IEC 61169-36 Ed. 1.0 b:1996 Radio-frequency connectors - Part 36: Microminiature r.f. connectors with snap-on coupling - Characteristic impedance 50 Ohms (Type MCX)

standard by International Electrotechnical Commission, 03/20/1996

Full Description

Provides information and rules for the preparation of detail specifications for series BMA r.f. connectors together with the pro forma blank detail specification (BDS). Prescribes mating face dimensions for general purpose connectors, dimensional details of standard test connectors grade 0, gauging information and tests selected from QC 220000 (IEC 61169-1) applicable to all detail specifications relating to Type MCX connectors.

Product Details

Edition: 1.0 Published: 03/20/1996 Number of Pages: 51 File Size: 1 file , 1.9 MB
