ASME B107.34-2003

SOCKET WRENCHES FOR SPARK PLUGS

1. SCOPE

   This Standard provides dimensional, performance, and safety requirements for detachable hand use socket wrenches with square drive for spark plugs. Inclusion of dimensional data in this Standard is not intended to imply that all of the products described herein are stock production sizes. Consumers are requested to consult with manufacturers concerning list of stock produc- tion sizes.




2. CLASSIFICATION (see Fig. 1)

   Figure 1 shows the different Types and Classes of socket wrenches for spark plugs.

   Type I: Socket, single hexagon (6 point)

   Class 1: Regular length

   Class 2: Long length

   Type II: Universal sockets, single hexagon (6 point)

   Class 1: Square block

   Class 2: Ball swivel




3. NORMATIVE REFERENCES

   The following is a list of publications referenced in this Standard.

   ASME B46.1-1995, Surface Texture (Surface Roughness, Waviness, and Lay)

   ASME B107.4M-1995, Driving and Spindle Ends for Por- table Hand Air and Electric Tools (Percussion Tools Excluded)

   ASME B107.17M-1997, Gages, Wrench Opening, Ref- erence

   Publisher: American Society of Mechanical Engineers (ASME International), Three Park Avenue, New York, NY 10016; Order Department: 22 Law Drive, Box 2300,

   Fairfield, NJ 07007-2300

   ASTM B 117-97, Standard Practice for Operating Salt Spray (Fog) Apparatus

   ASTM B 537-70(1997) Standard Practice for Rating of Electroplated Panels Subjected to Atmospheric Exposure

   ASTM B 571-97, Standard Test Methods for Qualitative Adhesion Testing of Metallic Materials

   ASTM D 968-93, Standard Test Methods for Abrasion Resistance of Organic Coatings by Falling Abrasive

   ASTM E 18-00, Standard Test Methods for Rockwell Hardness and Rockwell Superficial Hardness of Metallic Materials

   Publisher: American Society for Testing and Materials (ASTM), 100 Barr Harbor Drive, West Conshohocken, PA 19428

   Guide to Hand Tools-Selection, Safety Tips, Proper Use and Care

   Publisher: Hand Tools Institute (HTI), 25 North Broad- way, Tarrytown, NY 10591




4. REQUIREMENTS

   1. Figures

      The figures herein are descriptive and not restrictive, and are not intended to preclude the manufacture of sockets that are otherwise in accordance with this Standard.




   2. Materials

      The materials used in the manufacture of the sockets shall be such as to produce tools conforming to require- ments specified in this Standard.




   3. Marking

      Sockets shall be marked in a plain and permanent manner with the manufacturer’s name or with a trade- mark of such known character that the source of manu- facture and country of origin may be readily determined. In addition, sockets shall be marked in a plain and per- manent manner with the nominal size of the wrench opening (distance across flats).




   4. Hardness

      Sockets shall be heat treated to a hardness of 38 HRC to 54 HRC.




   5. Proof Torque

      When tested as specified, tools shall withstand the proof torque specified in the applicable tables without failure or permanent deformation (set), that might affect the durability or serviceability of the tools.




   6. Finish

All external surfaces shall be free from uncoated areas, pits, blisters, nodules, forge flash, burrs, cracks, and any

1
