 2007

AN INTERNA TIONAL C ODE

2007 ASME Boiler & Pressure Vessel Code

2007 Edition July 1, 2007

II

Part A

Ferrous Material Specifications (Beginning to SA-450)

MATERIALS

ASME Boiler and Pressure Vessel Committee

Subcommittee on Materials

Date of Issuance: July 1, 2007

(Includes all Addenda dated July 2006 and earlier)

This international code or standard was developed under procedures accredited as meeting the criteria for American National Standards and it is an American National Standard. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.

ASME does not “approve,” “rate,” or “endorse” any item, construction, proprietary device, or activity.

ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assume any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.

Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.

ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.

The footnotes in this document are part of this American National Standard.

ASME collective membership mark

The above ASME symbols are registered in the U.S. Patent Office.

“ASME” is the trademark of the American Society of Mechanical Engineers.

The Specifications published and copyrighted by the American Society for Testing and Materials are reproduced with the Society’s permission.

No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise, without the prior written permission of the publisher.

Library of Congress Catalog Card Number: 56-3934 Printed in the United States of America

Adopted by the Council of the American Society of Mechanical Engineers, 1914.

Revised 1940, 1941, 1943, 1946, 1949, 1952, 1953, 1956, 1959, 1962, 1965, 1968, 1971, 1974, 1977, 1980, 1983, 1986,

1989, 1992, 1995, 1998, 2001, 2004, 2007

The American Society of Mechanical Engineers Three Park Avenue, New York, NY 10016-5990

Copyright © 2007 by

THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS

All Rights Reserved

2007 ASME

BOILER AND PRESSURE VESSEL CODE

SECTIONS

I Rules for Construction of Power Boilers II Materials

Part A — Ferrous Material Specifications Part B — Nonferrous Material Specifications

Part C — Specifications for Welding Rods, Electrodes, and Filler Metals Part D — Properties (Customary)

Part D — Properties (Metric)

1. Rules for Construction of Nuclear Facility Components

   Subsection NCA — General Requirements for Division 1 and Division 2 Division 1

   Subsection NB — Class 1 Components Subsection NC — Class 2 Components Subsection ND — Class 3 Components Subsection NE — Class MC Components Subsection NF — Supports

   Subsection NG — Core Support Structures

   Subsection NH — Class 1 Components in Elevated Temperature Service Appendices

   Division 2 — Code for Concrete Containments

   Division 3 — Containments for Transportation and Storage of Spent Nuclear Fuel and High Level Radioactive Material and Waste

2. Rules for Construction of Heating Boilers V Nondestructive Examination

VI Recommended Rules for the Care and Operation of Heating Boilers VII Recommended Guidelines for the Care of Power Boilers

VIII Rules for Construction of Pressure Vessels Division 1

Division 2 — Alternative Rules

Division 3 — Alternative Rules for Construction of High Pressure Vessels IX Welding and Brazing Qualifications

1. Fiber-Reinforced Plastic Pressure Vessels

2. Rules for Inservice Inspection of Nuclear Power Plant Components XII Rules for Construction and Continued Service of Transport Tanks

ADDENDA

Colored-sheet Addenda, which include additions and revisions to individual Sections of the Code, are published annually and will be sent automatically to purchasers of the applicable Sections up to the publication of the 2010 Code. The 2007 Code is available only in the loose-leaf format; accordingly, the Addenda will be issued in the loose-leaf, replacement-page format.

INTERPRETATIONS

ASME issues written replies to inquiries concerning interpretation of technical aspects of the Code. The Inter- pretations for each individual Section will be published separately and will be included as part of the update service to that Section. Interpretations of Section III, Divisions 1 and 2, will be included with the update service to Subsec- tion NCA.

Interpretations of the Code are distributed annually in July with the issuance of the edition and subse- quent addenda. Interpretations posted in January at www.cstools.asme.org/interpretations are included in the July distribution.

CODE CASES

The Boiler and Pressure Vessel Committee meets regu- larly to consider proposed additions and revisions to the Code and to formulate Cases to clarify the intent of existing requirements or provide, when the need is urgent, rules for materials or constructions not covered by existing Code rules. Those Cases that have been adopted will appear in the appropriate 2007 Code Cases book: “Boilers and Pressure Vessels” and “Nuclear Components.” Supple- ments will be sent automatically to the purchasers of the Code Cases books up to the publication of the 2010 Code.

CONTENTS

Foreword ............................................................................... ix

Statements of Policy .................................................................... xiii

Personnel .............................................................................. xv

ASTM Personnel xxvii

Preface xxix

Specifications Listed by Materials xxxi

Specification Removal xxxix

Guidelines on Submittal of Technical Inquiries to the Boiler and Pressure Vessel

Committee ........................................................................... xli

Guideline on the Approval of New Materials Under the ASME Boiler and Pressure Vessel

Code ................................................................................ xliii

Guideline on Acceptable ASTM Editions .................................................. xlvii

Guideline on Acceptable Non-ASTM Editions ............................................. lvii

Guidelines on Multiple Marking of Materials .............................................. lix Summary of Changes .................................................................... lxi

List of Changes in BC Order ............................................................. lxii

Specifications

SA-6/SA-6M General Requirements for Rolled Structural Steel Bars, Plates, Shapes, and

Sheet Piling 1

SA-20/SA-20M General Requirements for Steel Plates for Pressure Vessels 83

SA-29/SA-29M General Requirements for Steel Bars, Carbon and Alloy, Hot-Wrought and

Cold-Finished 127

SA-31 Steel Rivets and Bars for Rivets, Pressure Vessels 153

SA-36/SA-36M Carbon Structural Steel 157

SA-47/SA-47M Ferritic Malleable Iron Castings 163

SA-53/SA-53M Pipe, Steel, Black and Hot-Dipped, Zinc-Coated, Welded and Seamless 171

SA-105/SA-105M Carbon Steel Forgings for Piping Applications 199

SA-106 Seamless Carbon Steel Pipe for High-Temperature Service 205

SA-134 Pipe, Steel, Electric-Fusion (Arc)-Welded (Sizes NPS 16 and Over) 221

SA-135 Electric-Resistance-Welded Steel Pipe 227

SA-178/SA-178M Electric-Resistance-Welded Carbon Steel and Carbon-Manganese Steel

Boiler and Superheater Tubes 237

SA-179/SA-179M Seamless Cold-Drawn Low-Carbon Steel Heat Exchanger and Condenser

Tubes 243

SA-181/SA-181M Carbon Steel Forgings, for General-Purpose Piping 247

SA-182/SA-182M Forged or Rolled Alloy and Stainless Steel Pipe Flanges, Forged

Fittings, and Valves and Parts for High-Temperature Service 251

SA-192/SA-192M Seamless Carbon Steel Boiler Tubes for High-Pressure Service 271

SA-193/SA-193M Alloy Steel and Stainless Steel Bolting Materials for High-Temperature

Service 275

SA-194/SA-194M Carbon and Alloy Steel Nuts for Bolts for High-Pressure or High-

Temperature Service, or Both 293

SA-202/SA-202M Pressure Vessel Plates, Alloy Steel, Chromium-Manganese-Silicon 311

SA-203/SA-203M Pressure Vessel Plates, Alloy Steel, Nickel 315

SA-204/SA-204M Pressure Vessel Plates, Alloy Steel, Molybdenum 319
