Wrought Copper and Copper Alloy Braze-Joint Pressure Fittings

AN A MERICAN NA TIONAL S T AND ARD

ASME B16.50-2013

[Revision of ASME B16.50-2001 (R2008)]

ASME B16.50-2013

[Revision of ASME B16.50-2001 (R2008)]

Wrought Copper and Copper Alloy Braze-Joint Pressure Fittings

AN AMERICAN NA TIONAL S T AND ARD

Two Park Avenue • New York, NY • 10016 USA

Date of Issuance: August 6, 2013

The next edition of this Standard is scheduled for publication in 2018.

ASME issues written replies to inquiries concerning interpretations of technical aspects of this Standard. Interpretations are published on the ASME Web site under the Committee Pages at https://cstools.asme.org/ as they are issued.

Errata to codes and standards may be posted on the ASME Web site under the Committee Pages to provide corrections to incorrectly published items, or to correct typographical or grammatical errors in codes and standards. Such errata shall be used on the date posted.

The Committee Pages can be found at https://cstools.asme.org/. There is an option available to automatically receive an e-mail notification when errata are posted to a particular code or standard. This option can be found on the appropriate Committee Page after selecting “Errata” in the “Publication Information” section.

ASME is the registered trademark of The American Society of Mechanical Engineers.

This code or standard was developed under procedures accredited as meeting the criteria for American National Standards. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.

ASME does not “approve,” “rate,” or “endorse” any item, construction, proprietary device, or activity.

ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assumes any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.

Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.

ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.

No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,

without the prior written permission of the publisher.

The American Society of Mechanical Engineers Two Park Avenue, New York, NY 10016-5990

Copyright © 2013 by

THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS

All rights reserved Printed in U.S.A.

CONTENTS

Foreword iv

Committee Roster v

Correspondence With the B16 Committee vi

Summary of Changes vii

1. Scope 1

2. General 1

3. Pressure–Temperature Ratings 1

4. Terminology 1

5. Marking 5

6. Material 5

7. Laying Lengths 5

8. Tube Stops 5

9. Inspection Tolerance 5

10. Threaded Ends 5

11. Alignment 8

12. Gaging 8

Figures

1. Method of Designating Laying Lengths of Fittings and

   Openings of Reducing Fittings 3

2. Tube Stops 6

3. Alignment 8

Tables

1. Internal Pressure–Temperature Ratings for Copper Fittings, kPa 2

2. Inspection Tolerance 6

3. Dimensions of Braze-Joint Ends 7

iii

FOREWORD

In 1994, the ASME B16 Standards Committee authorized Subcommittee J Standardization to develop a standard for wrought copper and copper alloy braze-joint pressure fittings. These fittings are intended for use with seamless copper tube conforming to the American National StandardsInstitute(ASTM)StandardSpecifications,B88(WaterandGeneralPlumbingSystems),B280 (Air Conditioning and Refrigeration Service), and B819 (Medical Gas Systems). Following approval by the Standards Committee and ASME, this Standard was approved as an American National Standard on October 11, 2001, with the new designation ASME B16.50-2001.

In this 2013 Edition, references to ASME standards were revised to no longer list specific edition years; the latest edition of ASME publication applies, unless stated otherwise. Also in this Edition, Tables 3 and I-3 now include a maximum cup length under the column heading shown as “Depth, G.” Following approval by the B16 Standards Committee and the ASME Supervisory Board, and after public review, this Standard was approved as an American National Standard by ANSI on May 28, 2013.

Requests for interpretation or suggestions for revision should be sent to the Secretary, B16 Standards Committee, The American Society of Mechanical Engineers, Two Park Avenue, New York, NY 10016-5990.

iv

ASME B16 COMMITTEE

Standardization of Valves, Flanges, Fittings, and Gaskets

(The following is the roster of the Committee at the time of approval of this Standard.)

STANDARDS COMMITTEE OFFICERS

W. B. Bedesem, Chair

G. A. Jolly, Vice Chair

C. E. O’Brien, Secretary

A. Appleton, Alloy Stainless Products Co., Inc.

R. W. Barnes, ANRIC Enterprises, Inc.

W. B. Bedesem, Consultant

STANDARDS COMMITTEE PERSONNEL

M. Katcher, Haynes International

W. N. McLean, B&L Engineering

T. A. McMahon, Emerson Process Management

R. M. Bojarczuk, ExxonMobil Research & Engineering Co.

D. F. Buccicone, Consultant

A. M. Cheta, Shell Exploration and Production Co.

M. A. Clark, NIBCO, Inc.

G. A. Cuccio, Capitol Manufacturing Co.

1. E. Davila, Crane Energy

2. R. Frikken, Becht Engineering Co.

K. A. Hettler, U.S. Coast Guard

G. A. Jolly, Vogt Valves/Flowserve Corp.

M. L. Nayyar, NICE

C. E. O’Brien, The American Society of Mechanical Engineers

W. H. Patrick, Dow Chemical Co.

D. Rahoi, Consultant

R. A. Schmidt, Canadoil

H. R. Sonderegger, Fluoroseal, Inc.

W. M. Stephan, Flexitallic LP

F. R. Volgstadt, Volgstadt & Associates, Inc.

D. A. Williams, Southern Co. Generation

SUBCOMMITTEE J — COPPER AND COPPER ALLOY FLANGES, FLANGED FITTINGS, AND SOLDER JOINT FITTINGS

M. A. Clark, Chair, NIBCO, Inc.

D. F. Buccicone, Vice Chair, Consultant

C. R. Ramcharran, Secretary, The American Society of Mechanical Engineers

J. A. Ballanco, JB Engineering & Code Cons PC

S. L. Cavanaugh, Cavanaugh Consulting

A. Ciechanowski, NSF International

D. R. Frikken, Becht Engineering Co.

M. Gillespie, Viega LLC

T. L. Jamison, Jamison Engineering

A. G. Kireta, Jr., Copper Development Association, Inc.

A. A. Knapp, A. Knapp & Associates

S. Robinett, Consultant

C. Stout, Mueller Industries

C. Mueller, Alternate, Mueller Industries

v

CORRESPONDENCE WITH THE B16 COMMITTEE

General. ASME Standards are developed and maintained with the intent to represent the consensus of concerned interests. As such, users of this Standard may interact with the Committee by requesting interpretations, proposing revisions, and attending Committee meetings. Corre- spondence should be addressed to:

Secretary, B16 Standards Committee

The American Society of Mechanical Engineers Two Park Avenue

New York, NY 10016-5990

As an alternative, inquiries may be submitted via email to: SecretaryB16@asme.org.

Proposing Revisions. Revisions are made periodically to the Standard to incorporate changes that appear necessary or desirable, as demonstrated by the experience gained from the application of the Standard. Approved revisions will be published periodically.

The Committee welcomes proposals for revisions to this Standard. Such proposals should be as specific as possible, citing the paragraph number(s), the proposed wording, and a detailed description of the reasons for the proposal, including any pertinent documentation.

Interpretations. Upon request, the B16 Committee will render an interpretation of any require- ment of the Standard. Interpretations can only be rendered in response to a written request sent to the Secretary of the B16 Standards Committee.

The request for interpretation should be clear and unambiguous. It is further recommended that the inquirer submit his/her request in the following format:

Subject: Cite the applicable paragraph number(s) and the topic of the inquiry.

Edition: Cite the applicable edition of the Standard for which the interpretation is being requested.

Question: Phrase the question as a request for an interpretation of a specific requirement suitable for general understanding and use, not as a request for an approval of a proprietary design or situation. The inquirer may also include any plans or drawings that are necessary to explain the question; however, they should not contain proprietary names or information.

Requests that are not in this format will be rewritten in this format by the Committee prior to being answered, which may inadvertently change the intent of the original request.

ASME procedures provide for reconsideration of any interpretation when or if additional information that might affect an interpretation is available. Further, persons aggrieved by an interpretation may appeal to the cognizant ASME Committee or Subcommittee. ASME does not “approve,” “certify,” “rate,” or “endorse” any item, construction, proprietary device, or activity. Attending Committee Meetings. The B16 Standards Committee regularly holds meetings, which are open to the public. Persons wishing to attend any meeting should contact the Secretary of

the B16 Standards Committee.

vi

ASME B16.50-2013 SUMMARY OF CHANGES

Following approval by the B16 Committee and ASME, and after public review, ASME B16.50-2013 was approved by the American National Standards Institute on May 28, 2013.

ASME B16.50-2013 consists of editorial changes, revisions, and corrections identified by a margin note, (13), placed next to the affected area.

vii

INTENTIONALLY LEFT BLANK

viii

ASME B16.50-2013

WROUGHT COPPER AND COPPER ALLOY BRAZE-JOINT PRESSURE FITTINGS

1. 1 SCOPE

   This Standard establishes requirements for wrought copper and wrought copper alloy braze-joint seamless fittings designed for use with seamless copper tube con- forming to ASTM Standard Specification, B88 (Water and General Plumbing Systems), B280 (Air Conditioning and Refrigeration Service), and B819 (Medical Gas Systems).

   This Standard covers joints assembled with brazing materials conforming to ANSI/AWS A5.8.

   This Standard is allied to ASME standards B16.18 and B16.22. It provides requirements for fitting-ends suitable for brazing. This Standard covers

   1. pressure–temperature ratings

   2. abbreviations for end connections

   3. size and method of designating openings of fittings

   4. marking

   5. material

   6. dimensions and tolerances

   7. testing

1. GENERAL

   1. Units of Measure

      This Standard states values in both SI (Metric) and

      U.S. Customary units. These systems of units are to be regarded separately as standard. Within the text, the

      U.S. Customary units are shown in parentheses or in separate tables that appear in Mandatory Appendix I. The values stated in each system are not exact equiva- lents; therefore, it is required that each system of units be used independently of the other. Combining values from the two systems constitutes nonconformance with the Standard.




   2. References

      Standards and specifications adopted by reference in this Standard are shown in Mandatory Appendix II, which is part of this Standard. It is not considered practi- cal to identify the specific edition of each standard and specification in the individual references. Instead, the specific edition reference is identified in Mandatory Appendix II.

   3. Quality Systems

      Requirements relating to the product manufacturer’s Quality System Programs are described in Nonmandatory Appendix B.




2. PRESSURE–TEMPERATURE RATINGS

   1. Rating of System

      The internal pressure–temperature rating for a braze- joint system is dependent upon not only fitting and tube strength but also selection of valves and appurtenances. Pressure–temperature ratings for fittings and braze joints to the dimensions of Table 3 (Table I-3), made with typical commercial brazing materials, shall be consid-

      ered equal to the values given in Table 1 (Table I-1). The internal pressure–temperature rating of the sys-

      tem shall be the lowest of the values shown in Table 1 (Table I-1) and those of the tube, valves, or appurtenances.

   2. Fitting Bursting Strength

      Fittings manufactured to this Standard shall have an ambient–temperature bursting strength of at least four times the 38°C (100°F) internal pressure rating as shown in Table 1 (Table I-1).




3. TERMINOLOGY

   1. Size

      The size of the fittings shown in Tables 3 and I-3 corresponds to standard water tube size as shown in ASTM B88. The size of the threaded ends corresponds to nominal pipe size as shown in ASME B1.20.1.

      Fittings are designated by the size of the openings in the sequence illustrated in Fig. 1.

   2. Abbreviations

The following symbols are used to designate the type of fitting end:

C p braze-joint fitting end made to receive copper tube diameter (female)

F p internal ANSI standard taper pipe-thread end (female) NPTI

FTG p braze-joint fitting end made to copper tube diameter (male)

M p external ANSI standard taper pipe-thread end (male) NPTE

(13)

1
