ASME B16.15-2011 Cast Copper Alloy Threaded Fittings: Classes 125 and 250

standard by ASME International, 09/15/2011

Full Description

This Standard covers cast Classes 125 and 250 copperalloy threaded pipe fittings with provisions for substitutingwrought copper alloys for plugs, bushings, caps,and couplings in small sizes. This Standard includes thefollowing:

(a) pressure?temperature ratings

(b) size and method of designating openings of reducingpipe fittings

(c) marking requirements

(d) minimum requirements for casting quality andmaterials

(e) dimensions and tolerances in SI (metric) andU.S. Customary units

(f) threading requirements

(g) pressure test requirements

Mandatory Appendix I provides table values inU.S. Customary units.

More details

In stock

$33.00

-56%

$75.00

More info

000823U001


Cast Copper Alloy Threaded Fittings

Classes 125 and 250


AN A MERICAN NA TIONAL S T AND ARD




ASME B16.15-2011

(Revision of ASME B16.15-2006)

ASME B16.15-2011

(Revision of ASME B16.15-2006)


Cast Copper Alloy Threaded Fittings

Classes 125 and 250



AN AMERICAN NA TIONAL S T AND ARD



Three Park Avenue • New York, NY • 10016 USA


Date of Issuance: September 15, 2011


The next edition of this Standard is scheduled for publication in 2016.


ASME issues written replies to inquiries concerning interpretations of technical aspects of this Standard. Periodically certain actions of the ASME B16 Committee may be published as Cases. Cases and interpretations are published on the ASME Web site under the Committee Pages at https://cstools.asme.org as they are issued and will be published within the next edition of this Standard.


ASME is the registered trademark of The American Society of Mechanical Engineers.


This code or standard was developed under procedures accredited as meeting the criteria for American National Standards. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.

ASME does not “approve,” “rate,” or “endorse” any item, construction, proprietary device, or activity.

ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assumes any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.

Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.

ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.


No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,

without the prior written permission of the publisher.


The American Society of Mechanical Engineers Three Park Avenue, New York, NY 10016-5990


Copyright © 2011 by

THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS

All rights reserved Printed in U.S.A.


CONTENTS

Foreword iv

Committee Roster vi

Correspondence With the B16 Committee vii

Summary of Changes viii

  1. Scope 1

  2. General 1

  3. Pressure–Temperature Ratings 1

  4. Size 2

  5. Marking 2

  6. Material 2

  7. Threading 3

  8. Ribs 3

  9. Surface Finish 3

  10. Fitting Dimensions 3

  11. Tolerances 3

  12. Pressure Test 4

Figure

1 Identification of Reducing Fittings 2

Tables

  1. Pressure–Temperature Ratings 2

  2. Dimensions of 90-deg Elbows, Tees, Crosses, 45-deg Elbows, and Couplings

    (Straight Sizes) — Class 125 5

  3. Dimensions of Caps — Class 125 6

  4. Dimensions of Outside Head, Inside Head, and Face Bushings — Class 250 7

  5. Dimensions of 90-deg Elbows (Reducing Sizes) — Class 125 8

  6. Dimensions of Tees (Reducing Sizes) — Class 125 9

  7. Dimensions of 90-deg Elbows (Reducing Sizes) — Class 250 10

  8. Dimensions of Tees (Reducing Sizes) — Class 250 11

  9. Dimensions of Square Head and Square Socket Plugs 12

  10. Dimensions of Reducers, Closed and Open Pattern Return Bends, and 45-deg Y

    Branches (Straight Sizes) — Class 125 13

  11. Dimensions of 90-deg and 45-deg Street Elbows — Class 125 14

  12. Dimensions of 90-deg Elbows, Tees, Crosses, 45-deg Elbows, and Couplings

    (Straight Sizes) — Class 250 15

  13. Inspection Tolerances, Center-to-End and Center-to-Center 16

    Mandatory Appendices

    1. Ratings and Dimensions of Fittings in U.S. Customary Units 17

    2. References 29

Nonmandatory Appendix

A Quality System Program 30

iii


(11) FOREWORD


As early as the spring of 1921, the consolidation and further development of threaded and flanged fittings standards in force in this country seemed desirable. To meet this need, the American Standards Association (ASA) [now the American National Standards Institute (ANSI)] authorized the organization of a Sectional Committee on the Standardization of Pipe Flanges and Flanged Fittings (B16), with the Heating, Piping, and Air Conditioning Contractors’ National Association (now known as the Mechanical Contractors Association of America), the Manufacturers Standardization Society of the Valve and Fittings Industry (MSS), and The American Society of Mechanical Engineers acting as joint sponsors.

In June 1927, the Manufacturers Standardization Society of the Valve and Fittings Industry appointed a committee on Nonferrous Screw Fittings for the purpose of developing standards for products commonly designated as threaded pipe fittings of brass, bronze, or other nonferrous materials. At the time, brass threaded fittings were furnished from a number of different patterns with wide variations in dimensions and weights.

MSS SP-10 for 125-lb Bronze Screwed Fittings and MSS SP-11 for 250-lb Bronze Screwed Fittings were developed and adopted by the MSS in September 1930. The lighter fittings were patterned after malleable iron threaded fittings, then standardized in ASA B16c, while the heavier products were patterned after the cast iron threaded fittings covered by ASA B16d. Thus, a practice was standardized that had been found satisfactory in the valve and fittings industry over many years. Following the publication of revised editions in 1941 and 1943, SP-10 was submitted to Subcommittee No. 2 of ASA Sectional Committee B16 for adoption as an American Standard. Final approval of that edition was granted on January 23, 1947 with the designation ASA B16.15. A reaffirmation of the Standard was granted in 1952, and a complete revision for updating the

Standard was approved by ASA on March 25, 1958.

After revision in 1944, SP-11 was submitted to Subcommittee No. 2 in August 1947, and ASA granted the approval of B16.17 on April 6, 1949.

In 1961, Subcommittee No. 2 reviewed the two Standards and noted that the historical reason for their separate existence no longer applied. Accordingly, the two were combined into ASA B16.15 with final ASA approval granted on February 6, 1964.

In 1969, the document was reviewed by Subcommittee No. 2, and minor changes were proposed. Final ANSI approval was granted on April 14, 1971.

In 1977, the MSS submitted a proposed revision to Subcommittee B (formerly No. 2) for B16 review and approval. Changes included the addition of metric (SI) units and editorial updating. ANSI granted final approval on December 4, 1978.

In 1982, American National Standards Committee B16 was reorganized as the ASME B16 Committee, operating under procedures accredited by ANSI. The revision, following regular 5-yr review by Subcommittee B, involved rationalization of metric equivalent dimensions and updating of reference standards. Following approval within ASME, ANSI approval was granted on July 30, 1985 with the new designation ANSI/ASME B16.15-1985.

In 1994, and again in 2004, the document was reaffirmed.

In 2005, Subcommittee B of the ASME B16 Committee changed the title to Cast Copper Alloy Threaded Fittings, a section on leakage capacity was added, and nominal size (DN) according to ISO 6078 was addressed as SI values were positioned in the main text, while U.S. Customary values were positioned in Mandatory Appendix I. The reference for gaging internal fitting threads was made clearer by using the wording from ANSI/ASME B1.20.1, Pipe Threads — General Purpose — Inch. Many clarifying and editorial revisions were made in order to improve the text. After approval by ASME, ANSI approval was granted on August 25, 2006 with the new designation of ASME B16.15-2006.

In this edition, references to ASME standards were revised to no longer list specific edition years; the latest edition of ASME publications applies unless stated otherwise. Materials manufactured to other editions of the referenced ASTM standards have been permitted to be used to manufacture


iv

fittings meeting the requirements of this Standard as long as the fitting manufacturer verifies the material meets the requirements of the referenced edition. Following approval by the Standards Committee and the ASME Board on PTCS, this revision to the 2006 edition was approved as an American National Standard by ANSI on August 9, 2011 with the new designation ASME B16.15-2011.

All requests for interpretations or suggestions for revisions should be sent to the Secretary B16, The American Society of Mechanical Engineers, Three Park Avenue, New York, NY 10016-5990.


v


ASME B16 COMMITTEE

Standardization of Valves, Flanges, Fittings, and Gaskets

(The following is the roster of the Committee at the time of approval of this Standard.)


STANDARDS COMMITTEE OFFICERS

W. B. Bedesem, Chair

G. A. Jolly, Vice Chair

D. R. Sharp, Secretary



A. Appleton, Alloy Stainless Products Co., Inc.

R. W. Barnes, Anric Enterprises, Inc.

W. B. Bedesem, Consultant

STANDARDS COMMITTEE PERSONNEL

G. A. Jolly, Vogt Valves/Flowserve Corp.

M. Katcher, Haynes International

W. N. McLean, B&L Engineering

R. M. Bojarczuk, ExxonMobil Research and Engineering Co.

D. F. Buccicone, Elkhart Products Corp.

A. M. Cheta, Royal Dutch Shell

M. A. Clark, Nibco, Inc.

G. A. Cuccio, Capitol Manufacturing Co.

  1. E. Davila, Crane Energy

  2. R. Frikken, Becht Engineering Co.

R. P. Griffiths, U.S. Coast Guard

T. A. McMahon, Emerson Process Management

M. L. Nayyar, Bechtel Power Corp.

W. H. Patrick, The Dow Chemical Co.

R. A. Schmidt, Canadoil

D. R. Sharp, The American Society of Mechanical Engineers

H. R. Sonderegger, Fluoroseal, Inc.

W. M. Stephan, Flexitallic, L.P.

F. R. Volgstadt, Volgstadt and Associates, Inc.

D. A. Williams, Southern Company Generation


SUBCOMMITTEE B — THREADED FITTINGS (EXCEPT STEEL), FLANGES, AND FLANGED FITTINGS

K. Barron, Vice Chair, Ward Manufacturing

C. E. O’Brien, Secretary, The American Society of Mechanical Engineers

W. Bliss, Tyler Pipe Co.

R. W. Bonds, Ductile Iron Pipe Research Association

M. A. Clark, Nibco, Inc.

J. R. Holstrom, Val-Matic Valve and Manufacturing Corp.

A. A. Knapp, A. Knapp and Associates

W. H. Levan, Cast Iron Soil Pipe Institute

P. I. McGrath, Jr., Contributing Member, Consultant

W. N. McLean, B&L Engineering

J. K. Schultz, Conine Manufacturing Co., Inc.

G. L. Simmons, Charlotte Pipe and Foundry

G. T. Walden, Frischkorn, Inc.


vi


CORRESPONDENCE WITH THE B16 COMMITTEE


General. ASME Standards are developed and maintained with the intent to represent the consensus of concerned interests. As such, users of this Standard may interact with the Committee by requesting interpretations, proposing revisions, and attending Committee meetings. Corre- spondence should be addressed to:

Secretary, B16 Standards Committee

The American Society of Mechanical Engineers Three Park Avenue

New York, NY 10016-5990


As an alternative, inquiries may be submitted via email to: SecretaryB16@asme.org.

Proposing Revisions. Revisions are made periodically to the Standard to incorporate changes that appear necessary or desirable, as demonstrated by the experience gained from the application of the Standard. Approved revisions will be published periodically.

The Committee welcomes proposals for revisions to this Standard. Such proposals should be as specific as possible, citing the paragraph number(s), the proposed wording, and a detailed description of the reasons for the proposal, including any pertinent documentation.

Proposing a Case. Cases may be issued for the purpose of providing alternative rules when justified, to permit early implementation of an approved revision when the need is urgent, or to provide rules not covered by existing provisions. Cases are effective immediately upon ASME approval and shall be posted on the ASME Committee Web page.

Requests for Cases shall provide a Statement of Need and Background Information. The request should identify the Standard, the paragraph, figure or table number(s), and be written as a Question and Reply in the same format as existing Cases. Requests for Cases should also indicate the applicable edition(s) of the Standard to which the proposed Case applies.

Interpretations. Upon request, the B16 Committee will render an interpretation of any require- ment of the Standard. Interpretations can only be rendered in response to a written request sent to the Secretary of the B16 Standards Committee.

The request for interpretation should be clear and unambiguous. It is further recommended that the inquirer submit his/her request in the following format:


Subject: Cite the applicable paragraph number(s) and the topic of the inquiry.

Edition: Cite the applicable edition of the Standard for which the interpretation is being requested.

Question: Phrase the question as a request for an interpretation of a specific requirement suitable for general understanding and use, not as a request for an approval of a proprietary design or situation. The inquirer may also include any plans or drawings that are necessary to explain the question; however, they should not contain proprietary names or information.


Requests that are not in this format will be rewritten in this format by the Committee prior to being answered, which may inadvertently change the intent of the original request.

ASME procedures provide for reconsideration of any interpretation when or if additional information that might affect an interpretation is available. Further, persons aggrieved by an interpretation may appeal to the cognizant ASME Committee or Subcommittee. ASME does not “approve,” “certify,” “rate,” or “endorse” any item, construction, proprietary device, or activity. Attending Committee Meetings. The B16 Standards Committee regularly holds meetings, which are open to the public. Persons wishing to attend any meeting should contact the Secretary of

the B16 Standards Committee.


vii


ASME B16.15-2011 SUMMARY OF CHANGES


Following approval by the ASME B16 Committee and ASME, and after public review, ASME B16.15-2011 was approved by the American National Standards Institute on August 9, 2011.


ASME B16.15-2011 includes the following changes identified by a margin note, (11). In addition, in the main text, the “General” section was moved to section 2, and subsequent sections and their paragraphs were renumbered accordingly.


Page

Location

Change

iv

Foreword

Revised

1, 2

3.2

Revised

3, 4

11.1

Formerly para. 1.1

12

Table 9

Title revised

17

Mandatory Appendix I

Title and last paragraph revised

25

Table I-9

Title revised

29

Mandatory Appendix II

  1. First paragraph revised

  2. Updated

30

Nonmandatory Appendix A

Revised


NOTE: Interpretations follow the last page of this edition.


viii

ASME B16.15-2011


CAST COPPER ALLOY THREADED FITTINGS

Classes 125 and 250


  1. SCOPE

    This Standard covers cast Classes 125 and 250 copper alloy threaded pipe fittings with provisions for substitut- ing wrought copper alloys for plugs, bushings, caps, and couplings in small sizes. This Standard includes the following:

    1. pressure–temperature ratings

    2. size and method of designating openings of reduc- ing pipe fittings

    3. marking requirements

    4. minimum requirements for casting quality and materials

    5. dimensions and tolerances in SI (metric) and

      U.S. Customary units

    6. threading requirements

    7. pressure test requirements

      Mandatory Appendix I provides table values in

      U.S. Customary units.


  2. GENERAL

    1. Relevant Units

      This Standard states values in both SI (Metric) and

      U.S. Customary units. These systems of units are to be regarded separately as standard. Within the text, the

      U.S. Customary units are shown in parentheses or in separate tables that appear in Mandatory Appendix I. The values stated in each system are not exact equiva- lents; therefore, it is required that each system of units be used independently of the other. Combining values from the two systems constitutes nonconformance with the Standard.


    2. References

      Standards and specifications containing provisions to the extent referenced herein constitute requirements of this Standard. These referenced documents are listed in Mandatory Appendix II.


    3. Quality Systems

      Requirements relating to the product manufacturer’s Quality System Programs are described in Nonmandatory Appendix A.

    4. Denotation

      1. Pressure Rating Designation. Class, followed by a dimensionless number, is the designation for pressure–temperature ratings, e.g., Class 125 and Class 250.

      2. Size. NPS, followed by a dimensionless num- ber, is the designation for nominal fittings size, e.g., NPS 2.

    5. Time of Purchase, Manufacture, or Installation

      The pressure–temperature ratings in this Standard are applicable upon its publication to all fittings within its scope that otherwise meet its requirements. For unused fittings maintained in inventory, the manufacturer of the fittings may certify conformance to this edition provided that it can be demonstrated that all requirements of this edition have been met. Where such components were installed in accordance with the pressure–temperature ratings of an earlier edition of this Standard, those rat- ings are applicable except as may be governed by the applicable code or regulation.

    6. User Accountability

      This Standard cites responsibilities that are to be assumed by the fitting user in the areas of the tempera- ture at which the pressure rating is taken.

    7. Service Conditions

Criteria for selection of materials suitable for particu- lar fluid service are not within the scope of this Standard.


  1. PRESSURE–TEMPERATURE RATINGS

    1. General

      Pressure–temperature ratings for these pipe fittings are shown in Tables 1 and I-l. All pressures are gage.

    2. Rating

Pressure–temperature ratings are independent of the contained fluid and are the maximum allowable pres- sures at the tabulated temperatures. Intermediate rat- ings may be obtained by linear interpolation between the temperatures shown.

The temperature shown for the corresponding pres- sure rating shall be the material temperature of the


(11)


1
