IEEE C57.19.04-2018 IEEE Standard for Performance Characteristics and Dimensions for High Current Power Transformer Bushings with Rated Continuous Current in Excess of 5000 A in Bus Enclosures

standard by IEEE, 06/08/2018

Full Description

Scope

This standard covers the electrical, dimensional, and related special requirements for high current rating power transformer bushings located within bus enclosures that have rated continuous current in excess of 5000 A. Bushings covered by this standard are intended for use as components of liquid-filled transformers including, but not limited to, generator step-up (GSU) transformers.

Abstract

New IEEE Standard - Active.The electrical, dimensional, and related special requirements for high current rating power transformer bushings within bus enclosures that have rated continuous current in excess of 5000 A are addressed in this standard. Bushings covered by this standard are intended for use as components of liquid-filled transformers, including but not limited to Generator Step-Up (GSU) Transformers.

Product Details

Published: 06/08/2018 ISBN(s): 9781504448932, 9781504448949, 9781504449595 Number of Pages: 23 File Size: 1 file , 2.1 MB Product Code(s): STD23128, STDPD23128, STDPL23128
