IEEE 802.5j-1993 IEEE Trial Use Standard for Information Processing Systems-Local Area Networks-Part 5: Token Ring Access Method and Physical Layer Spec.-Fiber Optic Media Station Attachment

standard by IEEE, 06/30/1994

Full Description

Scope

This Technical Report specifies the functional, electrical, optical, and mechanical characteristics of a fibre optic interface for connecting a 4- or 16-Mbit/s token ring station to the trunk coupling unit (TCU) of a token ring. It is based upon a fibre optic transmitter, a channel of multimode graded-index fibres, and a direct-detection photodiode receiver; and includes signalling provisions for bypass of the station from the ring and self-test capabilities.

Abstract

New IEEE Standard - Superseded.The functional, electrical, optical, and mechanical characteristics of a fibre optic interface for connecting a 4- or 16-Mbit/s token ring station to the trunk coupling unit of a token ring are specified. This technical report is based upon a fibre optic transmitter, a channel of multimode graded-index fibres, and a direct-detection photodiode receiver; and includes signaling provisions for bypass of the station from the ring and self-test capabilities.

Product Details

Published: 06/30/1994 ISBN(s): 9781559374149 Number of Pages: 32 File Size: 1 file , 1.4 MB Product Code(s): STDSU17202
