ASME B1.7-2006

SCREW THREADS: NOMENCLATURE, DEFINITIONS, AND LETTER SYMBOLS

1. GENERAL

   1. Scope

      The purpose of this Standard is to establish a uniform practice for standard screw threads with regard to the following:

      1. screw thread nomenclature

      2. letter symbols for the designating features of a screw thread for use on drawings, in tables that set forth dimensional standards, in other records, and for ex- pressing mathematical relationship

         This Standard consists of: a glossary of terms, illus- trations, an illustrated table showing the application of symbols, and a table of thread series designations. Many of the terms and symbols specified in this Standard vary considerably from those prior to the 1984 issue, because ISO terms and symbols have been adopted where the intended definition is the same.




   2. References

      The following is a list of publications referenced in this Standard.

      ANSI/CGA V-1, National Gas Screw Threads1 Publisher: Canadian Gas Association (CGA), 350 Sparks

      Street, Ottawa, Ontario K1R 7S8, Canada

      ASME B1.20.7, Hose Coupling Screw Threads ASME Y14.5M, Dimensioning and Tolerancing

      Publisher: The American Society of Mechanical Engi- neers (ASME), Three Park Avenue, New York, NY 10016-5990; Order Department: 22 Law Drive, P.O. Box 2300, Fairfield, NJ 07007-2300

      ISO 7-1, Pipe Threads Where Pressure Tight Joints are Made on Threads—Part 1: Designation, Dimensions, and Tolerances

      ISO 228-1, Pipe Threads Where Pressure Tight Joints are Not Made on the Threads—Part 1: Designation, Di- mensions, and Tolerances

      ISO 1502, ISO General Purpose Metric Screw Thread- Gauging

      ISO 2901, ISO Metric Trapezoidal Screw Threads ISO 2902, ISO Metric Trapezoidal Screw Threads ISO 2903, ISO Metric Trapezoidal Screw Threads ISO 2904, ISO Metric Trapezoidal Screw Threads ISO/R1501, ISO Miniature Screw Threads




      1 May also be obtained from American National Standards In- stitute (ANSI), 25 West 43rd Street, New York, NY 10036.

      Publisher: International Organization for Standardiza- tion (ISO), 1 rue de Varembé, Case Postal 56, CH-1211, Genève 20, Switzerland/Suisse




   3. Federal Government Use

      When this Standard is approved by the Department of Defense and Federal agencies, and is incorporated into FED-STD-H28/1, Screw Thread Standards for Federal Services, Section 1, the use of this Standard by the Fed- eral Government is subject to all requirements and lim- itations of FED-STD-H28/1.




2. DEFINITION OF TERMS

The definitions presented herein are listed alphabeti- cally and apply generally to all forms of screw threads, thread gages, and thread measurements. They relate to the following:

1. types of screw threads

2. size and fit of threaded parts in general

3. geometric elements, attributes, and dimensions of screw threads

ISO nomenclature is used where the exact meaning is coincident with the U.S. practice.

actual fit: the measured difference, subject to measure- ment uncertainty, before assembly, between the sizes of two mating parts that are to be assembled.

actual size: the measured size of a characteristic or ele- ment subject to measurement uncertainty.

addendum: the addendum of an external thread is the ra- dial distance between the major and pitch cylinders or cones, respectively. The addendum of an internal thread is the radial distance between the minor and pitch cylin- ders or cones, respectively. This term applies to those threads having a recognized pitch cylinder or pitch cone.

allowance: a prescribed difference between the maximum material limits of mating parts. It is the minimum clear- ance (positive allowance) or maximum interference (negative allowance) between such parts. It is numeri- cally equal to the absolute value of ISO term funda- mental deviation (see Fig. 1).

attribute: nondimensional thread element(s) and charac- teristic(s), taken singly or in a group. Inspection/evalu- ation by limit gages is an attribute inspection.

axis of thread: the axis of the thread pitch cylinder or cone (see Fig. 2).

1
