Metallic Gaskets for Pipe Flanges

Ring-Joint, Spiral-Wound, and Jacketed

AN A MERICAN NA TIONAL S T AND ARD

ASME B16.20-2012

(Revision of ASME B16.20-2007)

ASME B16.20-2012

(Revision of ASME B16.20-2007)

Metallic Gaskets for Pipe Flanges

Ring-Joint, Spiral-Wound, and Jacketed

AN AMERICAN NA TIONAL S T AND ARD

Two Park Avenue • New York, NY • 10016 USA

Date of Issuance: June 25, 2013

The next edition of this Standard is scheduled for publication in 2017.

ASME issues written replies to inquiries concerning interpretations of technical aspects of this Standard. Periodically certain actions of the ASME B16 Committee may be published as Cases. Cases and interpretations are published on the ASME Web site under the Committee Pages at https://cstools.asme.org/ as they are issued.

Errata to codes and standards may be posted on the ASME Web site under the Committee Pages to provide corrections to incorrectly published items, or to correct typographical or grammatical errors in codes and standards. Such errata shall be used on the date posted.

The Committee Pages can be found at https://cstools.asme.org/. There is an option available to automatically receive an e-mail notification when errata are posted to a particular code or standard. This option can be found on the appropriate Committee Page after selecting “Errata” in the “Publication Information” section.

ASME is the registered trademark of The American Society of Mechanical Engineers.

This code or standard was developed under procedures accredited as meeting the criteria for American National Standards. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.

ASME does not “approve,” “rate,” or “endorse” any item, construction, proprietary device, or activity.

ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assumes any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.

Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.

ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.

No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,

without the prior written permission of the publisher.

The American Society of Mechanical Engineers Two Park Avenue, New York, NY 10016-5990

Copyright © 2013 by

THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS

All rights reserved Printed in U.S.A.

CONTENTS

Foreword v

Committee Roster vi

Correspondence With the B16 Committee vii

Important Information Concerning Use of Asbestos or Alternative Materials viii

Summary of Changes xi

1. Scope 1

2. Ring-Joint Gaskets 1

3. Spiral-Wound Gaskets 2

4. Jacketed Gaskets 3

5. Grooved Metal Gaskets With Covering Layers 3

Figures

1. Spiral-Wound Gaskets (Metric) 5

2. Jacketed Gaskets (Metric) 5

3. Grooved Metal Gasket With Covering Layers 6

4. Illustration of Example Markings for Grooved Metal

Gasket With Covering Layers 7

Tables

1. Maximum Hardness for Ring Gaskets 1

2. Ring Gasket Markings 2

3. Type R Ring Gasket Dimensions and Tolerances 8

4. Pipe Sizes for Type R Ring Gaskets Suitable for Referenced Standards 11

5. Type RX Ring Gasket Dimensions and Tolerances 13

6. Pipe Sizes for Type RX Ring Gaskets Suitable for Referenced Standards 15

7. Type BX Ring Gasket Dimensions and Tolerances 16

8. Pipe Sizes for Type BX Ring Gaskets Suitable for Referenced Standards 17

9. Dimensions for Spiral-Wound Gaskets Used With ASME B16.5 Flanges 18

10. Dimensions for Spiral-Wound Gaskets Used With ASME B16.47 Series A Flanges 19

11. Dimensions for Spiral-Wound Gaskets Used With ASME B16.47 Series B Flanges 20

12. Inner-Ring Inside Diameters for Spiral-Wound Gaskets for Use With ASME B16.5

    Flanges 21

13. Inner-Ring Inside Diameters for Spiral-Wound Gaskets Used Between ASME

    B16.47 Series A Flanges 22

14. Inner-Ring Inside Diameters for Spiral-Wound Gaskets Used Between ASME

    B16.47 Series B Flanges 23

15. Minimum Pipe Wall Thickness Suitable for Use of Spiral-Wound Gaskets With

    Inner Rings for ASME B16.5 Flanges 24

16. Maximum Bore of ASME B16.5 Flanges for Use With Spiral-Wound Gaskets 25

17. Maximum Bore of ASME B16.47 Series A Flanges for Use With

    Spiral-Wound Gaskets 26

18. Maximum Bore of ASME B16.47 Series B Flanges for Use With

    Spiral-Wound Gaskets 27

19. Color Coding and Abbreviations for Spiral-Wound Gasket Materials 28

20. Example Markings for Spiral-Wound Gaskets 29

21. Jacketed Gasket Dimensions for ASME B16.5 Flanges 30

22. Jacketed Gasket Dimensions for ASME B16.47 Series A Flanges 31

23. Jacketed Gasket Dimensions for ASME B16.47 Series B Flanges 32




    iii

24. Abbreviations for Identifying Materials for Jacketed Gaskets 33

25. Example Markings for Jacketed Gaskets 33

26. Dimensions for Grooved Metal Gaskets With Covering Layers Used With

    ASME B16.5 Flanges 34

27. Dimensions for Grooved Metal Gaskets With Covering Layers Used With

    ASME B16.47 Series A Flanges 35

28. Dimensions for Grooved Metal Gaskets With Covering Layers Used With

    ASME B16.47 Series B Flanges 36

29. Color Coding and Abbreviations for Grooved Metal Gaskets With Covering Layers Materials 37

30. Example Markings for Grooved Metal Gaskets With Covering Layers 38

    Mandatory Appendices

    1. Dimensions of Gaskets in U.S. Customary Units 39

    2. References 61

Nonmandatory Appendix

A Quality System Program 62

iv

FOREWORD

Ring-joint gaskets and grooves probably originated in the boiler field, where they were used in various forms for manhole covers, autoclaves, and other closures; however, it was in the oil industry (both in the production and refining of oil) that they received the greatest recognition and were developed into their present form. Their use expanded steadily as temperatures and pressures were increased in steam plants. Tests examining their application in flanges and valves were conducted as early as 1928.

In June 1936, the American Petroleum Institute (API) issued Tentative Standard 5-G-3 on Ring- Joints for Steel Flanges and Flange Unions for use with API Tubular Goods. This standard was known as API Specification 6B, Ring-Joint Flanges. Following the acceptance of ring-joints for flanges and valves by API and the issuance of their standard, ASA B16e on Steel Pipe Flanges and Flanged Fittings was revised to include them, and the 1939 edition included standard dimensions for a full line of ring-joint flanges based on the API standard. Development work continued, and API formulated Standard 6E, Specification for Wellhead Equipment, which included ring-joints not covered in ASA B16e-1939.

In 1949, the American Standards Association (ASA), Sectional Committee B16, Subcommittee 3, Steel Flanges and Flanged Fittings, assembled the available information on ring-joint gaskets into a single standard. ASA approval was granted on April 30, 1952, with the designation ASA B16.20-1952.

An updated version was submitted, and ASA approval was granted on April 4, 1955, with the designation ASA B16.20-1955. Ring gaskets for Class 900 (900 lb at that time) in sizes NPS 26 through 36 were added, and ASA approval was granted on April 2, 1956. The standard was reviewed in 1962, and approval was granted by the ASA on April 25, 1963.

The standard was again reviewed and approval was granted by the American National Standards Institute (ANSI) on April 25, 1973, with the designation of an American National Standard.

API requested that ASME convert their gasket standard, API 601, into an ASME American National Standard. As a result of that request, the standard was expanded to include requirements for spiral-wound and jacketed gaskets that were formerly listed in API 601, 7th edition, 1988. Also, ring-joint groove dimensions were not included, because they were included in ASME/ ANSI B16.5-1988, Pipe Flanges and Flanged Fittings, and ASME B16.47-1990, Large Diameter Steel Flanges.

The 1993 edition was approved by the B16 Standards Committee, and, following approval by ASME, approval by ANSI was given on January 22, 1993, with the designation ASME B16.20-1993. In the 1998 edition of ASME B16.20, reference standards were updated, a quality system program annex was added, inner ring inside diameters for spiral-wound gaskets were revised, and several editorial revisions were made. Following approval by ASME B16 Subcommittee G and the B16 Main Committee, ANSI approved this American National Standard on November 20, 1998. In 2007, the Standard adopted metric dimensions as an independent standard to the U.S.Customary units, and Mandatory Appendix I was added to cover dimensional tables in

U.S. Customary units.

In 2012, the Standard introduced minor revisions to the material requirements for spiral-wound gaskets, along with the tables and figures. A new chapter has been included for Grooved Metal Gaskets With Covering Layers, and Mandatory Appendix II has also been updated to ensure relevancy.

Following approval by B16 Subcommittee G, the Standards Committee, and ASME, ANSI approved this American National Standard on October 22, 2012.
