ASME Y14.1-2020

DRAWING SHEET SIZE AND FORMAT

1. GENERAL

   1. Scope

      This Standard defines sheet sizes and formats for engi- neering drawings. Both metric and decimal-inch sheet sizes and formats are included. For engineering product definition preparation and practices, see ASME Y14.100.




   2. Purpose

      Standardization of drawing sheet sizes and uniform location of format features on drawing forms provides definite advantages in readability, handling, filing, and reproduction of engineering drawings. When using drawing sheets made by other organizations, an advan- tage is gained when like items of information are in the same location on all drawing sheets, and when unifor- mity of form and language is applied in making informa- tion entries. Revision information and dates are of particular importance to users of drawings and should be located and expressed uniformly on all engineering drawings.

      The widespread use and exchange of reduced-size copies of drawing sheets, both within and between organ- izations, emphasizes the importance of standardizing drawing sheet size and format.




   3. ASME Y14 Series Conventions

      The conventions in paras. 1.3.1 through 1.3.9 are used in this and other ASME Y14 standards.

      1. Mandatory, Recommended, Guidance, and Optional Words

         1. The word “shall” establishes a requirement.

         2. The word “will” establishes a declaration of purpose on the part of the design activity.

         3. The word “should” establishes a recommended practice.

         4. The word “may” establishes an allowed practice.

         5. The words “typical,” “example,” “for reference,” and the Latin abbreviation “e.g.” indicate suggestions given for guidance only.

         6. The word “or” used in conjunction with a require- ment or a recommended practice indicates that there are two or more options for complying with the stated requirement or practice.

         7. The phrase “unless otherwise specified” or “UOS” shall be used to indicate a default requirement. The phrase is used when the default is a generally applied require- ment and an exception may be provided by another docu- ment or requirement.

      2. Cross-Reference of Standards. Cross-reference of standards in text with or without a date following the standard designator shall be interpreted as follows:

         1. Reference to other ASME Y14 standards in the text without a date following the standard designator indicates that the issue of the standard identified in the References section (section 2) shall be used to meet the requirement.

         2. Reference to other ASME Y14 standards in the text with a date following the standard designator indicates that only that issue of the standard shall be used to meet the requirement.

      3. Invocation of Referenced Standards. The following examples define the invocation of a standard when specified in the References section (section 2) and referenced in the text of this Standard:

         1. When a referenced standard is cited in the text with no limitations to a specific subject or paragraph(s) of the standard, the entire standard is invoked. For example, “dimensioning and tolerancing shall be in accordance with ASME Y14.5” is invoking the complete standard because the subject of the standard is dimensioning and tolerancing and no specific subject or paragraph(s) within the standard are invoked.

         2. When a referenced standard is cited in the text with limitations to a specific subject or paragraph(s) of the standard, only the paragraph(s) on that subject is invoked. For example, “assign part or identifying numbers in accordance with ASME Y14.100” is invoking only the paragraph(s) on part or identifying numbers because the subject of the standard is engineering drawing practices and part or identifying numbers are a specific subject within the standard.

         3. When a referenced standard is cited in the text without an invoking statement, such as “in accordance with,” the standard is invoked for guidance only. For example, “for gaging principles, see ASME Y14.43” is only for guidance and no portion of the standard is invoked.

      4. Parentheses Following a Definition. When a definition is followed by a standard referenced in parenth- eses, the standard referenced in parentheses is the source for the definition.

1
