Glossary of Terms for Mechanical Fasteners

AN AMERICAN NA TIONAL S T AND ARD

ASME B18.12-2012

[Revision of ASME B18.12-2001 (R2006)]

Glossary of Terms for Mechanical Fasteners

AN AMERICAN NA TIONAL S T AND ARD

Three Park Avenue • New York, NY • 10016 USA

Date of Issuance: February 23, 2012

This Standard will be revised when the Society approves the issuance of a new edition.

ASME issues written replies to inquiries concerning interpretations of technical aspects of this Standard. Periodically certain actions of the ASME B18 Committee may be published as Cases. Cases and interpretations are published on the ASME Web site under the Committee Pages at https://cstools.asme.org/ as they are issued.

Errata to codes and standards may be posted on the ASME Web site under the Committee Pages to provide corrections to incorrectly published items, or to correct typographical or grammatical errors in codes and standards. Such errata shall be used on the date posted.

The Committee Pages can be found at https://cstools.asme.org/. There is an option available to automatically receive an e-mail notification when errata are posted to a particular code or standard. This option can be found on the appropriate Committee Page after selecting “Errata” in the “Publication Information” section.

ASME is the registered trademark of The American Society of Mechanical Engineers.

This code or standard was developed under procedures accredited as meeting the criteria for American National Standards. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.

ASME does not “approve,” “rate,” or “endorse” any item, construction, proprietary device, or activity.

ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assumes any such liability. Users of a code or standard are expressly advised that determination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.

Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.

ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.

No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,

without the prior written permission of the publisher.

The American Society of Mechanical Engineers Three Park Avenue, New York, NY 10016-5990

Copyright © 2012 by

THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS

All rights reserved Printed in U.S.A.

CONTENTS

Foreword iv

Committee Roster v

Correspondence With the B18 Committee vi

1. Introduction 1

2. Terminology 1

3. Product Families 23

Tables

1. Common Applications of Threaded Fastener Head Styles 8

2. Type Designations for Tapping Screws and Metallic Drive Screws 33

3. Screw and Washer Assembly Combinations 40

Index 55

iii

FOREWORD

Sect ional Committ ee B18 on Dimensional Standardization of Bolts, Nuts, Rivets, Screws, and Simi- lar Fasteners was organized in March 1922 under the procedure of the American Standards Association with the Society of Automotive Engineers and The American Society of Mechanical Engineers as joint sponsors.

Subcommittee 10 on the Glossary of Terms for Mechanical Fasteners was organized in February 1947. The purpose of the subcommittee was to promote and coordinate the standardization of fastener nomenclature for those products falling under the scope of the various other subcommittees of the B18 Sectional Committee, the definitions themselves being the responsibility of the cognizant subcommittee. It was later decided that terms not strictly in the above category but closely allied should be defined in the Glossary.

During the development period, several drafts of the Glossary were prepared and studied by Subcommittee 10 before a suitable format and content could be agreed upon.

To cover completely the field of mechanical fasteners, it has been necessary to include in this Standard illustra- tions of certain fastener features and types of fasteners that are of proprietary origin. Because it was impossible to include all variations of such proprietary designs, this Standard includes selected illustrations that exemplify the type of fastener or feature described. This selection was made on an impartial basis. The inclusion of any one

proprietary design in this Standard does not constitute endorsement by the committee or the sponsors, nor is omission of certain styles to be construed as rejection of such styles by the committee and sponsors.

ASA B18.12 was approved by the B18 Sectional Committee, the sponsors, and the American Standards Association, and it was designated as an American Standard on June 22, 1962.

In May 1995, Subcommittee 12 of the B18 Standards Committee set forth the concept that a complete update and significant revision of the Glossary of Terms was necessary. The content was completely reorganized to reflect a logical approach to basic fastener characteristics and configurations. Many new sections and items, such as blind fasteners and retaining rings, were included. In total, 538 terms were included in the 2001 edition of the Standard. ASME B18.12-2001 was approved by the American National Standards Institute on August 15, 2001.

In this edition, para. 3.1.3 was revised in its entirety, and para. 3.1.4 was added.

Suggestions for improvement of this Standard will be welcomed. They should be sent to The American Society of Mechanical Engineers, Secretary, B18 Standards Committee, Three Park Avenue, New York, NY 10016- 5990.

This revision was approved as an American National Standard on January 9, 2012.

iv

ASME B18 COMMITTEE

Standardization of Bolts, Nuts, Rivets, Screws, Washers, and Similar Fasteners

(The following is the roster of the Committee at the time of approval of this Standard.)

STANDARDS COMMITTEE OFFICERS

J. Greenslade, Chair

D. S. George, Vice Chair

R. D. Strong, Vice Chair

1. J. Gomez, Secretary







   V. Cartina, Autocraft Industrial

2. A. Clever, Consultant

A. P. Cockman, Ford Motor Co.

1. D. de la Garza, Texas Screw Products

2. S. George, Ramco Specialties

STANDARDS COMMITTEE PERSONNEL

W. J. Lutkus, Emhart Teknologies

D. A. McCrindle, Canadian Fasteners Institute

M. D. Prasad, Contributing Member, Global M & F Solutions, Inc.

S. Savoji, ITW Medalist

Q. M. Smith III, Oregon DOT

C. J. Gomez, The American Society of Mechanical Engineers

J. Greenslade, Industrial Fasteners Institute

J. J. Grey, Contributing Member, Fastener Consulting Services, Inc.

A. Herskovitz, Consultant

J. Hubbard, Leland-Powell Fasteners, Inc.

J. Jennings, Contributing Member, Naval Surface Warfare Center

W. H. King, Porteous Fastener Co.

W. H. Kopke, Consultant

D. J. Soscia, General Dynamics Electric Boat Corp.

W. R. Stevens, Ramco

1. D. Strong, Doerken Corp.

2. W. Vass, Consultant

C. B. Wackrow, MNP Corp.

W. K. Wilcox, Consultant

C. B. Williamson, Fastenal Co.

C. J. Wilson, Consultant

J. G. Zeratsky, National Rivet and Manufacturing Co.

1. J. Wilson, Chair, Consultant

2. A. Clever, Consultant

C. D. de la Garza, Texas Screw Products

M. A. Elmi, Consultant

SUBCOMMITTEE 12 — GLOSSARY OF TERMS

J. F. McCarrick, Defense Supply Center Philadelphia

D. A. McCrindle, Canadian Fasteners Institute

R. B. Meade, Atrona Material Testing Laboratories, Inc.

R. M. Serabin, Freundlich Supply Co.

J. S. Foote, Trade Association Management, Inc.

D. S. George, Ramco Specialties

J. Greenslade, Industrial Fasteners Institute

J. Jennings, Naval Surface Warfare Center

W. H. King, Porteous Fastener Co.

W. H. Kopke, Consultant

M. Levinson, ITW Shakeproof Industrial Products

D. F. Sharp, GMS Structural Engineers

G. M. Simpson, Semblex Corp.

Q. M. Smith III, Oregon DOT

W. R. Stevens, Ramco

R. D. Strong, Doerken Corp.

C. B. Wackrow, MNP Corp.

W. K. Wilcox, Consultant

C. B. Williamson, Fastenal Co.

v

CORRESPONDENCE WITH THE B18 COMMITTEE

General. ASME Standards are developed and maintained with the intent to represent the consensus of concerned interests. As such, users of this Standard may interact with the Committee by requesting interpretations, proposing revisions, and attending Committee meetings. Corre- spondence should be addressed to:

Secretary, B18 Standards Committee

The American Society of Mechanical Engineers Three Park Avenue

New York, NY 10016-5990

https://go.asme.org/Inquiry

Proposing Revisions. Revisions are made periodically to the Standard to incorporate changes that appear necessary or desirable, as demonstrated by the experience gained from the application of the Standard. Approved revisions will be published periodically.

The Committee welcomes proposals for revisions to this Standard. Such proposals should be as specific as possible, citing the paragraph number(s), the proposed wording, and a detailed description of the reasons for the proposal, including any pertinent documentation.

Proposing a Case. Cases may be issued for the purpose of providing alternative rules when justified, to permit early implementation of an approved revision when the need is urgent, or to provide rules not covered by existing provisions. Cases are effective immediately upon ASME approval and shall be posted on the ASME Committee Web page.

Requests for Cases shall provide a Statement of Need and Background Information. The request should identify the Standard, the paragraph, figure or table number(s), and be written as a Question and Reply in the same format as existing Cases. Requests for Cases should also indicate the applicable edition(s) of the Standard to which the proposed Case applies.

Interpretations. Upon request, the B18 Committee will render an interpretation of any require- ment of the Standard. Interpretations can only be rendered in response to a written request sent to the Secretary of the B18 Standards Committee.

The request for interpretation should be clear and unambiguous. It is further recommended that the inquirer submit his/her request in the following format:

Subject: Cite the applicable paragraph number(s) and the topic of the inquiry.

Edition: Cite the applicable edition of the Standard for which the interpretation is being requested.

Question: Phrase the question as a request for an interpretation of a specific requirement suitable for general understanding and use, not as a request for an approval of a proprietary design or situation. The inquirer may also include any plans or drawings that are necessary to explain the question; however, they should not contain proprietary names or information.

Requests that are not in this format may be rewritten in the appropriate format by the Committee prior to being answered, which may inadvertently change the intent of the original request.

ASME procedures provide for reconsideration of any interpretation when or if additional information that might affect an interpretation is available. Further, persons aggrieved by an interpretation may appeal to the cognizant ASME Committee or Subcommittee. ASME does not “approve,” “certify,” “rate,” or “endorse” any item, construction, proprietary device, or activity. Attending Committee Meetings. The B18 Standards Committee regularly holds meetings that are open to the public. Persons wishing to attend any meeting should contact the Secretary of

the B18 Standards Committee.

vi

ASME B18.12-2012

GLOSSARY OF TERMS FOR MECHANICAL FASTENERS

1. INTRODUCTION

   1. Scope

      This Standard is a summary of nomenclature and ter- minology currently used to define and/or describe mechanical fasteners, related characteristics, and the manufacturing processes that produce these products. Utilization of these terms by manufacturers and con- sumers is intended to reduce or eliminate confusion and serve as a sound basis for communication.

      1. Primary Operations. Mechanical fasteners are pro- duced by forming or screw machine operations. Forming is generally scrapless and, depending upon size, may produce fasteners at rates exceeding 500 pieces per minute. Screw machining, although more tightly toler- anced, is significantly slower and generates scrap because it involves the removal of material.

      2. Secondary Operations. Fasteners generally undergo several secondary operations or processes, such as thread rolling, heat treating, or plating.

      3. Fastener. A fastener is a mechanical device designed specifically to hold, join, couple, assemble, or maintain equilibrium of single or multiple components. The resulting assembly may function dynamically or statically as a primary or secondary component of a mechanism or structure. Based on the intended applica- tion, a fastener is produced with varying degrees of built-in precision and engineering capability, ensuring adequate, sound service under planned, pre-established environmental conditions.

      4. Bolts, Studs, Screws, Nuts, Washers, Rivets, Pins, and Custom-Formed Parts. These items are the general prod- uct families in which mechanical fasteners are best classi- fied. Within each product family are numerous types that may have a name conforming to the technical lan- guage of a national standard or alternately may have a name that has its origins in commercial or marketing nomenclature often taken from its intended application. Such names, for example, include the “stove bolt” and “carriage bolt.” Because mechanical fasteners are used in just about every mechanical assembly, they necessarily have been designed to meet a broad range of applica- tions from watch and computer assembly to the space shuttle design. The names given to fasteners appear to be as limitless as the designer’s imagination. While many fasteners may look alike, they generally have defined engineered capabilities based upon their intended application.

   2. Referenced Documents

      In the development of this Standard, a number of terms were written based upon language found in more than 230 standards and other publications of the follow- ing organizations:

      1. American Society for Testing and Materials (ASTM International), 100 Barr Harbor Drive, P.O. Box C700, West Conshohocken, PA 19428-2959 (www.astm.org)

      2. The American Society of Mechanical Engineers (ASME), Three Park Avenue, New York, NY 10016-5990; Order Department: 22 Law Drive, P.O. Box 2900, Fairfield, NJ 07007-2900 (www.asme.org)

      3. Industrial Fasteners Institute (IFI), 6363 Oak Tree Boulevard, Independence, OH 44131 (www.indfast.org)

      4. Society of Automotive Engineers (SAE International), 400 Commonwealth Drive, Warrendale, PA 15096 (www.sae.org)




2. TERMINOLOGY

   1. Basic Fastener Terminology

2.1.1

commercial fastener: manufactured to published consensus standards and stocked by manufacturers or distributors.

2.1.2

compression fastener: a fastener whose primary function is to resist compressive forces.

2.1.3

endurance limit or endurance strength: the maximum alter- nating stress that a fastener can withstand for a specified number of stress cycles without failure.

2.1.4

headed fastener: a fastener having one end enlarged or formed.

2.1.5

headless fastener: a fastener, either threaded or unthreaded, that does not have either end enlarged.

2.1.6

high-strength fastener: a fastener having high tensile and shear strengths attained through combinations of materials, work-hardening, and heat treatment. These fasteners usually have a tensile strength in excess of 120,000 psi.

1
