New Reduced price! ASME Y14.1M-2012 View larger

ASME Y14.1M-2012

M00052375

New product

ASME Y14.1M-2012 Metric Drawing Sheet Size and Format

standard by ASME International, 03/15/2013

Full Description

This Standard defines metric sheet sizes and formatsfor engineering drawings. Decimal inch sheet sizes andformat are defined in ASME Y14.1. For engineeringdrawing preparation and practices, see ASME Y14.100.

More details

In stock

$26.84

-56%

$61.00

More info

000728U001


Metric Drawing Sheet Size and Format

Engineering Drawing and Related Documentation Practices


AN A MERICAN NA TIONAL S T AND ARD

ASME Y14.1M



ADOPTION NOTICE


ASME Y14.1M, “Metric Drawing Sheet Size and Format,” was adopted on 10 March 1995 for use by the Department of Defense (DoD). Proposed changes by DoD activities must be submitted to the DoD Adopting Activity: Commander, U.S. ARDEC, ATTN: RDAR-QES-E, Picatinny Arsenal, NJ 07806-5000 or emailed to usarmy.picatinny.ardec.list.ardec-stdzn-branch@mail.mil. Copies of this document may be purchased from the American Society of Mechanical Engineers, Two Park Avenue, New York, New York, United States, 10016. https://www.asme.org.


Custodians: Adopting Activity:

Army — AR Army — AR

Navy — SA (Project DRPR-2013-001)

Air Force — 16 DLA — DH


Review Activities:

Army — AV, CR, MI, PT, TE, TM Navy — AS, CG, CH, MC, NP

Air Force — 04, 13, 99 DLA — IS

OSD — SE

Other — CM, MP, DC2, NS


NOTE: The activities listed above were interested in this document as of the date of this document. Since organizations and responsibilities can change, you should verify the currency of the information above using the ASSIST Online database at https://assist.dla.mil.


AMSC N/A AREA DRPR

DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.


ASME Y14.1M-2012

[Revision of ASME Y14.1M-2005 (R2010)]

ASME Y14.1M-2012

[Revision of ASME Y14.1M-2005 (R2010)]


Metric Drawing Sheet Size and Format



Engineering Drawing and Related Documentation Practices


AN AMERICAN NA TIONAL S T AND ARD



Two Park Avenue • New York, NY • 10016 USA


Date of Issuance: March 15, 2013


This Standard will be revised when the Society approves the issuance of a new edition.


Errata to codes and standards may be posted on the ASME Web site under the Committee Pages to provide corrections to incorrectly published items, or to correct typographical or grammatical errors in codes and standards. Such errata shall be used on the date posted.


The Committee Pages can be found at https://cstools.asme.org/. There is an option available to automatically receive an e-mail notification when errata are posted to a particular code or standard. This option can be found on the appropriate Committee Page after selecting “Errata” in the “Publication Information” section.


ASME is the registered trademark of The American Society of Mechanical Engineers.


This code or standard was developed under procedures accredited as meeting the criteria for American National Standards. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.

ASME does not “approve,” “rate,” or “endorse” any item, construction, proprietary device, or activity.

ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assumes any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.

Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.

ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.


No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,

without the prior written permission of the publisher.


The American Society of Mechanical Engineers Two Park Avenue, New York, NY 10016-5990


Copyright © 2013 by

THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS

All rights reserved Printed in U.S.A.


CONTENTS

Foreword iv

Committee Roster v

Correspondence With the Y14 Committee vi


1

General .........................................................................

1

2

References ......................................................................

2

3

Terms and Definitions ............................................................

2

4

Drawing Sheet Sizes .............................................................

4

5

Formats .........................................................................

4

6

Title Blocks......................................................................

5

7

Revision History Block ...........................................................

5

8

Revision Status of Sheets Block ..................................................

6

9

Associated Lists .................................................................

6

10

Additional Data Blocks ...........................................................

6

11

Additional Drawing Number Blocks................................................

6

Figures

4-1

Basic Sheet Size Formats, A0 Through A4 Sizes ..................................

7

4-2

Elongated Sheet Size Formats, A1.0, A2.1, A2.0, A3.2, A3.1, and A3.0 Sizes .......

8

4-3

System Size Overview ..........................................................

9

5-1

Title Block for A2, A3, and A4 Sizes .............................................

9

5-2

Title Block for A0 and A1 Sizes .................................................

10

5-3

Continuation Sheet Title Block for A2, A3, and A4 Sizes .........................

10

5-4

Continuation Sheet Title Block for A0 and A1 Sizes ..............................

11

5-5

Microfilm Arrowheads ..........................................................

11

5-6

Microfilm Identification Block ...................................................

12

7-1

Revision History Block .........................................................

12

8-1

Revision of Status of Sheets Block ...............................................

12

10-1

Tolerance and Projection Blocks .................................................

13

10-2

Application Block ..............................................................

13

11-1

Margin Drawing Number Block .................................................

14

Tables

4-1

Basic Sheet Sizes ................................................................

15

4-2

Elongated Sheet Sizes ...........................................................

15


iii


FOREWORD


This Standard establishes a series of recommended metric drawing sizes and the basic format for engineering drawings. It provides a basis for uniformity in engineering drawing size and format that industry and government can utilize. It is not the intent of this Standard to prevent individual organizations from designing specific formats that meet their individual needs, but rather to provide common engineering delineation standards to aid the interchange of drawings between industry, government, and other users.

This Standard is a revision of ASME Y14.1M-2005, Metric Drawing Sheet Size and Format. It has been prepared in alignment with the United States Omnibus Trade and Competitiveness Act of 1988, Section 5164, Metric Usage.

This Standard utilizes International Standard ISO 5457 as the basis for recommended metric engineering drawing size and format.

This Standard has been developed to lend itself with the least amount of variation from the presently recognized International Standard, and has been structured to support the United States Department of Defense (DoD) metrication policy and objectives.

Work on the revision of this Standard began in October 2010 in Tucson, Arizona by the members of Subcommittee 1.

The following is a summary of the significant changes that were incorporated into this revision:

  1. Added ASME Y14 Series Conventions section.

  2. Revised various definitions to match those listed in ASME Y14.100.

  3. Added definition for field of drawing and updated Figs. 4-1 and 4-2.

  4. Clarified para. 4.2 (formerly para. 2.2) regarding how the lengths of elongated sheets are determined.

  5. Expanded zoning practices to address continuous and repetitive zoning methods.

  6. Microfilming practices are now listed as optional.

  7. Introduced (design activity identification) DAI, replacing CAGE Code.

  8. Addressed revision status of sheet block for multiple-sheet drawings with maintained at the same revision level.

  9. Made the location of the angle of projection block optional (within or adjacent to the title block).

  10. Changed reference to ASME Y14.5 in Fig. 10-1.

    Where this Standard is specified as a requirement in a document, its defined requirements are assumed to be consistent with the needs of the user. Therefore, each user provides appropriate interpretations, as the need arises, consistent with the environment in which it is applied.

    The successful revision of this Standard is attributed to the subcommittee members and their respective companies, and the Department and Agencies of the U.S. Government.

    Suggestions for the improvement of this Standard are welcome. They should be sent to The American Society of Mechanical Engineers, Attn: Secretary, Y14 Standards Committee, Two Park Avenue, New York, NY 10016-5990.

    This revision was approved by American National Standard Institute (ANSI) as an American National Standard on December 19, 2012.


    iv


    ASME Y14 Committee Engineering Drawing and Related Documentation Practices

    (The following is the roster of the Committee at the time of approval of this Standard.)


    STANDARDS COMMITTEE OFFICERS


    F. Bakos, Jr., Chair

    W. A. Kaba, Vice Chair

    F. Constantino, Secretary


    STANDARDS COMMITTEE PERSONNEL


    1. R. Anderson, Dimensional Control Systems, Inc.

F. Bakos, Jr., Consultant

J. V. Burleigh, Consultant

F. Constantino, The American Society of Mechanical Engineers

D. E. Day, TEC_EASE, Inc.

K. Dobert, Siemens

C. W. Ferguson, WM Education Services

B. A. Harding, Purdue University

D. H. Honsinger, Consultant

W. A. Kaba, Sprint AeroSystems, Inc.

A. Krulikowski, Effective Training

E. McCarthy, Ratheon Co.

P. J. McCuistion, Ohio University

J. D. Meadows, James D. Meadows & Associates, Inc.

H. W. Oakes, United States Air Force (Peerless Technologies Corp.)

N. H. Smith, Sprint AeroSystems, Inc.

M. J. Stahl, Caterpillar, Inc.

R. G. Wilhelm, University of North Carolina

B. A. Wilson, The Boeing Co.


SUBCOMMITTEE 1 — DRAWING SHEET SIZE AND FORMAT


J. B. Hoskins, Chair, The Boeing Co.

J. V. Burleigh, Consultant

B. A. Harding, Purdue University

G. M. Nelson, Consultant

R. H. Settle, Naval Surface Warfare Center, Dahlgren Division

N. Stern, United States Army

M. W. Woodworth, Retired, U.S. Department of the Air Force


v


CORRESPONDENCE WITH THE Y14 COMMITTEE


General. ASME Standards are developed and maintained with the intent to represent the consensus of concerned interests. As such, users of this Standard may interact with the Committee by requesting interpretations, proposing revisions, and attending Committee meetings. Corre- spondence should be addressed to:

Secretary, Y14 Standards Committee

The American Society of Mechanical Engineers Two Park Avenue

New York, NY 10016-5990

https://go.asme.org/inquiry

Proposing Revisions. Revisions are made periodically to the Standard to incorporate changes that appear necessary or desirable, as demonstrated by the experience gained from the application of the Standard. Approved revisions will be published periodically.

The Committee welcomes proposals for revisions to this Standard. Such proposals should be as specific as possible, citing the paragraph number(s), the proposed wording, and a detailed description of the reasons for the proposal, including any pertinent documentation.

Attending Committee Meetings. The Y14 Standards Committee regularly holds meetings that are open to the public. Persons wishing to attend any meeting should contact the Secretary of the Y14 Standards Committee.


vi

ASME Y14.1M-2012


ENGINEERING DRAWING AND RELATED DOCUMENTATION PRACTICES


METRIC DRAWING SHEET SIZE AND FORMAT



  1. GENERAL


    1. Scope

      This Standard defines metric sheet sizes and formats for engineering drawings. Decimal inch sheet sizes and format are defined in ASME Y14.1. For engineering drawing preparation and practices, see ASME Y14.100.


    2. Purpose

      Standardization of drawing sheet sizes and the uni- form location of format features on drawing forms pro- vides definite advantages in readability, handling, filing, and reproduction. In using drawing sheets made by other organizations, an advantage is gained when like items of information are in the same location on all drawing sheets, and when uniformity of form and lan- guage is applied in making information entries. Revision information and dates are of particular importance to users of drawings and should be located and expressed uniformly on all engineering drawings.

      The widespread use and exchange of reduced-size copies of drawing sheets both within and between orga- nizations emphasizes the importance of standardization of drawing sheet size and format.


    3. ASME Y14 Series Conventions

      The following conventions are guidance used in this and other ASME Y14 series standards.


      1. Mandatory, Nonmandatory, Guidance, and Optional Words

        1. The word “shall” establishes a mandatory requirement.

        2. The word “will” establishes an intended, manda- tory requirement.

        3. The words “should” and “may” establish a non- mandatory practice.

        4. The words “typical,” “example,” “for reference,” or the Latin abbreviation “e.g.” indicate suggestions given for guidance only.

        5. When the text of this Standard has an “or” state- ment, it indicates that there are two or more options on how to comply with the stated requirement.


      2. Cross-Reference of Standards. Cross-reference of standards in text with or without a date following the standard identity is interpreted as follows:

        1. Reference to other ASME Y14 series standards in the text without a date following the standard identity indicates the issue of the standard as identified in the Reference section shall be used to meet the requirement.

        2. Reference to other ASME Y14 series standards in the text with a date following the standard identity indicates that only that issue of the standard shall be used to meet the requirement.

      3. Invocation of Referenced Standards. The fol- lowing examples define the invocation of a standard when specified in the References section and referenced in the text of this Standard:

        1. When the text states “dimensioning and toleranc- ing shall be in accordance with ASME Y14.5-2009,” with no limitations to a specific subject or area of the Standard, the entire text of ASME Y14.5-2009 is invoked.

        2. When the text states “assign part or identifying numbers in accordance with ASME Y14.100-20XX,” only the paragraph requirements on part or identifying num- ber assignment in ASME Y14.100-20XX are invoked.

        3. When the text states “for gaging principles, see ASME Y14.43,” the text provides a cross-reference of where to find guidance for dimensioning and toleranc- ing for gages and fixtures, and no portion of ASME Y14.43 is invoked.

      4. Parentheses Following a Definition. When a definition is followed by a standard referenced in paren- theses, the standard referenced in parentheses is the controlling standard for the definition.

      5. Notes. Notes depicted in this Standard in ALL UPPERCASE letters are intended to reflect actual drawing entries. Notes depicted in initial Uppercase or lowercase letters are to be considered supporting data to the contents of this Standard and are not intended for literal entry on drawings. A statement requiring the addition of a note with the qualifier “such as” is a requirement to add a note, and the content of the text is allowed to vary to suit the application.

      6. Acronyms and Abbreviations. Acronyms and abbreviations are spelled out the first time used in this


1
