ASME MFC-22–2007

MEASUREMENT OF LIQUID BY TURBINE FLOWMETERS

1. SCOPE

   This Standard describes the criteria for the application of a turbine flowmeter with a rotating blade for the measurement of liquid flows through closed conduit running full.

   The standard discusses the following:

   1. considerations regarding the liquids to be measured

   2. turbine flowmeter system

   3. installation requirements

   4. design specifications

   5. the maintenance, operation, and performance

   6. measurement uncertainties

      This Standard does not address the details of the installation of accessory equipment used to measure pressure, temperature, and/or density for the accurate determination of mass or base volumes, or those accesso- ries used to automatically compute mass or base volumes.




2. REFERENCES

   The following is a list of publications referenced in this Standard. Unless otherwise specified, the latest edition shall apply.

   ANSI/NCSL Z540.2-1997 (R2002), U.S. Guide to

   Expression of Uncertainty in Measurement Publisher: NCSL International, 2995 Wilderness Place,

   Suite 107, Boulder, CO 80301-5404

   ASME MFC-1M, Glossary of Terms Used in the Measurement of Fluid Flows in Pipes

   Publisher: The American Society of Mechanical Engineers (ASME), Three Park Avenue, New York, NY 10016-5990; Order Department: 22 Law Drive,

   P.O. Box 2300, Fairfield, NJ 07007-2300

   ISO Guide to the expression of uncertainty in measurement

   Publisher: International Organization for Standardization (ISO), 1 ch. de la Voie-Creuse, Case postale 56, CH-1211, Gene`ve 20, Switzerland/Suisse

   NIST Technical Note 1297 (TN 1297), Guidelines for Evaluating and Expressing the Uncertainty of NIST Measurement Results

   Publisher: United States Department of Commerce,

   Gaithersburg, MD 20899; https://physics.nist.gov/ Pubs/guidelines/TN1297/tn1297s.pdf




3. DEFINITIONS AND SYMBOLS

Much of the vocabulary and many of the symbols used in this Standard are defined in ASME MFC-1M. Others that are unique in the field under consideration, or with special technical meanings are given in para. 3.1. Where a term has been adequately defined in the main text, reference is made to the appropriate paragraph.

3.1 Definitions

base flow rate: flow rate converted from flowing condi- tions to base conditions of pressure and temperature, generally expressed in units of base volume per unit time (e.g., gpm, m3/h, etc.).

base pressure: a specified reference pressure to which a fluid volume at flowing conditions is reduced for the purpose of billing and transfer accounting. It is generally taken as 14.73 psia (101.560 kPa) by the gas industry in the U.S.

base temperature: a specified reference temperature to which a fluid volume at flowing conditions is reduced for the purpose of billing and transfer accounting. It is generally taken as 60°F (15.56°C) by the gas industry in the U.S.

base volume: volume of the fluid at base pressure and temperature.

flowing pressure: static pressure of the fluid at the flowing condition.

flowing temperature: the temperature of the fluid at the flowing condition.

linearity: linearity refers to the constancy of K factor over a specified range, defined by either the pipe Reynolds number or the flow rate. A typical liquid turbine meter performance curve is shown in Fig. 1. The linear range of the turbine meter is usually specified by a band defined by maximum and minimum K factors, within which the K factor for the meter is assumed to be Kmean. The upper and lower limits of this range can be specified by the manufacturer as a function of maximum and minimum Reynolds number ranges, a flow rate range of a specified fluid, or other meter design limitations such as pressure, temperature, or installation effects.

pipe Reynolds number: expressed by the equation

Technology Administration, National Institute of Standards and Technology (NIST), 100 Bureau Drive,

Rep p

vpD p

vpD

(1)

1
