ASME B16.24-2016 Cast Copper Alloy Pipe Flanges, Flanged Fittings, and Valves: Classes 150, 300, 600, 900, 1500 and 2500

standard by ASME International, 10/31/2016

Full Description

1.1 Inclusions

This Standard covers the following cast copper alloy:
(a) threaded pipe flanges and blind flanges havingclass designations 150, 300, 600, 900, 1500, and 2500
(b) flanged fittings having rating class designations150 and 300
(c) threaded and flanged valves having rating classdesignations 150, 300, 600, 1500, and 2500

1.2 Dimensional Requirements
This Standard establishes requirements for
(a) pressure-temperature ratings
(b) size and method of designating openings forreduced fittings
(c) markings
(d) materials
(e) dimensions
(f) bolting and gaskets
(g) tolerances
(h) nondestructive examination for valves
(i) tests

Product Details

Published: 10/31/2016 ISBN(s): 9780791871294 ANSI: ANSI Approved Number of Pages: 42 File Size: 1 file , 840 KB Redline File Size: 2 files , 4.6 MB
