Cast Copper Alloy Fittings for Flared Copper Tubes

AN A MERICAN NA TIONAL S T AND ARD

ASME B16.26-2013

(Revision of ASME B16.26-2011)

ASME B16.26-2013

(Revision of ASME B16.26-2011)

Cast Copper Alloy Fittings for Flared Copper Tubes

AN AMERICAN NA TIONAL S T AND ARD

Two Park Avenue • New York, NY • 10016 USA

Date of Issuance: September 12, 2013

The next edition of this Standard is scheduled for publication in 2018.

ASME issues written replies to inquiries concerning interpretations of technical aspects of this Standard. Periodically certain actions of the ASME B16 Committee may be published as Cases. Cases and interpretations are published on the ASME Web site under the Committee Pages at https://cstools.asme.org/ as they are issued.

Errata to codes and standards may be posted on the ASME Web site under the Committee Pages to provide corrections to incorrectly published items, or to correct typographical or grammatical errors in codes and standards. Such errata shall be used on the date posted.

The Committee Pages can be found at https://cstools.asme.org/. There is an option available to automatically receive an e-mail notification when errata are posted to a particular code or standard. This option can be found on the appropriate Committee Page after selecting “Errata” in the “Publication Information” section.

ASME is the registered trademark of The American Society of Mechanical Engineers.

This code or standard was developed under procedures accredited as meeting the criteria for American National Standards. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.

ASME does not “approve,” “rate,” or “endorse” any item, construction, proprietary device, or activity.

ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assumes any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.

Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.

ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.

No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,

without the prior written permission of the publisher.

The American Society of Mechanical Engineers Two Park Avenue, New York, NY 10016-5990

Copyright © 2013 by

THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS

All rights reserved Printed in U.S.A.

CONTENTS

Foreword iv

Committee Roster vi

Correspondence With the B16 Committee vii

Summary of Changes viii

1. Scope 1

2. General 1

3. Pressure Rating 1

4. Size 1

5. Marking 1

6. Material 1

7. Dimensions 1

8. Threading 2

9. Hydrostatic Test 2

Tables

1. General Dimensions — Cast Copper Alloy Fittings for Flared Copper Tubes 3

2. Thread Specifications: External Threads on Fittings — Class 2A 4

3. Thread Specifications: Internal Threads on Nuts — Class 2B 4

iii

FOREWORD

The development of a standard for brass fittings for flared copper water tubes was initiated by a subcommittee of the Copper Tube and Fitting Manufacturers Standardization Committee in 1929. When a general agreement had been reached, the draft of the proposed standard was submitted to Sectional Committee A40 on Minimum Requirements for Plumbing and Standardization of Plumbing Equipment, of the American Standards Association (ASA). Sectional Committee A40 was jointly sponsored by the American Society of Sanitary Engineering and The American Society of Mechanical Engineers (ASME).

Final ASA approval and designation as an American Standard, ASA A40.2-1936, was granted January 20, 1936.

The Standard remained unchanged and without reaffirmation until 1955 when this activity was transferred from Sectional Committee A40 to Sectional Committee B16 on Standardization of Pipe Flanges and Fittings, under the sponsorship of ASME, the Mechanical Contractors Association of America, Inc., and the Manufacturers Standardization Society of the Valve and Fittings Industry.

Subcommittee No. 9 B16 on Solder-Joint Fittings was instructed to develop a revised standard. The revised draft of this Standard was submitted to industry for criticism and comment. The final draft was approved by Sectional Committee B16 and its sponsors by letter ballot.

ASA approval and designation as ASA B16.26-1958 was granted on February 12, 1958. Beginning in 1965, consideration was given to reviewing the Standard in light of progress made in the production of these fittings. Subcommittee No. 9 completed its work by recommending the updating of referenced standards and thread specifications and including additional material. Following approval by the USA Standards Committee and Sponsors, the revision was approved by the new USA Standards Institute on April 21, 1967.

In 1982, American National Standards Committee B16 was reorganized as an ASME Committee operating under procedures accredited by the American National Standards Institute (ANSI). In the 1988 edition, metric units were omitted, and references to other standards were updated. Following approval by the B16 Main Committee and the ASME Supervisory Board, and after public review, the Standard was approved as an American National Standard by ANSI on August 23, 1988.

In the 2006 edition, metric units became the primary reference units while U.S. Customary units were maintained in either parenthetical or separate forms. SI values were positioned in the main text; U.S. Customary values were positioned in Mandatory Appendix I. The Scope was clarified, and a section on hydrostatic testing was added, along with a quality assurance recom- mendation in Nonmandatory Appendix B. Additional information concerning the design of the tube flare was also incorporated, in answer to user requests for such information, and was reported in Nonmandatory Appendix A. Following approval by the B16 Main Committee and the ASME Supervisory Board, and after public review, the Standard was approved as an American National Standard by ANSI on May 23, 2006.

In the 2011 edition, references to ASME standards were revised to no longer list specific edition years; the latest edition of ASME publications applies unless stated otherwise. Materials manufactured to other editions of the referenced ASTM standards have been permitted to be used to manufacture fittings meeting the requirements of this Standard as long as the fitting manufacturer verifies the material meets the requirements of the referenced edition. Following approval by the Standards Committee and the ASME Board on PTCS, the revision to the 2006 edition was approved as an American National Standard by ANSI on August 9, 2011 with the new designation ASME B16.26-2011.

In this 2013 edition, provisions have been included to recognize low lead alloys to comply with the U.S. Safe Drinking Water Act, which will be effective January 2014. Following approval by the ASME B16 Standards Committee, approval as an American National Standard was given by ANSI on July 29, 2013, with the new designation ASME B16.26-2013.

iv

Requests for interpretations or suggestions for revisions should be sent to the Secretary, B16 Committee, The American Society of Mechanical Engineers, Two Park Avenue, New York, NY 10016-5990.

v

ASME B16 COMMITTEE

Standardization of Valves, Flanges, Fittings, and Gaskets

(The following is the roster of the Committee at the time of approval of this Standard.)

STANDARDS COMMITTEE OFFICERS

W. B. Bedesem, Chair

G. A. Jolly, Vice Chair

C. E. O’Brien, Secretary

A. Appleton, Alloy Stainless Products Co., Inc.

R. W. Barnes, ANRIC Enterprises, Inc.

W. B. Bedesem, Consultant

STANDARDS COMMITTEE PERSONNEL

M. Katcher, Haynes International

W. N. McLean, B&L Engineering

T. A. McMahon, Emerson Process Management

R. M. Bojarczuk, ExxonMobil Research & Engineering Co.

A. M. Cheta, Shell Exploration and Production Co.

M. A. Clark, NIBCO, Inc.

G. A. Cuccio, Capitol Manufacturing Co.

1. E. Davila, Crane Energy

2. R. Frikken, Becht Engineering Co.

R. B. Hai, RBH Associates

K. A. Hettler, U.S. Coast Guard

G. A. Jolly, Vogt Valves/Flowserve Corp.

M. L. Nayyar, NICE

C. E. O’Brien, The American Society of Mechanical Engineers

W. H. Patrick, Dow Chemical Co.

D. Rahoi, Consultant

R. A. Schmidt, Canadoil

H. R. Sonderegger, Fluoroseal, Inc.

W. M. Stephan, Flexitallic LP

F. R. Volgstadt, Volgstadt & Associates, Inc.

D. A. Williams, Southern Co. Generation

SUBCOMMITTEE J — COPPER AND COPPER ALLOY FLANGES, FLANGED FITTINGS, AND SOLDER JOINT FITTINGS

M. A. Clark, Chair, NIBCO, Inc.

C. R. Ramcharran, Secretary, The American Society of Mechanical Engineers

J. A. Ballanco, JB Engineering & Code Consulting PC

S. L. Cavanaugh, Cavanaugh Consulting

A. Ciechanowski, NSF International

D. R. Frikken, Becht Engineering Co.

M. Gillespie, Viega LLC

T. L. Jamison, Jamison Engineering

A. G. Kireta, Jr., Copper Development Association, Inc.

A. A. Knapp, A. Knapp & Associates

S. Robinett, Consultant

1. Shingleton, Viega LLC

2. Morgan, Alternate, Viega LLC

C. Stout, Mueller Industries

C. Mueller, Alternate, Mueller Industries

vi

CORRESPONDENCE WITH THE B16 COMMITTEE

General. ASME Standards are developed and maintained with the intent to represent the consensus of concerned interests. As such, users of this Standard may interact with the Committee by requesting interpretations, proposing revisions, and attending Committee meetings. Corre- spondence should be addressed to:

Secretary, B16 Standards Committee

The American Society of Mechanical Engineers Two Park Avenue

New York, NY 10016-5990

As an alternative, inquiries may be submitted via email to: SecretaryB16@asme.org.

Proposing Revisions. Revisions are made periodically to the Standard to incorporate changes that appear necessary or desirable, as demonstrated by the experience gained from the application of the Standard. Approved revisions will be published periodically.

The Committee welcomes proposals for revisions to this Standard. Such proposals should be as specific as possible, citing the paragraph number(s), the proposed wording, and a detailed description of the reasons for the proposal, including any pertinent documentation.

Proposing a Case. Cases may be issued for the purpose of providing alternative rules when justified, to permit early implementation of an approved revision when the need is urgent, or to provide rules not covered by existing provisions. Cases are effective immediately upon ASME approval and shall be posted on the ASME Committee Web page.

Requests for Cases shall provide a Statement of Need and Background Information. The request should identify the Standard, the paragraph, figure or table number(s), and be written as a Question and Reply in the same format as existing Cases. Requests for Cases should also indicate the applicable edition(s) of the Standard to which the proposed Case applies.

Interpretations. Upon request, the B16 Committee will render an interpretation of any require- ment of the Standard. Interpretations can only be rendered in response to a written request sent to the Secretary of the B16 Standards Committee.

The request for interpretation should be clear and unambiguous. It is further recommended that the inquirer submit his/her request in the following format:

Subject: Cite the applicable paragraph number(s) and the topic of the inquiry.

Edition: Cite the applicable edition of the Standard for which the interpretation is being requested.

Question: Phrase the question as a request for an interpretation of a specific requirement suitable for general understanding and use, not as a request for an approval of a proprietary design or situation. The inquirer may also include any plans or drawings that are necessary to explain the question; however, they should not contain proprietary names or information.

Requests that are not in this format will be rewritten in this format by the Committee prior to being answered, which may inadvertently change the intent of the original request.

ASME procedures provide for reconsideration of any interpretation when or if additional information that might affect an interpretation is available. Further, persons aggrieved by an interpretation may appeal to the cognizant ASME Committee or Subcommittee. ASME does not “approve,” “certify,” “rate,” or “endorse” any item, construction, proprietary device, or activity. Attending Committee Meetings. The B16 Standards Committee regularly holds meetings, which are open to the public. Persons wishing to attend any meeting should contact the Secretary of

the B16 Standards Committee.

vii

ASME B16.26-2013 SUMMARY OF CHANGES

Following approval by the B16 Committee and ASME, and after public review, ASME B16.26-2013 was approved by the American National Standards Institute on July 29, 2013.

ASME B16.26-2013 consists of editorial changes, revisions, and corrections identified by a margin note, (13), placed next to the affected area.

viii

ASME B16.26-2013

CAST COPPER ALLOY FITTINGS FOR FLARED COPPER TUBES

1. SCOPE

   This Standard establishes specifications for cast cop- per alloy fittings and nuts used with flared seamless copper tube conforming to ASTM B88 (water and gen- eral plumbing systems). Included are requirements for the following:

   1. pressure rating

   2. size

   3. marking

   4. material

   5. dimensions

   6. threading

   7. hydrostatic testing




2. GENERAL

1. References

   Codes, standards, and specifications containing provi- sions to the extent referenced herein constitute require- ments of this Standard. These reference documents are listed in Mandatory Appendix II.

2. Convention

   For determining conformance with this Standard, the convention for fixing significant digits where limits (maximum and minimum values) are specified shall be as defined in ASTM E29. This requires that an observed or calculated value be rounded off to the nearest unit in the last right-hand digit used for expressing the limit. Decimal values and tolerances do not imply a particular method of measurement.

3. Relevant Units

   This Standard states values in both SI (Metric) and

   U.S. Customary units. These systems of units are to be regarded separately as standard. Within the text, the

   U.S. Customary units are shown in parentheses or in separate tables that appear in Mandatory Appendix I. The values stated in each system are not exact equiva- lents; therefore, it is required that each system of units be used independently of the other. Combining values from the two systems constitutes nonconformance with the Standard.

4. Quality Systems

   Requirements relating to the product manufacturer’s quality system programs are described in Nonmandatory Appendix B.

5. Service Conditions

Criteria for selection of materials suitable for particu- lar fluid service are not within the scope of this Standard.

1. PRESSURE RATING

   The fittings covered by this Standard are designed for a maximum cold-water service pressure of 1 200 kPa (175 psig).




2. SIZE

   The sizes of the fittings shown in Table 1 (Table I-1) correspond to standard water tube size as defined in ASTM B88.




3. MARKING

   Each fitting shall be marked with the manufacturer’s name or trademark and other applicable markings as required by MSS SP-25. Marking of fittings less than nominal size 1⁄2 is optional.




4. MATERIAL

   1. Castings intended for use in applications up to 400°F (204°C) shall be of a copper alloy produced to meet

      1. the requirement of ASTM B62 Alloy C83600 or

      2. the chemical and tensile requirements of ASTM B584 Alloy C83800 or C84400 and in all other respects comply with the requirements of ASTM B62

   2. Castings intended for use in potable water appli- cations, up to 200°F (93°C), shall be low lead (0.25% or less) and shall be

      1. of a copper alloy produced to meet the require- ments of ASTM B584 Alloy C87850 or C89833 or

      2. of other cast copper alloys, provided the fittings produced meet mechanical and corrosion-resistant prop- erties needed for potable water application




5. DIMENSIONS

7.1 Fitting and Nut

The dimensions and tolerances of fittings and nuts shall be as shown in Table 1 (Table I-1). Design of the sealing surfaces of the fitting and nut shall be at the discretion of the manufacturer.

(13)

1
