BS PD ISO/TS 13399-204:2016
M00002858
New product
BS PD ISO/TS 13399-204:2016 Cutting tool data representation and exchange
standard by BSI Group, 02/29/2016
Full Description
BS PD ISO/TS 13399-204:2016 specifies a concept for the design of cutting items, limited to any kind ofreplaceable inserts for reaming, using related properties and domains of values.This part of ISO 13399 specifies a common way of designing simplified models that contain the following: definitions and identification of the design features of replaceable inserts for reaming, with a link tothe properties used; definitions and identification of the internal structure of the 3D model that represents the featuresand the properties of replaceable inserts for reaming;The following are outside the scope of this part of ISO 13399: applications where these standard data may be stored or referenced; creation and exchange of simplified 3D models for cutting tools; creation and exchange of simplified 3D models for tool items; creation and exchange of simplified 3D models for other cutting items not described in this partof ISO 13399; creation and exchange of simplified 3D models for adaptive items; creation and exchange of simplified 3D models for assembly items and auxiliary items.
Cross References:
ISO/TS 13399-2
ISO/TS 13399-80
ISO 13399-1
ISO/TS 13399-3
ISO/TS 13399-5
ISO/TS 13399-50
ISO/TS 13399-70
ISO/TS 13399-100
ISO/TS 13399-150
All current amendments available at time of purchase are included with the purchase of this document.
In stock
