ASME Y14.2-2014 (R2020) Line Conventions and Lettering

standard by ASME International, 01/30/2015

Full Description

This standard establishes the line and lettering practices for use in the preparation of engineering drawings, including the recognition of the requirements for CAD (Computer Aided Design) and manual preparation for their reduction and reproduction.

Product Details

Published: 01/30/2015 ISBN(s): 9780791869710 ANSI: ANSI Approved Number of Pages: 28 File Size: 1 file , 2.7 MB
