ASME B5.62M-2016 Hollow Taper Tooling With Flange-Face Contact
standard by ASME International,
In stock
Warning: Last items in stock!
Availability date: 01/04/2022
Hollow Taper Tooling With Flange-Face Contact
AN A MERICAN NA TIONAL S T AND ARD
AN AMERICAN NATIONAL STANDARD
Date of Issuance: December 5, 2016
This Standard will be revised when the Society approves the issuance of a new edition.
ASME issues written replies to inquiries concerning interpretations of technical aspects of this Standard. Interpretations are published on the Committee Web page and under https://go.asme.org/InterpsDatabase. Periodically certain actions of the ASME B5 Committee may be published as Cases. Cases are published on the ASME Web site under the B5 Committee Page at https://go.asme.org/B5committee as they are issued.
Errata to codes and standards may be posted on the ASME Web site under the Committee Pages to provide corrections to incorrectly published items, or to correct typographical or grammatical errors in codes and standards. Such errata shall be used on the date posted.
The B5 Committee Page can be found at https://go.asme.org/B5committee. There is an option available to automatically receive an e-mail notification when errata are posted to a particular code or standard. This option can be found on the appropriate Committee Page after selecting “Errata” in the “Publication Information” section.
ASME is the registered trademark of The American Society of Mechanical Engineers.
This code or standard was developed under procedures accredited as meeting the criteria for American National Standards. The Standards Committee that approved the code or standard was balanced to assure that individuals from competent and concerned interests have had an opportunity to participate. The proposed code or standard was made available for public review and comment that provides an opportunity for additional public input from industry, academia, regulatory agencies, and the public-at-large.
ASME does not “approve,” “rate,” or “endorse” any item, construction, proprietary device, or activity.
ASME does not take any position with respect to the validity of any patent rights asserted in connection with any items mentioned in this document, and does not undertake to insure anyone utilizing a standard against liability for infringement of any applicable letters patent, nor assumes any such liability. Usersof a code or standard are expressly advised thatdetermination of the validity of any such patent rights, and the risk of infringement of such rights, is entirely their own responsibility.
Participation by federal agency representative(s) or person(s) affiliated with industry is not to be interpreted as government or industry endorsement of this code or standard.
ASME accepts responsibility for only those interpretations of this document issued in accordance with the established ASME procedures and policies, which precludes the issuance of interpretations by individuals.
No part of this document may be reproduced in any form, in an electronic retrieval system or otherwise,
without the prior written permission of the publisher.
The American Society of Mechanical Engineers Two Park Avenue, New York, NY 10016-5990
Copyright © 2016 by
THE AMERICAN SOCIETY OF MECHANICAL ENGINEERS
All rights reserved Printed in U.S.A.
Foreword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Committee Roster vi
Correspondence With the B5 Committee vii
Part 1 | HSK Shanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 1 |
1-1 | General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 1 |
1-2 | Forms A and C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 1 |
1-3 | Forms B and D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 2 |
1-4 | Form E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 2 |
1-5 | Form F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 2 |
1-6 | Form T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 2 |
1-7 | Identification Coding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 2 |
Part 2 | HSK Receivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 29 |
2-1 | General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 29 |
2-2 | Forms A and C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 29 |
2-3 | Forms B and D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 29 |
2-4 | Form E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 29 |
2-5 | Form F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 29 |
2-6 | Form T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 29 |
Mandatory Appendix
I References 40
Nonmandatory Appendix
A Figures | Recommendations for Use and Applications of HSK Forms A, C, and T . . . . . . . . . . . . . . . . . . . | 41 |
1-1.3-1 | Basic HSK Shank Forms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 3 |
1-2-1 | HSK Form A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 4 |
1-2-2 | HSK Form C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 8 |
1-3-1 | HSK Form B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 11 |
1-3-2 | HSK Form D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 13 |
1-4-1 | HSK Form E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 17 |
1-5-1 | HSK Form F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 20 |
1-6-1 | HSK Form T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 23 |
1-7-1 | Identification Coding for HSK Shanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 28 |
2-2-1 | HSK Receiver, Form A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 30 |
2-2-2 | HSK Receiver, Form C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 31 |
2-3-1 | HSK Receiver, Form B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 33 |
2-3-2 | HSK Receiver, Form D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 34 |
2-4-1 | HSK Receiver, Form E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 36 |
2-5-1 | HSK Receiver, Form F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 37 |
2-6-1 | HSK Receiver, Form T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 38 |
A-2.5-1 | Preferred Balancing Zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 42 |
A-3-1 | Coolant Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 43 |
Tables 1-2-1 | Dimensions for HSK Forms A and C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 9 |
1-3-1 | Dimensions for HSK Forms B and D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 15 |
1-4-1 | Dimensions for HSK Form E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 19 |
1-5-1 | Dimensions for HSK Form F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 22 |
1-6-1 | Dimensions for HSK Form T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 27 |
1-7-1 | Allowable Combinations of HSK Form, Nominal Size, and Features per ASME B5.62M . . . . . . . . | 28 |
2-2-1 | Dimensions for HSK Receivers, Forms A and C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 32 |
2-3-1 | Dimensions for HSK Receivers, Forms B and D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 35 |
2-4-1 | Dimensions for HSK Receivers, Form E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 36 |
2-5-1 | Dimensions for HSK Receivers, Form F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 37 |
2-6-1 | Dimensions for HSK Receivers, Form T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 39 |
A-2.2-1 | Pull Force, kN, for HSK Forms A, C, and T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 41 |
A-2.3-1 | Theoretical Speed, Torque, and Bending Moment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . | 42 |
ASME B5.62M establishes a new American National Standard based on the “Final Report on the Research Project Interface Machine/Tool: Testing and Optimization of Machine Tools,” also known as the “Aachen Reports,” published in March 1994 by the Laboratory for Machine Tools and Production Engineering of the Rheinisch-Westfaelische Technical College, Aachen University, Germany.
This Standard has been created to eliminate confusion caused by different versions and translations of standards for the hollow taper shank, or HSK shank.
The HSK machine tool interface offers an alternative to the standard “steep taper,” with greater stiffness, rigidity, and repeatability than provided by ASME B5.50, CAT-V, and other toolholders with 7/24 tapers.✲ The ASME B5 Technical
Committee 45 felt that, in contrast to existing versions and translations of standards for the HSK, this Standard should contain a more comprehensive interpretation of the Aachen findings, to eliminate confusion arising from the blend of existing HSK documentation. This Standard provides the user with a comprehensive selection of options and includes supplemental information.
ASME B5.62M-2016 was approved by the American National Standards Institute on August 22, 2016.
✲ Final Report on Research Project — Study on Design Possibilities for the Connection Machine/Tool, August 15, 1991, page 4
(The following is the roster of the Committee at the time of approval of this Standard.)
STANDARDS COMMITTEE OFFICERS
S. G. Wallace, Chair
D. R. Alonzo, Secretary
STANDARDS COMMITTEE PERSONNEL
D. R. Alonzo, The American Society of Mechanical Engineers
J. A. Babinski, Contributing Member, Thomson Aerospace & Defense
A. M Bratkovich, Contributing Member, Consultant
J. B. Bryan, Honorary Member, Consultant
H. M. Brynes, Crown Equipment
H. Cooper, Honorary Member, Consultant
J. D. Drescher, UTC — Pratt & Whitney
D. A. Felinski, Contributing Member, B11 Standards, LLC
A. J. Koteles, The Babcock and Wilcox Co.
D. Mancini, Edmunds Gages
J. A. Soons, National Institute of Standards and Technology
R. C. Spooner, Contributing Member, Powerhold, Inc.
D. Springhorn, D. Springhorn Technical Consultants
W. Springhorn, Alternate, D. Springhorn Technical Consultants
S. G. Wallace, The Boeing Co.
TECHNICAL COMMITTEE 45 — SPINDLE NOSES AND TOOL SHANKS FOR MACHINING CENTERS
D. Springhorn, Chair, D. Springhorn Technical Consultants
J. E. Burley, Vice Chair, Big Kaiser Precision Tooling, Inc.
H. M. Brynes, Crown Equipment
D. G. Hartman, Parlec, Inc.
G. S. Hobbs, Advanced Machine & Engineering Co.
K. Hoffman, Ingersoll Machine Tool
K. Holdmann, TAC Rockford
J. Kable, Kable Tool & Engineering
A. J. Koteles, The Babcock and Wilcox Co.
D Mancini, Contributing Member, Edmunds Gages
O. Sandkuehler, Bilz Tool Co., Inc.
K. T. Sekerak, Mazak Corp.
S. G. Wallace, The Boeing Co.
H. M. Whalley, The George Whalley Co.
L. Yothers, Kennametal, Inc.
NOTE: The Committee would like to thank C. Koehn, Air Gaging, LLC, for his contributions to this Standard.
General. ASME Standards are developed and maintained with the intent to represent the consensus of concerned interests. As such, users of this Standard may interact with the Committee by requesting interpretations, proposing revisions or a case, and attending Committee meetings. Correspondence should be addressed to:
Secretary, B5 Standards Committee
The American Society of Mechanical Engineers Two Park Avenue
New York, NY 10016-5990
https://go.asme.org/Inquiry
Proposing Revisions. Revisions are made periodically to the Standard to incorporate changes that appear necessary or desirable, as demonstrated by the experience gained from the application of the Standard. Approved revisions will be published periodically.
The Committee welcomes proposals for revisions to this Standard. Such proposals should be as specific as possible, citing the paragraph number(s), the proposed wording, and a detailed description of the reasons for the proposal, including any pertinent documentation.
Proposing a Case. Cases may be issued to provide alternative rules when justified, to permit early implementation of an approved revision when the need is urgent, or to provide rules not covered by existing provisions. Cases are effective immediately upon ASME approval and shall be posted on the ASME Committee Web page.
Requests for Cases shall provide a Statement of Need and Background Information. The request should identify the Standard and the paragraph, figure, or table number(s), and be written as a Question and Reply in the same format as existing Cases. Requests for Cases should also indicate the applicable edition(s) of the Standard to which the proposed Case applies.
Interpretations. Upon request, the B5 Standards Committee will render an interpretation of any requirement of the Standard. Interpretations can only be rendered in response to a written request sent to the Secretary of the B5 Standards Committee.
Requests for interpretation should preferably be submitted through the online Interpretation Submittal Form. The form is accessible at https://go.asme.org/InterpretationRequest. Upon submittal of the form, the Inquirer will receive an automatic e-mail confirming receipt.
If the Inquirer is unable to use the online form, he/she may mail the request to the Secretary of the B5 Standards Committee at the above address. The request for an interpretation should be clear and unambiguous. It is further rec- ommended that the Inquirer submit his/her request in the following format:
Subject: Cite the applicable paragraph number(s) and the topic of the inquiry in one or two words. Edition: Cite the applicable edition of the Standard for which the interpretation is being requested.
Question: Phrase the question as a request for an interpretation of a specific requirement suitable for general understanding and use, not as a request for an approval of a proprietary design or situation. Please provide a condensed and precise question, composed in such a way that a “yes” or “no” reply is acceptable.
Proposed Reply(ies): Provide a proposed reply(ies) in the form of “Yes” or “No,” with explanation as needed. If entering replies to more than one question, please number the questions and replies.
Background Information: Provide the Committee with any background information that will assist the Committee in understanding the inquiry. The Inquirer may also include any plans or drawings that are necessary to explain the question; however, they should not contain proprietary names or information.
Requests that are not in the format described above may be rewritten in the appropriate format by the Committee prior to being answered, which may inadvertently change the intent of the original request.
ASME procedures provide for reconsideration of any interpretation when or if additional information that might affect an interpretation is available. Further, persons aggrieved by an interpretation may appeal to the cognizant ASME Committee or Subcommittee. ASME does not “approve,” “certify,” “rate,” or “endorse” any item, construction, proprietary device, or activity.
Attending Committee Meetings. The B5 Standards Committee regularly holds meetings and/or telephone confer- ences that are open to the public. Persons wishing to attend any meeting and/or telephone conference should contact the Secretary of the B5 Standards Committee. Future Committee meeting dates and locations can be found on the Committee Page at https://go.asme.org/B5committee.
ASME B5.62M-2016
GENERAL
1-1.1 Scope
This Standard covers basic toolholder shanks with a hollow 1/9.98 taper, and simultaneous contact face and taper mating surfaces that are applicable to a range of machine tool applications. Hollow taper shank (HSK shank) Forms A, B, C, D, E, F, and T with nominal flange diameters of 25 mm to 160 mm are covered by this Standard.
1-1.2 Interchangeability
Machine tool interfaces conforming to this Standard are interchangeable with machine tool interfaces conforming to DIN 69893-1:2003, DIN 69893-2:2003, DIN 69893-
5:2004, DIN 69893-6:2003, ISO 12164-1:2001, ISO
12164-2:2001, ISO 12164-3:2008, and ISO 12164-4:2008.
1-1.3 Forms
The HSK machine tool interfaces as manufactured in the seven basic shank forms (see Figure 1-1.3-1), and as custo- mized by selection of several optional features, are suitable for use in a wide range of machine tool applica- tions. The seven basic shank forms are as follows:
Form A. Form A is the preferred design for use on machine tools with automatic tool changers. Keyways are located at the small end of the tool taper. Form A includes provision for through-tool coolant and manual tool change. See Figure 1-1.3-1, illustration (a).
Form B. Like Form A, Form B is for use on machine tools with automatic tool changers, but it has a reduced taper compared to Form A. Keyways are located on the flange. Form B includes provision for through-flange coolant and manual tool change. See Figure 1-1.3-1, illus- tration (b).
Form C. Form C is similar to Form A but is intended for use on machine tools requiring manual tool change. Tools with Form C shanks are typically used on transfer lines, or as part of a modular tooling system. See Figure 1- 1.3-1, illustration (c).
Form D. Form D is similar to Form B but is intended for use on machine tools requiring manual tool change. See Figure 1-1.3-1, illustration (d).
Form E. Form E is similar to Form A, but it does not have keyways or orientation features. Form E is intended for high-speed machining. See Figure 1-1.3-1, illustration (e).
Form F. Form F is similar to Form E but has a reduced taper size. Form F is intended for high-speed machining. See Figure 1-1.3-1, illustration (f).
Form T. Form T is similar to Form A but has modi- fications to accommodate use with stationary tools. See Figure 1-1.3-1, illustration (g).
1-1.4 Definitions
balance: the condition in which the mass centerline and rotational centerline of a rotor are coincident.
clamp set: a mechanical device for securing a shank in the receiver.
data chip: a radio-frequency identification device.
drive key: a feature of a machine tool intended to orient the toolholder in the receiver and assist in delivery of the driving torque from the spindle nose to the tool.
keyway: the part of a machine tool that receives the drive key.
receiver: the spindle or nonrotating socket of a machine.
shank: a unit that fits directly into the spindle or nonro- tating socket of a machine.
spindle: component assembly of the machine tool, the function of which is to accept the basic toolholder shank.
spindle nose: that part of a spindle into which the shank is accepted.
1-1.5 Figure Interpretation
The Part 1 figures are illustrated and labeled in accor- dance with ASME Y14.5.
FORMS A AND C
Form A includes provisions for automatic tool change, a data chip, an orientation notch, an access hole for manual clamping, drive keyways, and through-spindle coolant supply via coolant tube. Form C is intended for manual tool change and includes an access hole for manual clamping, drive keyways, and through-spindle coolant supply.
