New Reduced price! ASME BTH-1-2017 View larger

ASME BTH-1-2017

M00052391

New product

ASME BTH-1-2017 Design of Below-the-Hook Lifting Devices

standard by ASME International, 02/10/2017

Full Description

This Standard provides minimum structural andmechanical design and electrical component selectioncriteria for ASME B30.20, Below-the-Hook LiftingDevices.

The provisions in this Standard apply to the designor modification of below-the-hook lifting devices. Compliancewith requirements and criteria that may beunique to specialized industries and environments isoutside the scope of this Standard.

Lifting devices designed to this Standard shall complywith ASME B30.20, Below-the-Hook Lifting Devices.ASME B30.20 includes provisions that apply to themarking, construction, installation, inspection, testing,maintenance, and operation of below-the-hook liftingdevices.

The provisions defined in this Standard address themost common and broadly applicable aspects of thedesign of below-the-hook lifting devices. A qualifiedperson shall determine the appropriate methods to beused to address design issues that are not explicitlycovered in the Standard so as to provide design factorsand/or performance consistent with the intent of thisStandard.

More details

In stock

$27.72

-56%

$63.00

More info

007401U001


Design of

Below-the-Hook Lifting Devices


AN A MERICAN NA TIONAL S T AND ARD



ASME BTH-1–2017

(Revision of ASME BTH-1–2014)

ASME BTH-1–2017

(Revision of ASME BTH-1–2014)


Design of Below-the-Hook Lifting Devices



AN AMERICAN NA TIONAL S T AND ARD



Two Park Avenue • New York, NY • 10016 USA


Date of Issuance: February 10, 2017


The next edition of this Standard is scheduled for publication in 2020. This Standard will become effective 1 year after the Date of Issuance.


ASME issues written replies to inquiries concerning interpretations of technical aspects of this Standard. Interpretations are published on the ASME Web site under the Committee Pages at https://cstools.asme.org/ as they are issued.


Errata to codes and standards may be posted on the ASME Web site under the Committee Pages to provide corrections to incorrectly published items, or to correct typographical or grammatical errors in codes and standards. Such errata shall be used on the date posted.


The Committee Pages can be found at https://cstools.asme.org/. There is an option available to automatically receive an e-mail notification when errata are posted to a particular code or standard. This option can be found on the appropriate Committee Page after selecting “Errata” in the “Publication Information” section.


ASME is the registered trademark of The American Society of Mechanical Engineers.


This code or standard was developed under procedures accredited as meeting the criteria for American National Standards. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.

ASME does not “approve,” “rate,” or “endorse” any item, construction, proprietary device, or activity.

ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assumes any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.

Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.

ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.


No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,

without the prior written permission of the publisher.


The American Society of Mechanical Engineers Two Park Avenue, New York, NY 10016-5990


Copyright © 2017 by

THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS

All rights reserved Printed in U.S.A.


CONTENTS

Foreword v

Committee Roster vi

Correspondence With the BTH Committee vii

Summary of Changes ix


Chapter 1

Scope, Definitions, and References...........................................

1

1-1

Purpose ...................................................................

1

1-2

Scope .....................................................................

1

1-3

New and Existing Devices .................................................

1

1-4

General Requirements .....................................................

1

1-5

Definitions ................................................................

2

1-6

Symbols ...................................................................

6

1-7

References .................................................................

9

Chapter 2

Lifter Classifications.........................................................

11

2-1

General ...................................................................

11

2-2

Design Category ...........................................................

11

2-3

Service Class ..............................................................

11

Chapter 3

Structural Design ...........................................................

12

3-1

General ...................................................................

12

3-2

Member Design ...........................................................

12

3-3

Connection Design ........................................................

17

3-4

Fatigue Design ............................................................

20

3-5

Other Design Considerations ...............................................

22

Chapter 4

Mechanical Design ..........................................................

35

4-1

General ...................................................................

35

4-2

Sheaves ...................................................................

35

4-3

Wire Rope .................................................................

36

4-4

Drive Systems .............................................................

36

4-5

Gearing ...................................................................

36

4-6

Bearings ...................................................................

38

4-7

Shafting ...................................................................

39

4-8

Fasteners ..................................................................

40

4-9

Grip Support Force ........................................................

41

4-10

Vacuum Lifting Device Design .............................................

41

4-11

Fluid Power Systems ......................................................

42

Chapter 5

Electrical Components .......................................................

43

5-1

General ...................................................................

43

5-2

Electric Motors and Brakes .................................................

43

5-3

Operator Interface .........................................................

43

5-4

Controllers and Auxiliary Equipment .......................................

44

5-5

Grounding ................................................................

45

5-6

Power Disconnects .........................................................

45

5-7

Batteries ...................................................................

45

Chapter 6

Lifting Magnet Design.......................................................

46

6-1

Purpose ...................................................................

46

6-2

Design Requirements ......................................................

46

6-3

Selection and Design ......................................................

46


Figures

1-5.5-1


Magnetic Lifters ...........................................................


5

4-2.6-1

Sheave Dimensions ........................................................

35

4-2.7-1

Sheave Gap ................................................................

35

4-9.2-1

Illustration of Holding and Support Forces .................................

41

Tables

2-3-1

Service Class ..............................................................

11

3-2.2-1

Limiting Width–Thickness Ratios for Compression Elements ................

14

3-3.4.2-1

Minimum Effective Throat Thickness of Partial-Penetration Groove Welds .....

19

3-3.4.3-1

Minimum Sizes of Fillet Welds .............................................

20

3-4.3-1

Allowable Stress Ranges, ksi (MPa) .........................................

21

3-4.4-1

Fatigue Design Parameters .................................................

23

4-5.3-1

Strength Factors for Calculating Load Capacity (American Standard Tooth

Forms) ..................................................................

37

4-6.2-1

L10 Bearing Life ............................................................

38

4-7.5-1

Key Size Versus Shaft Diameter (ASME B17.1) ..............................

40

4-7.5-2

Key Size Versus Shaft Diameter (DIN 6885-1) ...............................

40

4-7.6.1-1

Fatigue Stress Amplification Factors ........................................

40

Nonmandatory Appendices

  1. Commentary for Chapter 1: Scope, Definitions, and References 49

  2. Commentary for Chapter 2: Lifter Classifications 53

  3. Commentary for Chapter 3: Structural Design 55

  4. Commentary for Chapter 4: Mechanical Design 64

  5. Commentary for Chapter 5: Electrical Components 67

  6. Commentary for Chapter 6: Lifting Magnet Design 69


FOREWORD


There have been many formal requests for interpretation of the limited structural design criteria stated within ASME B30.20, Below-the-Hook Lifting Devices, a safety standard. As a consequence, industry has for quite some time expressed a need for a comprehensive design standard for below-the-hook lifting devices that would complement the safety requirements of ASME B30.20. All editions of ASME B30.20 have included structural design criteria oriented toward the industrial manufacturing community requiring a minimum design factor of 3, based on the yield strength of the material; recent editions have also included design criteria for the fatigue failure mode. However, members of the construction community expressed the need for design criteria more suitable to their operating conditions, including a lower design factor, and the necessity to address other failure modes such as fracture, shear, and buckling, and design topics such as impact and fasteners.

A Design Task Group was created in 1997 to begin work on a design standard as a companion document to ASME B30.20. The ASME BTH Standards Committee on the Design of Below-the- Hook Lifting Devices was formed out of the Design Task Group and held its organizational meeting on December 5, 1999.

ASME BTH-1–2005, Design of Below-the-Hook Lifting Devices, contained five chapters: Scope and Definitions, Lifter Classifications, Structural Design, Mechanical Design, and Electrical Components. This Standard, intended for general industry and construction, set forth two design categories for lifters based on the magnitude and variation of loading, and operating and environ- mental conditions. The two design categories provided different design factors for determining allowable static stress limits. Five Service Classes based on load cycles were provided. The Service Class establishes allowable stress range values for lifter structural members and design parameters for mechanical components. ASME BTH-1–2005 was approved by the American National Stan- dards Institute (ANSI) on October 18, 2005.

ASME BTH-1–2008 incorporated editorial revisions and two new mechanical design sections for grip ratio and vacuum lifting device design. ASME BTH-1–2008 was approved by ANSI on September 17, 2008.

ASME BTH-1–2011 incorporated revisions throughout the Standard and the addition of a new mechanical design section for fluid power systems. ASME BTH-1–2011 was approved by ANSI on September 23, 2011.

ASME BTH-1–2014 incorporated into Chapter 4 a section on lifting magnets. Other technical revisions included new requirements for fluid pressure control and electrical system guarding. Along with these technical changes, the nonmandatory Commentary for each chapter was moved to its own respective Nonmandatory Appendix. ASME BTH-1–2014 was approved by ANSI on June 24, 2014.

This revision of ASME BTH-1 includes the addition of Chapter 6: Lifting Magnet Design, an accompanying Nonmandatory Appendix with commentary for the new chapter, and other revi- sions. Following the approval by the ASME BTH Standards Committee, ANSI approved this edition as an American National Standard, with the new designation ASME BTH-1–2017, on January 6, 2017.


ASME BTH STANDARDS COMMITTEE

Design of Below-the-Hook Lifting Devices

(The following is the roster of the Committee at the time of approval of this Standard.)


STANDARDS COMMITTEE OFFICERS


D. R. Verenski, Chair

D. Duerr, Vice Chair

G. Bolan, Secretary


STANDARDS COMMITTEE PERSONNEL


B. B. Bacon, Tennessee Valley Authority

G. Bolan, The American Society of Mechanical Engineers

G. A. Bond, Wood’s Powr-Grip Co., Inc.

P. W. Boyd, The Boeing Co.

D. Duerr, 2DM Associates, Inc.

J. D. Edmundson, Konecranes/P&H

A. Faris, Braun Intertec

M. T. Gaunce, SCHUNK

K. M. Jankowski, Walker Magnetics

T. C. Mackey, Washington River Protection Solutions

D. L. McCabe, Babcock and Wilcox Co.

B. A. Pickett, Systems Engineering and Forensic Services

D. T. Rebbin, Bradley Lifting Corp.

J. E. Rea, Alternate, Bradley Lifting Corp.

J. W. Rowland III, Consultant

R. S. Stemp, Lampson International, LLC

M. P. Zerba, Alternate, Lampson International, LLC

P. D. Sweeney, Riverside Engineering, LLC

D. R. Verenski, Hunter Lift Ltd.

T. J. Brookbank, Alternate, Hunter Lift Ltd.

T. D. Waterworth, ENERPAC

S. Barton, Contributing Member, Consultant


HONORARY MEMBERS


R. A. Dahlin, Walker Magnetics

  1. W. Downs, Jr., Downs Crane and Hoist Co.


    CORRESPONDENCE WITH THE BTH COMMITTEE


    General. ASME Standards are developed and maintained with the intent to represent the consensus of concerned interests. As such, users of this Standard may interact with the Committee by requesting interpretations, proposing revisions, and attending Committee meetings. Corre- spondence should be addressed to:

    Secretary, BTH Standards Committee

    The American Society of Mechanical Engineers Two Park Avenue

    New York, NY 10016-5990

    https://go.asme.org/Inquiry


    Proposing Revisions. Revisions are made periodically to the Standard to incorporate changes that appear necessary or desirable, as demonstrated by the experience gained from the application of the Standard. Approved revisions will be published periodically.

    The Committee welcomes proposals for revisions to this Standard. Such proposals should be as specific as possible, citing the paragraph number(s), the proposed wording, and a detailed description of the reasons for the proposal, including any pertinent documentation.

    Interpretations. Upon request, the BTH Standards Committee will render an interpretation of any requirement of the Standard. Interpretations can only be rendered in response to a written request sent to the Secretary of the BTH Standards Committee.

    Requests for interpretation should preferably be submitted through the online Interpretation Submittal Form. The form is accessible at https://go.asme.org/InterpretationRequest. Upon sub- mittal of the form, the Inquirer will receive an automatic e-mail confirming receipt.

    If the Inquirer is unable to use the online form, he/she may mail the request to the Secretary of the BTH Standards Committee at the above address. The request for an interpretation should be clear and unambiguous. It is further recommended that the Inquirer submit his/her request in the following format:


    Subject: Cite the applicable paragraph number(s) and the topic of the inquiry in one or two words.

    Edition: Cite the applicable edition of the Standard for which the interpreta- tion is being requested.

    Question: Phrase the question as a request for an interpretation of a specific requirement suitable for general understanding and use, not as a request for an approval of a proprietary design or situation. Please provide a condensed and precise question, composed in such a way that a “yes” or “no” reply is acceptable.

    Proposed Reply(ies): Provide a proposed reply(ies) in the form of “Yes” or “No,” with explanation as needed. If entering replies to more than one question, please number the questions and replies.

    Background Information: Provide the Committee with any background information that will assist the Committee in understanding the inquiry. The Inquirer may also include any plans or drawings that are necessary to explain the question; however, they should not contain proprietary names or information.


    Requests that are not in the format described above may be rewritten in the appropriate format by the Committee prior to being answered, which may inadvertently change the intent of the original request.

    ASME procedures provide for reconsideration of any interpretation when or if additional information that might affect an interpretation is available. Further, persons aggrieved by an interpretation may appeal to the cognizant ASME Committee or Subcommittee. ASME does not “approve,” “certify,” “rate,” or “endorse” any item, construction, proprietary device, or activity. Attending Committee Meetings. The BTH Standards Committee regularly holds meetings and/or telephone conferences that are open to the public. Persons wishing to attend any meeting

    and/or telephone conference should contact the Secretary of the BTH Standards Committee.


    ASME BTH-1–2017 SUMMARY OF CHANGES


    Following approval by the ASME BTH Standards Committee and ASME, and after public review, ASME BTH-1–2017 was approved by the American National Standards Institute on January 6, 2017.

    ASME BTH-1–2017 includes editorial changes, revisions, and corrections identified by a margin note, (17).


    Page

    2–5

    Location

    1-5.1

    Change

    (1) Definitions of applied load(s), dead load,

    load cycle, maximum stress, minimum

    stress, and rated load added

    1. Definitions of cycle, load; load(s), applied; load, dead; load, rated; rigging hardware; sling; stress, maximum; and stress, minimum deleted

    2. Definitions of shall and should and location where design factor is first used revised

1-5.3 (1) Definitions of equalizing sheave and

running sheave added

  1. Definitions of sheave, equalizing and

    sheave, running deleted

  2. Location where back-driving, L10 bearing life, and vacuum pad are first used revised

1-5.4 (1) Definitions of electrical power supply, electric motor, externally powered electromagnet, and master switch added

  1. Definitions of electromagnet, externally powered; motor, electric; power supply, electrical; and switch, master deleted

  2. Location where brake, control system, rectifier, and sensor(s) are first used revised

1-5.5 Added

Fig. 1-5.5-1 Added

6–10 1-6.1 (1) Units for a, Dp, and and nomenclature for hc, hp, My , Sxc, and Sxt added

  1. Nomenclature for Fr, Fyf, and Fyw

    deleted

  2. Nomenclature for ni revised

1-6.2 (1) Units for A and added

(2) Nomenclature for Su and Sy revised

1-6.3 Added

1-7 References updated


Page

Location

Change

11

2-2

Revised

2-2.3

Added
