ASME B89.7.3.3-2002

GUIDELINES FOR ASSESSING THE RELIABILITY OF DIMENSIONAL MEASUREMENT UNCERTAINTY STATEMENTS

ABSTRACT

The primary purpose of this technical report is to provide guidelines for assessing the reliability of mea- surement uncertainty statements. Applying these guide- lines can assist businesses in avoiding disagreements about measurement uncertainty statements and in resolv- ing such disagreements should they occur. Disagree- ments over uncertainty statements involving both single measurement systems and multiple measurement sys- tems (each having their own uncertainty statement) are considered. Guidance is provided for examining uncertainty budgets as the primary method of assessing their reliability. Additionally, resolution by direct mea- surement of the measurand is also discussed.

1. SCOPE




   1.1 Objective

   This technical report provides guidance in assessing

2. DEFINITIONS1

acceptance zone: the set of values of a characteristic, for a specifie measurement process and decision rule, that results in product acceptance when a measurement result is within this zone.2

decision rule: a documented rule, meeting the require- ments of section 3 of ASME B89.7.3.1, that describes how measurement uncertainty will be allocated with regard to accepting or rejecting a product according to its specificatio and the result of a measurement.

expanded uncertainty: quantity definin an interval about the result of a measurement that may be expected to encompass a large fraction of the distribution of values that could reasonably be attributed to the measur- and. See GUM, 2.3.5.

guard band: the magnitude of the offset from the specificatio limit to the acceptance or rejection zone boundary.3, 4, 5, 6, 7, 8

the reliability of a statement of measurement uncertainty

in question, that is, in judging whether that stated uncertainty can be trusted to include the values that could reasonably be attributed to the measured quantity (measurand) with which that stated uncertainty is asso- ciated.

1. Applicability

   This report is most applicable to statements of uncer- tainty in the results of dimensional measurements based upon the ISO Guide to Expression of Uncertainty in Measurement (GUM). (Also called ANSI/NCSL Z540-2.)




2. Purpose

This technical report helps parties to avoid potential, or resolve actual, disagreements over the magnitude of a stated measurement uncertainty, particularly when that uncertainty is part of a determination of conformity of a manufactured product to a dimensional specifi cation.

1 Many of these definition are selected from ASME B89.7.3.1. The figure from that document are omitted here for brevity.

2 When claiming product acceptance, it is important to state the decision rule; e.g., “acceptance using the XX rule.”

3 The symbol g is deliberately used for the guard band, instead of the symbol U employed in ISO 14253-1 since U is reserved for the expanded uncertainty which is associated with a measurement result and hence it is confusing to attach U to a specificatio limit. The evaluation of U is a technical issue, while the evaluation of g is a business decision.

4 The guard band is usually expressed as a percentage of the expanded uncertainty, i.e., a 100% guard band has the magnitude of the expanded uncertainty U.

5 Two-sided guard banding occurs when a guard band is applied to both the upper and lower specificatio limits. (In some exceptional situations the guard band applied within the specificatio zone, gIn, could be different at the upper specificatio limit and at the lower specificatio limit. This would reflec a different risk assessment associated with an upper or lower out-of-specificatio condition depending on whether the characteristic was larger or smaller than allowed by the specificatio zone.) If both the upper and lower guard bands are the same size then this is called symmetric two- sided guard banding.

6 A guard band is sometimes distinguished as the upper or lower guard band, associated with the upper or lower specificatio limit. Subscripts are sometimes attached to the guard band notation, g, to provide clarity, e.g., gUp and gLo. See ASME B89.7.3.1, Fig. 1.

1
