ASME MFC-6–2013

MeasureMent of fluid flow in PiPes using Vortex flowMeters

1. sCoPe

   This Standard

   1. describes the use of vortex flowmeters, including their physical components, principle of operation, instal- lation, performance, influence factors, and calibration in a closed conduit running full for the measurement of volu- metric flow rate and volume flow total of single-phase liquids or gases, including vapors such as steam

   2. describes the use of vortex flowmeters in combi- nation with one or more other process measurements for the inferential measurement of mass flow rate, mass flow total, base volumetric flow rate, base volume total, and heat flow metering

   3. is limited to full-bore flowmeters and does not include the special case of insertion-type flowmeters




2. referenCes and related doCuMents

   Unless otherwise indicated, the latest issue of a refer- enced standard shall apply.

   ASME MFC-1M, Glossary of Terms Used in the Measurement of Fluid Flow in Pipes

   Publisher: The American Society of Mechanical Engineers (ASME), Two Park Avenue, New York, NY 10016- 5990; Order Department: 22 Law Drive, P.O. Box 2900, Fairfield, NJ 07007-2900 (www.asme.org)




   IEC 60529, Degrees of Protection Provided by Enclosures (IP Code)

   Publisher: International Electrotechnical Commission (IEC), 3, rue de Varembé, Case Postale 131, CH-1211 Genève 20, Switzerland/Suisse (www.iec.ch)




3. terMinologY and sYMBols

3.1 definitions from asMe MfC-1M used in this standard

For the purposes of this Standard, the following defi- nitions are particularly useful in describing the charac- teristics of vortex shedding flowmeters. ASME MFC-1M provides a more extensive collection of definitions and symbols pertaining to the measurement of fluid flow in closed conduits.

cavitation: the implosion of vapor bubbles formed after flashing when the local pressure rises above the vapor pressure of the liquid.

flashing: the formation of vapor bubbles in a liquid when the local pressure falls to or below the vapor pressure of the liquid, often due to local lowering of pressure because of an increase in the liquid velocity.

K factor: in pulses per unit volume, the ratio of the meter output in number of pulses to the corresponding total volume of fluid passing through the meter during a measured period. Variations in the K factor may be pre- sented as a function of either the meter bore Reynolds number or the flow rate of a specific fluid at a specific set of thermodynamic conditions (see Fig. 9.2-1).

lowest local pressure: the lowest pressure found in the meter. This is the pressure of concern regarding flashing and cavitation. Some of the pressure is recovered down- stream of the meter.

meter bore Reynolds number: a dimensionless ratio of iner- tial to viscous forces that is used as a correlating param- eter that combines the effects of viscosity, density, and pipeline velocity. It is defined as

Re  DU

D m

meter factor: the reciprocal of the mean K factor.

pressure loss: the difference between the upstream pres- sure and the pressure downstream of the meter after recovery.

random error: a component of the error of measurement that, in the course of a number of measurements of the same measurand, varies in an unpredictable way.

NOTE: It is not possible to correct for random error.

random uncertainty: a component of uncertainty associ- ated with a random error. Its effect on mean values can be reduced by taking many measurements.

rangeability: flowmeter rangeability is the ratio of the maxi- mum to minimum flow rates or Reynolds number in the range over which the meter meets a specified uncertainty.

response time: for a step change in flow rate, response time is the time needed for the indicated flow rate to

1
