IEC 61156-12 Ed. 1.0 en:2019 Multicore and symmetrical pair/quad cables for digital communications - Part 12: Symmetrical single pair cables with transmission characteristics up to 600 MHz - Work area wiring - Sectional specification

standard by International Electrotechnical Commission, 01/14/2021

Full Description

IEC 61156-12:2021 describes cables intended to be used for transmission of 1 Gbit/s over a single twisted pair for office, home and industrial application. An example of an existing application is 1000BASE-T1; see ISO/IEC TR 11801-9906. The transmission characteristics of these cables are specified up to a frequency of 600 MHz and at a temperature of 20 C. The cable type recognised is intended to be used for the work area wiring of shielded channels with a nominal length of 40 m. Possible designs are U/FTP, X/UTP and X/FTP, where X stands for F, S or SF.

Product Details

Edition: 1.0 Published: 01/14/2021 Number of Pages: 25 File Size: 1 file , 1.2 MB
