New Reduced price! ASME B89.4.22-2004 (R2019) View larger

ASME B89.4.22-2004 (R2019)

M00052432

New product

ASME B89.4.22-2004 (R2019) Methods for Performance Evaluation of Articulated Arm Coordinate Measuring Machines (CMM)

standard by ASME International, 08/12/2005

Full Description

The scope of this Standard pertains to the performance evaluation of Articulated Arm Coordinate Measuring Machines (AACMMs). While any number of rotational joints can be evaluated, the Standard focuses on the more common configurations commercially available today and is limited to seven joints. The Standard addresses purely manual machines, so no motorized axes are addressed in the current document. While the application of this class of measuring machine continues to grow, at this point in time only contact probes are considered and optical noncontact probes are specifically excluded. This Standard establishes requirements and methods for specifying and testing the performance of AACMMs. In addition to clarifying the performance evaluation of AACMMs, this Standard seeks to facilitate performance comparisons among machines by unifying terminology, general machine classification, the treatment of environmental effects, and data analysis. This Standard attempts to define the simplest testing methods capable of yielding adequate results for most AACMMs and it is not intended to replace more complete tests that may be suitable for special applications.

More details

In stock

$22.00

-56%

$50.00

More info

B89-4-22-2004_archive-front.pdf


ASME B89.4.22-2004


Methods for Performance Evaluation of Articulated Arm Coordinate Measuring Machines


AN A MERICAN NA TIONAL S T AND ARD


ASME B89.4.22-2004

ASME B89.4.22-2004


Methods for Performance Evaluation of Articulated Arm Coordinate Measuring Machines


AN AMERICAN NATIONAL STANDARD



Three Park Avenue • New York, NY 10016


Date of Issuance: August 12, 2005


This Standard will be revised when the Society approves the issuance of a new edition. There will be no addenda issued to this edition.


ASME will issue written replies to inquiries concerning interpretation of technical aspects of this Standard.


ASME is the registered trademark of The American Society of Mechanical Engineers.


This code or standard was developed under procedures accredited as meeting the criteria for American National Stan- dards. The Standards Committee that approved the code or standard was balanced to assure that individuals from com- petent and concerned interests have had an opportunity to participate. The proposed code or standard was made avail- able for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.

ASME does not approve, rate, or endorse any item, construction, proprietary device, or activity.

ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringe- ment of any applicable letters patent, nor assume any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.

Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as gov- ernment or industry endorsement of this code or standard.

ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.


No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,

without the prior written permission of the publisher.


The American Society of Mechanical Engineers Three Park Avenue, New York, NY 10016-5990


Copyright © 2005 by

THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS

All rights reserved Printed in U.S.A.


CONTENTS

Foreword iv

Committee Roster v

Correspondence With the B89 Committee vi

Introduction 1

  1. Scope 1

  2. Definitions 1

  3. Environmental Specifications 5

  4. Environmental Tests 8

  5. Machine Performance 9

  6. Test Equipment 17

    Figures

    1. AACMM Classification Form 2

    2. Environmental Specification Form 3

    3. Performance Specification Form 4

    4. Typical Machine of the 2-1-2 Configuration, With a-b-d-e-f deg Rotation 5

    5. Typical Machine of the 2-2-2 Configuration, With a-b-c-d-e-f deg Rotation 5

    6. Typical Machine of the 2-1-3 Configuration, With a-b-d-e-f-g deg Rotation 5

    7. Typical Machine of the 2-2-3 Configuration, With a-b-c-d-e-f-g deg Rotation 5

    8. AACMM Mounted Vertically for Evaluation 7

    9. AACMM Mounted Horizontally for Use 7

    10. Mounting Stiffness Test Setup 9

    11. Three Default Locations of the Mounted Seat During the Single-Point

      Articulation Performance Test 11

    12. Isometric View of Default Articulations 11

    13. Default Five-Point Probe Pattern 12

    14. Octant Numbering Scheme 14

    15. Recommended Ball Bar Locations 15

    16. Volumetric Performance Test Results 17

Tables

  1. Diameter Deviations 10

  2. Single-Point Articulation Performance Test 13

  3. Recommended Artifact Positions 16

  4. Volumetric Performance Test Results 16

Nonmandatory Appendices


A

User’s Guide to ASME B89.4.22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

19

B

Thermal Environment Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

20

C

Seismic Vibration Verification Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

21

D

Electrical Power Monitoring Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

25

E

Interim Testing of AACMM Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

26

F

Ball Bar Design and Mounting Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . .

29

G

Kinematic, Conical Seat, and Chamfered Hole Design Recommendations . . . . . . . . . .

36

H

Determination of Thermal Error Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

39

I

Statistics Used in Specifying AACMM Performance Evaluation . . . . . . . . . . . . . . . . . .

42

J

Application of Decision Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

44

iii


FOREWORD


The ambiguity of articulated arm coordinate measuring machines (AACMM) specifications makes comparative evaluations of performance characteristics very difficult. Because of this and the increasing use of this class of measurement equipment, the ASME Standards Committee B89 elected to establish a USA industry standard applicable to these machines. At the October 1994 meeting, Project Team B89.4.22 was established to develop the Standard.

As far as possible, this Standard parallels ASME B89.4.1b-2001 for “conventional” coordinate measuring machines. An attempt has also been made to make the Standard compatible with ex- isting and emerging international standards.

This Standard addresses the performance evaluation of AACMM by supplying definitions and test procedures. These procedures should enable users to determine if an AACMM is appropri- ate for their specific requirements. It should also provide accurate comparison of machines from different suppliers and provide a determination of whether an AACMM meets contractual re- quirements without negotiations after the machine has been purchased.

The intent of this Standard is to specify the simplest methods that can be used for reasonable performance evaluation. It is recognized that a more complex evaluation may be appropriate for special applications. These methods, however, must be specified in adequate detail in the AACMM specification.

This Standard was approved by the American National Standards Institute on August 9, 2004.


iv


ASME B89 STANDARDS COMMITTEE

Dimensional Metrology

(The following is the roster of the Committee at the time of approval of this Standard.)


OFFICERS


B. Parry, Chair

D. Beutel, Vice Chair

M. Lo, Secretary


COMMITTEE PERSONNEL


D. Beutel, Caterpillar, Inc.

J. B. Bryan, Bryan Associates

T. Carpenter, USAF, Newark AF Base

T. Charlton, Jr., Charlton Associ8s

D. Christy, Mahr Federal

G. Hetland, International Institute of Geometric Dimensioning and Tolerancing

R. J. Hocken, University of North Carolina

M. Leibers, Professional Instruments Co.

M. Lo, The American Society of Mechanical Engineers

B. Parry, The Boeing Co.

S. D. Phillips, National Institute of Standards and Technology

J. Salsbury, Mitutoyo America Inc.

D. Swyt, National Institute of Standards and Technology

B. R. Taylor, Renishaw PLC


SUBCOMMITTEE 4 — COORDINATE MEASURING TECHNOLOGY


S. D. Phillips, Chair, National Institute of Standards and Technology

D. Beutel, Caterpillar, Inc.

T. Carpenter, U.S. Air Force, Newark AF Base

T. Charlton, Jr., Charlton Associ8s

T. D. Doiron, National Institute of Standards and Technology

J. L. Henry, Sheffield Measurement

R. B. Hook, Metcon

B. Parry, The Boeing Co.

R. C. Veale, National Institute of Standards and Technology

D. Wright, Renishaw PLC


PERSONNEL OF WORKING GROUP B89.4.22 — ARTICULATED ARM COORDINATE MEASURING MACHINES


B. Parry, Chair, The Boeing Co.

G. Caskey, University of North Carolina at Charlotte

S. Ilmrud, Romer CimCore Inc.

S. Raab, FARO Technologies

D. Wright, Renishaw PLC


SPECIAL ACKNOWLEDGEMENT


While not a member of the Project Team when the document was approved, we would like to acknowledge the work performed and significant contributions made by Michael O’Laughlin, while an employee of Romer Inc. Mike was the Secretary since the inception of the Project Team and, thanks to his diligent minutes, kept the remainder of us on track.


v


CORRESPONDENCE WITH THE B89 COMMITTEE


General. ASME Standards are developed and maintained with the intent to represent the con- sensus of concerned interests. As such, users of this Standard may interact with the Committee by requesting interpretations, proposing revisions, and attending Committee meetings. Corre- spondence should be addressed to:

Secretary, B89 Standards Committee

The American Society of Mechanical Engineers Three Park Avenue

New York, NY 10016-5990

Proposing Revisions. Revisions are made periodically to the Standard to incorporate changes that appear necessary or desirable, as demonstrated by the experience gained from the applica- tion of the Standard. Approved revisions will be published periodically.

The Committee welcomes proposals for revisions to this Standard. Such proposals should be as specific as possible, citing the paragraph number(s), the proposed wording, and a detailed de- scription of the reasons for the proposal, including any pertinent documentation.

Interpretations. Upon request, the B89 Committee will render an interpretation of any re- quirement of the Standard. Interpretations can only be rendered in response to a written request sent to the Secretary of the B89 Standards Committee.

The request for interpretation should be clear and unambiguous. It is further recommended that the inquirer submit his/her request in the following format:

Subject: Cite the applicable paragraph number(s) and provide a concise description. Edition: Cite the applicable edition of the Standard for which the interpretation is be-

ing requested.

Question: Phrase the question as a request for an interpretation of a specific require- ment suitable for general understanding and use, not as a request for an ap- proval of a proprietary design or situation.

Requests that are not in this format may be rewritten in the appropriate format by the Commit- tee prior to being answered, which may inadvertently change the intent of the original request.

ASME procedures provide for reconsideration of any interpretation when or if additional in- formation that might affect an interpretation is available. Further, persons aggrieved by an in- terpretation may appeal to the cognizant ASME committee or subcommittee. ASME does not “ap- prove,” “certify,” “rate,” or “endorse” any item, construction, proprietary device, or activity.

Attending Committee Meetings. The B89 Standards Committee regularly holds meetings that are open to the public. Persons wishing to attend any meeting should contact the Secretary of the B89 Standards Committee.


vi

ASME B89.4.22-2004


METHODS FOR PERFORMANCE EVALUATION OF ARTICULATED ARM COORDINATE MEASURING MACHINES


INTRODUCTION

The primary purpose of this Standard is to clarify the performance evaluation of articulated arm coordinate measuring machines (AACMMs). A secondary purpose is to facilitate performance comparisons between ma- chines. Definitions, environmental requirements, and test methods are specified. This Standard defines the test methods capable of yielding adequate results for the ma- jority of articulated arm coordinate measuring machines and is not intended to replace more complete tests that may be required for special applications.


  1. SCOPE

    The scope of this Standard pertains to the perform- ance evaluation of articulated arm coordinate measur- ing machines. While any number of rotational joints can be evaluated, the Standard focuses on the more com- mon configurations commercially available today and is limited to seven joints. The Standard addresses purely manual machines, so no motorized axes are addressed in the current document. While the application of this class of measuring machine continues to grow, at this point in time only contact probes are considered and op- tical noncontact probes are specifically excluded.

    This Standard establishes requirements and methods for specifying and testing the performance of AACMMs. In addition to clarifying the performance evaluation of AACMMs, this Standard seeks to facilitate performance comparisons among machines by unifying terminology, general machine classification, the treatment of envi- ronmental effects, and data analysis. This Standard at- tempts to define the simplest testing methods capable of yielding adequate results for most AACMMs and it is not intended to replace more complete tests that may be suitable for special applications.

    This Standard provides definitions of terms applica- ble to AACMMs. These definitions are separated into two parts. The first part is a glossary covering technical terms used throughout this and other ASME Standards. The second part defines a number of common machine classifications.

    The actual specification is subdivided into three sections: general machine classification, machine envi- ronmental requirements, and machine performance. Machine classification includes machine type, measure-

    ment ranges, and rotary axis encoder resolution. Envi- ronmental specification includes thermal response, elec- trical requirements, and vibration sensitivity. Machine performance specification includes effective diameter test, single-point articulation performance, and volu- metric performance tests.

    Within this Standard, performance values are reported as the maximum deviation, the range, and the standard deviation. This is done to bring the Standard more into line with existing national and international standards.

    In order to clarify the use of this Standard, a short guide on how to use it is included as Appendix A.

    Productivity is an important consideration in the se- lection of an articulated arm coordinate measuring ma- chine. There are numerous factors that affect the rela- tive productivity of measuring systems, which include variables attributable to both the measurement system and the workpiece. This Standard does not address methods to specify and evaluate productivity. Produc- tivity should be evaluated with respect to the expected use of the system, including such aspects as software, ergonomics, and the frequency of calibration.


    1. Contents and Specification Forms

      Any specification described as complying with this Stan- dard shall include, as a minimum, the following items:

      1. ) a machine classification form (see Fig. 1). If no classification is applicable, the actual configuration shall be described in equivalent detail.

      2. an environmental specification form (see Fig. 2).

      3. ) a performance specification form (see Fig. 3).


    2. Alternatives

      This Standard allows parts of the environmental test section to be deferred or bypassed and only the per- formance tests to be carried out. This alternative is ac- ceptable only if it is agreeable to both the user and the supplier, and if deferred as specified.


  2. DEFINITIONS

    1. Glossary

2.1.1 Terms. This glossary contains brief definitions of the majority of technical terms used in this Standard. Some of the definitions listed are used in the non-


1
