ASME B18.29.2M-2005 (R2017) Helical Coil Screw Thread Inserts: Free Running and Screw Locking (Metric Series)

standard by ASME International, 02/06/2006

Full Description

This Standard delineates the dimensional, mechanical,and performance data for the metric series helicalcoil screw thread insert and threaded hole into whichit is installed. Appendices that describe insert selection,STI (screw thread insert) taps, insert installation, andremoval tooling are also included.

The inclusion of dimensional data in this Standard isnot intended to imply that all products described arestock sizes.

Product Details

Published: 02/06/2006 ISBN(s): 0791829731 ANSI: ANSI Approved Number of Pages: 28 File Size: 1 file , 900 KB
