ASME Y14.41-2003 (R2008)
M00052516
New product
ASME Y14.41-2003 (R2008) Digital Product Definition Data Practices
standard by ASME International, 08/01/2003
Full Description
3D modeling is the future of design and ASME Y14.41 sets the rules. Y14.41 extends ASME Y14.5M into the 3D world.
The development of this National Standard was initiated at the request of industry and the U.S. Government. Developers of this standard include independent consultants and individuals from General Motors Corporation, Dassault-Systems, The Boeing Company, U.S. Department of the Army - TACOM-ARDEC, Rockwell Collins Inc., Raytheon Company, Thiokol Propulsion, EDS PLM Solutions, General Dynamics Land Systems, Lockheed Martin Aeronautics Company, Ford Motor Company, Caterpillar Inc., DEPCO Inc., Rolls-Royce Corporation, CNH Global NV, Purdue University, and Hutchinson Technology Inc.
The Y14.41 standard establishes requirements, and references documents applicable to the preparation and revision of digital product definition data, referred to as data sets. Y14.41 defines the exceptions and additional requirements to existing ASME standards for using product definition data sets or drawings in 3D digital format. This standard supports two methods of application: model only, and model and drawing in digital format.
The structure of the standard begins with the requirements common to both methods (model only, and model and drawing in digital format), and then branches to the other sections that have differing requirements for each method.
It also provides a guide for the many computer aided design (CAD) software packages to develop better modeling and annotation practices for CAD and engineering disciplines.
Adoption Notice: ASME Y14.41 was adopted on 7 July 2003 for use by the Department of Defense, (DoD). Proposed changes by DoD activities must be submitted to the DoD Adopting Activity: Commander, US Army TACOM-ARDEC, ATTN: AMSTA-AR-QAW-E, Picatinny Arsenal, NJ 07806-5000.
In stock
More info
Engineering Drawing
and Related Documentation
Practices
ASME Y14.41-2003
DIGITAL PRODUCT DEFINITION DATA
PRACTICES
An American National Standard
ASME Y14.41
ADOPTION NOTICE
ASME Y14.41, Digital Product Definition Data Practices, was adopted on 7 July 2003 for use by the Department of Defense, (DoD). Proposed changes by DoD activities must be submitted to the DoD Adopting Activity: Com- mander, U.S. Army TACOM-ARDEC, ATTN: AMSTA-AR-QAW-E, Picatinny Arsenal, NJ 07806-5000. Copies of this document may be purchased from The American Society of Mechanical Engineers (ASME), 22 Law Drive, PO Box 2900, Fairfield, NJ 07007-2900; https://www.asme.org.
Custodians: Adopting Activity:
Army — AR Army — AR
Navy — SA Air Force — 16 DLA — DH
Review Activities:
Army — AT, AV, CE, CR, EA, GL, MI, SM, TE Navy — AS, CH, EC, MC, OS, SH, TD, YD Air Force — 11, 13, 19, 68, 70, 71, 84, 99
DLA — CC, IS NSA — NS
AMSC N/A AREA DRPR
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
A N A M E R I C A N N A T I O N A L S T A N D A R D
DIGITAL PRODUCT DEFINITION DATA
PRACTICES
ASME Y14.41-2003
Date of Issuance: August 15, 2003
The next edition of this Standard is scheduled for publication in 2007. There will be no addenda or written interpretations of the requirements of this Standard issued to this edition.
ASME is the registered trademark of The American Society of Mechanical Engineers.
This code or standard was developed under procedures accredited as meeting the criteria for American National Standards. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.
ASME does not “approve,” “rate,” or “endorse” any item, construction, proprietary device, or activity.
ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assumes any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.
Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.
ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.
No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,
without the prior written permission of the publisher.
The American Society of Mechanical Engineers Three Park Avenue, New York, NY 10016-5990
Copyright © 2003 by
THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS
All rights reserved Printed in U.S.A.
