ASME B5.61-2003

Power Presses: General Purpose, Single Action, Straight Side Type

AN A MERICAN NA TIONAL S T AND ARD

ASME B5.61-2003

Power Presses: General Purpose, Single Action, Straight Side

Type

AN AMERICAN NA TIONAL S T AND ARD

Three Park Avenue • New York, NY 10016

Date of Issuance: December 15, 2004

This Standard will be revised when the Society approves the issuance of a new edition. There will be no addenda or written interpretations of the requirements of this Standard issued to this edition.

ASME is the registered trademark of The American Society of Mechanical Engineers.

This code or standard was developed under procedures accredited as meeting the criteria for American National Standards. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.

ASME does not ‘‘approve,’’ ‘‘rate,’’ or ‘‘endorse’’ any item, construction, proprietary device, or activity.

ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assume any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.

Participation by a federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.

ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which preclude the issuance of interpretations by individuals.

No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,

without the prior written permission of the publisher.

The American Society of Mechanical Engineers Three Park Avenue, New York, NY 10016-5990

Copyright © 2004 by

THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS

All rights reserved Printed in U.S.A.

CONTENTS

Figures

1. Slide Connections for Single-Point, Two-Point, and Four-Point Presses 2

2. Drives for Single-Point, Two-Point, and Four-Point Presses 3

3. Typical Construction of a Mechanical Press 4

4. Typical Construction of a Hydraulic Press 4

5. Typical Bolster 15

6. Typical Slide 15

7. Headed Pressure Pin 17

8. Headed Pressure Pinhole 17

9. Pressure Pinhole Location Identification System 18

10. Establishing the Bed as the Datum Plane 18

11. Bolster Flatness and Parallelism 19

12. Checking Parallelism From Slide Face to Bed or Bolster Surface 19

13. Checking Squareness of Slide Travel 20

14. Leveling the Slide Using Load Cells 20

15. Press Data Plate: Mechanical Press 21

16. Press Data Plate: Hydraulic Press 21

17. Counterbalance Data Plate 21

18. Die Cushion Data Plate 22

19. Press Designation System 22

20. Press Capability Graph (Metric) 23

21. Press Capability Graph (U.S. Customary) 24

Tables

1. Standard Capacity Ratings 1

2. Standard Rating Points 2

   iii

3. Press Speed/Drive Motor Relationship 2

4. Usable Flywheel Energy 3

5. Stroke and Die Space Dimensions: Mechanical Power Press 5

6. Bed and Slide Dimensions: Single-Point Press 5

7. Bed and Slide Dimensions: Two-Point and Four-Point Press 6

8. Bolster Locating Pin Dimensions 7

9. Spacing of Bolster Locating Pinholes: Single-Point Press 7

10. Spacing of Bolster Locating Pinholes: Two-Point and Four-Point Press 8

11. Bolster Mounting Slot Dimensions 9

12. Spacing of Bolster Mounting Slots: Single-Point Press 9

13. Spacing of Bolster Mounting Slots: Two-Point and Four-Point Press 10

14. Bolster Mounting Bolt Dimensions 11

15. Bolster Handling Holes: Single-Point Press 12

16. Bolster Handling Holes: Two-Point and Four-Point Press 13

17. Bolster Handling Hook Dimensions 14

18. Bolster Handling Hook Bolt Dimensions 14

19. Number of T-Slots 16

20. Plain Pressure Pin 16

21. Pressure Pinhole Patterns 17

22. Pressure Pinhole Plug 18

    Mandatory Appendices

    1. Mechanical Power Press Capacity Above Rating Point of 12.7 mm (0.5 in.) 25

    2. Mechanical Power Press Capacity Above Rating Point of 6.3 mm (0.25 in.) 26

    3. Mechanical Power Press Capacity Above Rating Point of 1.6 mm (0.06 in.) 27

    4. Usable Flywheel Energy 28

    5. Bed and Slide Deflection 29

    6. Offset Loading of a Mechanical Press Slide 30

Nonmandatory Appendices

1. Metric/U.S. Customary Conversion 31

2. Comparison of Capacity Ratings Between Historical JIC and ISO

Standards 32

iv

FOREWORD

Recognizing the need for a standard for mechanical power presses, the ASME Committee on Machine Tools and Components (B5) established in December 1973, Technical Committee 30 to develop an American National Standard addressing the interchangeability of bolsters, press tooling, and mounting provisions between general purpose presses of comparable bed size, capacity, and type.

The B5-TC30 membership consists of a balance between manufacturers, users, accessory suppli- ers and others associated with power presses. The technical committee’s work was based on the Joint Industry Conference (JIC) Press Room Standards, once the most widely used document, to develop a standard for mechanical power presses, and basic data submitted by U.S. manufacturers of power presses.

In April 1983, the committee completed the final draft of “Standard for Straight Side Type Presses (Metric).” This draft was not submitted for approval before the committee became inactive. In 1995, Technical Committee 30 was reestablished to continue the pursuit of the original objectives set forth in 1973. The scope of the Standard was expanded to include hydraulic power

presses.

ASME B5.61-2003 was approved by the American National Standards Institute on July 7, 2003.

v

ASME B5 STANDARDS COMMITTEE

Machine Tools — Components, Elements, Performance, and Equipment

(The following is the roster of the Committee at the time of approval of this Standard.)

OFFICERS

C. T. Wax, Chair

M. Lo, Secretary

COMMITTEE PERSONNEL

A. M. Bratkovich, The Association for Manufacturing Technology

1. J. Gregorovich, C. J. Gregorovich & Associates

2. King, Parlec

M. Lo, The American Society of Mechanical Engineers

C. D. Lovett, National Institute of Standards and Technology

C. Nuccitelly, Parlec

G. R. Rawlinson, Rawlinson & Associates

W. S. Roorda, Alcona Associates

R. C. Spooner, Powerhold, Inc.

C. T. Wax, Scully-Jones Corp.

TECHNICAL COMMITTEE 30 — POWER PRESSES

C. J. Gregorovich, Chair, C. J. Gregorovich & Associates

W. S. Roorda, Secretary, Alcona Associates

R. Boge, Smedberg Machine Corp.

A. M. Bratkovich, The Association for Manufacturing Technology

G. Clouse, Oak Products, Inc.

D. L. Cota, Benchmaster, Inc.

K. J. Koroncey, General Motors Corp.

S. R. Otsuka, Verson, A Division of Allied Corp.

G. R. Rawlinson, Rawlinson and Associates

A. Sambel, Schuler Hydroforming, Inc.

1. Speich, Clearing-Niagara

2. D. Steinke, The Minster Machine Co.

T. Werding, Schuler Hydroforming, Inc.

L. A. Wood, Whirlpool Corp.

vi

CORRESPONDENCE WITH THE B5 COMMITTEE

General. ASME Standards are developed and maintained with the intent to represent the consensus of concerned interests. As such, users of this Standard may interact with the Committee by proposing revisions, and attending Committee meetings. Correspondence should be addressed to:

Secretary, B5 Main Committee

The American Society of Mechanical Engineers Three Park Avenue

New York, NY 10016-5990

Proposing Revisions. Revisions are made periodically to the Standard to incorporate changes that appear necessary or desirable, as demonstrated by the experience gained from the application of the Standard. Approved revisions will be published periodically.

The Committee welcomes proposals for revisions to this Standard. Such proposals should be as specific as possible, citing the paragraph number(s), the proposed wording, and a detailed description of the reasons for the proposal, including any pertinent documentation. Attending Committee Meetings. The B5 Main Committee regularly holds meetings, which are open to the public. Persons wishing to attend any meeting should contact the Secretary

of the B5 Main Committee.

vii

ASME B5.61-2003

POWER PRESSES: GENERAL PURPOSE, SINGLE ACTION, STRAIGHT SIDE TYPE

1. SCOPE, PURPOSE, AND APPLICATION

   1. Scope




      Table 1 Standard Capacity Ratings




      Single-Point Press Two-Point Press Four-Point Press




      This Standard applies to hydraulic and mechanical kN		tons	kN	tons	kN	tons
      power presses commonly referred to by the metal- working industry as General Purpose, Single Action, 250		30	...	...	...	...
      500		55	500	55	. . .	. . .
      Straight Side Type Power Presses that, by means of dies 1 000		110	1 000	110	. . .	. . .
      or tooling attached to the slide and bolster, are used to 1 600		180	1 600	180	. . .	. . .
      shear, punch, form, or assemble metal or other materials. 2 000		225	2 000	225	. . .	. . .
      The following types of presses are excluded from this 2 500		280	2 500	280	2 500	280
      Standard: 4 000		450	4 000	450	4 000	450
      (a) air (pneumatic) 6 300		710	6 300	710	6 300	710
      10 000		1,125	10 000	1,125	10 000	1,125
      (b) bench	. . .	. . .	16 000	1,800	16 000	1,800
      (c) eyelet machines	. . .	. . .	20 000	2,250	20 000	2,250
      (d) forging	. . .	. . .	25 000	2,810	25 000	2,810
      (e) four slide machines
      (f) gap frame

      1. knuckle joint

      2. multiple action

      3. multiple slide

      4. spotting

      5. transfer feed

      6. turret punching

   2. Purpose

      The purpose of this Standard is to define and describe power presses and their interface, and to permit inter- changeability of bolsters, dies, and tooling components between presses of comparable type, size, and capacity.

   3. Application

      Any power press described herein and referred to as an American National Standard Power Press shall comply with the applicable requirements delineated in this Standard.




2. DEFINITIONS AND TERMINOLOGY

   Terms used in this Standard are defined in ASME B5.49, Glossary of Power Press Terms.




3. METRIC/U.S. CUSTOMARY RATIONALIZATION

   1. Metrication

      All units of dimension and capacity stated herein are in accordance with ASME B5.51M, Preferred SI Units

      for Machine Tools. Approximate U.S. Customary units are historical standards and are for reference only. Wher- ever used in this Standard, the unit tons denotes U.S. tons.




   2. Metric/U.S. Customary Conversion

      Nonmandatory Appendix A provides conversion multipliers applicable to this Standard.




4. PRESS CHARACTERISTICS

   1. Rated Capacity

      Standard capacity ratings shall be as specified in Table 1 (see also Fig. 1). See Nonmandatory Appendix B for historical comparison of capacity ratings.




   2. Rating Points (Mechanical Power Press)

1. Standard rating points shall be as specified in Table 2.

2. Drive design shall be based on providing the torque, which produces the rated press capacity at the rating point (see Fig. 2).

3. Press capacity at points other than the rating point are shown in

   1. Mandatory Appendix I for presses rated at

      12.7 mm (1⁄2 in.)

   2. Mandatory Appendix II for presses rated at 6.3 mm (1⁄4 in.)

1
