Cast Copper Alloy Pipe Flanges, Flanged Fittings, and Valves

Classes 150, 300, 600, 900,

1500, and 2500

AN A MERICAN NA TIONAL S T AND ARD

ASME B16.24-2016

(Revision of ASME B16.24-2011)

ASME B16.24-2016

(Revision of ASME B16.24-2011)

Cast Copper Alloy Pipe Flanges, Flanged Fittings, and Valves

Classes 150, 300, 600, 900,

1500, and 2500

AN AMERICAN NA TIONAL S T AND ARD

Two Park Avenue • New York, NY • 10016 USA

Date of Issuance: October 31, 2016

The next edition of this Standard is scheduled for publication in 2021.

ASME issues written replies to inquiries concerning interpretations of technical aspects of this Standard. Periodically certain actions of the ASME B16 Committee may be published as Cases. Cases and interpretations are published on the ASME Web site under the Committee Pages at https://cstools.asme.org as they are issued.

Errata to codes and standards may be posted on the ASME Web site under the Committee Pages to provide corrections to incorrectly published items, or to correct typographical or grammatical errors in codes and standards. Such errata shall be used on the date posted.

The Committee Pages can be found at https://cstools.asme.org/. There is an option available to automatically receive an e-mail notification when errata are posted to a particular code or standard. This option can be found on the appropriate Committee Page after selecting “Errata” in the “Publication Information” section.

ASME is the registered trademark of The American Society of Mechanical Engineers.

This code or standard was developed under procedures accredited as meeting the criteria for American National Standards. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.

ASME does not “approve,” “rate,” or “endorse” any item, construction, proprietary device, or activity.

ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assumes any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.

Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.

ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.

No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,

without the prior written permission of the publisher.

The American Society of Mechanical Engineers Two Park Avenue, New York, NY 10016-5990

Copyright © 2016 by

THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS

All rights reserved Printed in U.S.A.

CONTENTS

Foreword iv

Committee Roster vi

Correspondence With the B16 Committee vii

Summary of Changes ix

List of Changes in Record Number Order xi

1. Scope 1

2. General 1

3. Pressure–Temperature Ratings 2

4. Size and Method of Designating Openings 8

5. Marking 8

6. Materials 10

7. Flange and Valve Body Dimensions 11

8. Fitting and Valve Dimensions 11

9. Bolting and Gaskets 12

10. Tolerances 12

11. Pressure Testing 13

Figure

1 Method of Designating Outlets of Reducing Fittings 9

Tables

1. Pressure–Temperature Ratings for ASTM B61 Alloy C92200 and ASTM B62 Alloy

   C83600 3

2. Dimensions of Class 150 Threaded Companion and Blind Flanges for Alloys C83600

   and C92200 4

3. Dimensions of Class 150 Elbows, Tees, Crosses, Laterals, True Ys (Straight Sizes),

   and Reducers 5

4. Dimensions of Class 300 Threaded Companion and Blind Flanges for Alloys C83600

   and C92200 6

5. Dimensions of Class 300 Elbows, Tees, Crosses, Laterals, True Ys (Straight Sizes),

   and Reducers 7

6. Pressure–Temperature Ratings for ASTM B148 Alloy C95200 Flanges 8

7. Pressure–Temperature Ratings for ASTM B148 Alloy C95400 Flanges 8

   Mandatory Appendices

   1. Dimensions of Fittings in U.S. Customary Units 15

   2. ASTM B148 Valve Construction Supplemental Requirements 21

   3. References 24

Nonmandatory Appendices

1. Quality System Program 25

2. Method Used for Establishing Pressure–Temperature Ratings 26

FOREWORD

The development of the first Bronze Flanged Standard began in 1910 to eliminate the confusion prevailing in the trade with respect to bronze flange dimensions and service ratings. The work culminated and was published in 1914 under the title “1914 Brass Standard Flange Dimensions” for 150-lb and 250-lb (now Class 150 and Class 250) steam pressures.

This was superseded in 1928 by the Manufacturers Standardization Society of Valves and Fittings Industry (MSS) “Standard Practice” SP-2, which contained changes to provide inter- changeability with the American Cast-Iron Flange Standards for 125-lb (now Class 125) and Class 250 stream pressures. Subsequent revisions were issued in 1930 and 1936. In the latter, a new column of thickness for 300-lb (now Class 300) flanges was added.

In the 1937 edition, illustrations and dimensions of bronze-flanged fittings were added. This was edited and reprinted in 1943 to conform to the U.S. Department of Commerce, National Bureau of Standards, Simplified Practice Recommendation R-183-42, and to the War Production Board Limitation Order L-252, dated January 23, 1943.

In the 1946 edition, the pressure–temperature ratings were added for the Class 150 and Class 300 standards and the dimensions for that reference to the Class 250 standard were omitted. Limitation Order L-252 was canceled on April 28, 1945. The period of government prohibition of manufacture and civilian use of the Class 250 standard (during the life of Order L-252) caused no hardship on the part of either the manufacturer or the consumer, indicating that this pressure class in bronze products did not warrant being recognized as a standard.

This Standard was reviewed and reaffirmed in 1949. In October 1951, MSS ceded it to Sectional Committee B16 on Pipe Flanges and Flanged Fittings for review and possible approval as an American Standard.

Following approval of the sectional committee and sponsor organizations, it was sent to the American Standards Association (ASA), now the American National Standards Institute (ANSI), for approval and designation as an American Standard. This was granted on February 27, 1953. In 1961, following the organization of Subcommittee No. 11 (now Subcommittee J), the 1953 edition was revised. Chief among the changes recommended was the deletion of reference to brass. This resulted from an action of ASTM redefining the alloys that could properly be called bronze. Several other changes that brought the Standard up to date were also approved by the B16 Committee, with approval designation as an American Standard being granted on

July 20, 1962.

Subcommittee J, in keeping with regulations of ANSI, reviewed the Standard in 1969. Only minor changes were made. Among these were the presentation of pressure–temperature ratings in tabular form, and the gasket-retaining grooves being made permissible rather than recom- mended. Final approval of the changes was granted by ANSI on January 27, 1971.

A revision was undertaken in 1977, and several changes were proposed. Foremost among these was the addition of metric equivalents and the elimination of the optional gasket-retaining grooves. In addition, the Standard was extensively revised editorially. Following approvals by Subcommittee J and the Standards Committee, ANSI granted its approval on June 26, 1979.

In 1982, the American National Standard Committee B16 was reorganized as an ASME Committee, operating under procedures accredited by ANSI.

In 1991, the scope of the Standard was changed from bronze pipe flanges and fittings to cast copper alloy flanges and flanged fittings, and it was expanded to include class designations 150, 300, 600, 900, 1500, and 2500. The 1991 edition also established U.S. Customary units as the standard, and editorial revisions were made to improve the text. Following approval by the Standards Committee and ASME, the 1991 edition of the Standard was approved as an American National Standard by ANSI on February 1, 1991, with the new designation ASME B16.24-1991 and the new title “Cast Copper Alloy Pipe Flanges and Flanged Fittings.”

In 2001, the Standard was revised to include Nonmandatory Appendix A, Quality System Program. Editorial revisions were made for clarification. Following approval by the B16 Standards

Committee and the ASME Supervisory Board, the Standard was approved as an American National Standard by ANSI on October 24, 2001.

In the 2006 edition, metric units became the primary reference units while maintaining

U.S. Customary units in either parenthetical or separate forms. Requirements for Class 400 flanges were omitted from the Standard. In addition, several editorial revisions were made for clarity. Following approval by the Standards Committee and the ASME Board, ASME B16.24-2006, Cast Copper Alloy Pipe Flanges and Flanged Fittings: Classes 150, 300, 600, 900, 1500, and 2500 was approved as an American National Standard by ANSI on November 9, 2006.

In the 2011 edition, references to ASME Standards were revised to no longer list specific edition years; the latest edition of ASME publications applies unless stated otherwise. Materials manufactured to other editions of the referenced ASTM standards have been permitted to be used to manufacture fittings meeting the requirements of this Standard as long as the fitting manufacturer verifies the material meets the requirements of the referenced edition. Following approval by the Standards Committee and the ASME Board on PTCS, the 2011 revision was approved as an American National Standard by ANSI on August 9, 2011, with the designation ASME B16.24-2011.

In this 2016 edition, provisions have been made to revise the scope and table readings, and a new Mandatory Appendix and a new Nonmandatory Appendix have been added. Following the approval by the ASME B16 Standards Committee, approval as an American National Standard was given by ANSI on September 23, 2016, with the new designation ASME B16.24-2016 and the new title “Cast Copper Alloy Pipe Flanges, Flanged Fittings, and Valves: Classes 150, 300, 600, 900, 1500, and 2500.”

ASME B16 COMMITTEE

Standardization of Valves, Flanges, Fittings, and Gaskets

(The following is the roster of the Committee at the time of approval of this Standard.)

STANDARDS COMMITTEE OFFICERS

R. M. Bojarczuk, Chair

C. E. Davila, Vice Chair

C. Ramcharran, Secretary

A. Appleton, Alloy Stainless Products Co., Inc.

J. E. Barker, Dezurik Water Controls

R. W. Barnes, Anric Enterprises, Inc.

P. Milankov, Alternate, Consultant

K. Barron, Ward Manufacturing

STANDARDS COMMITTEE PERSONNEL

G. A. Jolly, Consultant

M. Katcher, Haynes International

T. A. McMahon, Emerson Process Management

M. L. Nayyar, NICE

W. H. Patrick, The Dow Chemical Co.

D. C. Bayreuther, Metso Automation, Flow Control Division

W. B. Bedesem, Consultant

R. M. Bojarczuk, ExxonMobil Research and Engineering Co.

A. M. Cheta, Qatar Shell GTL

M. A. Clark, NIBCO, Inc.

G. A. Cuccio, Capitol Manufacturing Co.

J. D’Avanzo, Fluoroseal Valves

1. E. Davila, Crane Energy

2. R. Frikken, Becht Engineering Co.

R. B. Hai, RBH Associates

D. Rahoi, Consultant

C. Ramcharran, The American Society of Mechanical Engineers

R. A. Schmidt, Canadoil

J. Tucker, Flowserve

F. R. Volgstadt, Volgstadt & Associates, Inc.

F. Feng, Delegate, China Productivity Center for Machinery

P. V. Craig, Contributing Member, Jomar Group

B. F. Fabian, Contributing Member, Pennsylvania Machine Works

A. G. Kireta, Jr., Contributing Member, Copper Development Association, Inc.

D. F. Reid, Contributing Member, VSP Technologies

SUBCOMMITTEE J — COPPER AND COPPER ALLOY FLANGES, FLANGED FITTINGS, AND SOLDER JOINT FITTINGS

A. G. Kireta, Jr., Chair, Copper Development Association, Inc.

M. A. Clark, Vice Chair, NIBCO, Inc.

E. Lawson, Secretary, The American Society of Mechanical Engineers

J. A. Ballanco, JB Engineering and Code Consulting PC

S. L. Cavanaugh, Cavanaugh Consulting

W. E. Chapin, Professional Code Consulting, LLC

A. Ciechanowski, NSF International

D. R. Frikken, Becht Engineering Co.

T. L. Jamison, Jamison Engineering

A. A. Knapp, A. Knapp & Associates

C. A. Mueller, Mueller Industries, Inc.

S. Robinett, Elkhart Products Corp.

1. Shingleton, Viega, LLC

2. Morgan, Alternate, Viega, LLC

S. Blair, Contributing Member, Cerro Flow Products, LLC

M. Gillespie, Contributing Member, Viega, LLC

CORRESPONDENCE WITH THE B16 COMMITTEE

General. ASME Standards are developed and maintained with the intent to represent the consensus of concerned interests. As such, users of this Standard may interact with the Committee by requesting interpretations, proposing revisions or a case, and attending Committee meetings. Correspondence should be addressed to:

Secretary, B16 Standards Committee

The American Society of Mechanical Engineers Two Park Avenue

New York, NY 10016-5990

https://go.asme.org/Inquiry

Proposing Revisions. Revisions are made periodically to the Standard to incorporate changes that appear necessary or desirable, as demonstrated by the experience gained from the application of the Standard. Approved revisions will be published periodically.

The Committee welcomes proposals for revisions to this Standard. Such proposals should be as specific as possible, citing the paragraph number(s), the proposed wording, and a detailed description of the reasons for the proposal, including any pertinent documentation.

Proposing a Case. Cases may be issued to provide alternative rules when justified, to permit early implementation of an approved revision when the need is urgent, or to provide rules not covered by existing provisions. Cases are effective immediately upon ASME approval and shall be posted on the ASME Committee Web page.

Requests for Cases shall provide a Statement of Need and Background Information. The request should identify the Standard and the paragraph, figure, or table number(s), and be written as a Question and Reply in the same format as existing Cases. Requests for Cases should also indicate the applicable edition(s) of the Standard to which the proposed Case applies.

Interpretations. Upon request, the B16 Standards Committee will render an interpretation of any requirement of the Standard. Interpretations can only be rendered in response to a written request sent to the Secretary of the B16 Standards Committee.

Requests for interpretation should preferably be submitted through the online Interpretation Submittal Form. The form is accessible at https://go.asme.org/InterpretationRequest. Upon sub- mittal of the form, the Inquirer will receive an automatic e-mail confirming receipt.

If the Inquirer is unable to use the online form, he/she may e-mail the request to the Secretary of the B16 Standards Committee at SecretaryB16@asme.org, or mail it to the above address. The request for an interpretation should be clear and unambiguous. It is further recommended that the Inquirer submit his/her request in the following format:

Subject: Cite the applicable paragraph number(s) and the topic of the inquiry in one or two words.

Edition: Cite the applicable edition of the Standard for which the interpreta- tion is being requested.

Question: Phrase the question as a request for an interpretation of a specific requirement suitable for general understanding and use, not as a request for an approval of a proprietary design or situation. Please provide a condensed and precise question, composed in such a way that a “yes” or “no” reply is acceptable.

Proposed Reply(ies): Provide a proposed reply(ies) in the form of “Yes” or “No,” with explanation as needed. If entering replies to more than one question, please number the questions and replies.

Background Information: Provide the Committee with any background information that will assist the Committee in understanding the inquiry. The Inquirer may also include any plans or drawings that are necessary to explain the question; however, they should not contain proprietary names or information.

Requests that are not in the format described above may be rewritten in the appropriate format by the Committee prior to being answered, which may inadvertently change the intent of the original request.

ASME procedures provide for reconsideration of any interpretation when or if additional information that might affect an interpretation is available. Further, persons aggrieved by an interpretation may appeal to the cognizant ASME Committee or Subcommittee. ASME does not “approve,” “certify,” “rate,” or “endorse” any item, construction, proprietary device, or activity. Attending Committee Meetings. The B16 Standards Committee regularly holds meetings and/or telephone conferences that are open to the public. Persons wishing to attend any meeting

and/or telephone conference should contact the Secretary of the B16 Standards Committee.

ASME B16.24-2016 SUMMARY OF CHANGES

Following approval by the ASME B16 Committee and ASME, and after public review, ASME B16.24-2016 was approved by the American National Standards Institute on September 23, 2016.

ASME B16.24-2016 includes the following changes identified by a margin note, (16). In addition, the title of the Standard was updated to include valves. The Record Numbers listed below are explained in more detail in the “List of Changes in Record Number Order” following this Summary of Changes.

their entirety (15-863)

(2) Subparagraph (d) deleted (15-863)

3.3 References to paras. 6.5 and 6.6 updated (15-863)

redesignated (15-2830)

1. (1) Revised to include valves (15-2830)

   (2) References to paras. 6.5.1 and 6.5.2 updated (15-2830)

   1. Revised to include valves (15-2830)

   2. Revised to include valves (15-2830)

redesignated (15-2830)

8.1.7 Revised to include valves (15-2830)

8.2 (1) First paragraph redesignated 8.2.1 (15-2830)

(2) Paragraph 8.2.2 added (15-2830)

13 11.3 Added (15-2830)

15 Mandatory Appendix I In second sentence, table numbers updated (15-2830)

20 Table I-6 Revised in its entirety (15-863) Table I-7 Added (15-863)

21–23 Mandatory Appendix II Added (15-2830)

24 Mandatory Appendix III (1) Redesignated from Mandatory Appendix II (15-2830)

1. ASME B16.10, ASME B16.34, ASME B16.47, and ASME B31T references added (15-2830)

2. ASTM and MSS references updated to latest editions (15-2830)

LIST OF CHANGES IN RECORD NUMBER ORDER

Record Number Change

11-560 Changed para. 7.6 to match the wording of other ASME B16 documents regarding thread gauging 15-863 Added a method for determining pressure–temperature ratings for flanges that conform to

ASME B16.5 dimensions, revised pressure–temperature rating tables for ASTM B148 alloy C95200,

and added pressure–temperature rating tables for ASTM B148 alloy C95400 15-1068 Changed the Scope of the Standard

15-2830 Revised the Standard to include construction details for ASTM B148 valves and updated references

INTENTIONALLY LEFT BLANK

ASME B16.24-2016

CAST COPPER ALLOY PIPE FLANGES, FLANGED FITTINGS, AND VALVES

CLASSES 150, 300, 600, 900, 1500, AND 2500

1. 1 SCOPE

   1.1 Inclusions

   This Standard covers the following cast copper alloy:

   1. threaded pipe flanges and blind flanges having class designations 150, 300, 600, 900, 1500, and 2500

   2. flanged fittings having rating class designations 150 and 300

   3. threaded and flanged valves having rating class designations 150, 300, 600, 1500, and 2500

1. Dimensional Requirements

   This Standard establishes requirements for

   1. pressure–temperature ratings

   2. size and method of designating openings for reduced fittings

   3. markings

   4. materials

   5. dimensions

   6. bolting and gaskets

   7. tolerances

   8. nondestructive examination for valves
