IEEE 286-1968 IEEE Recommended Practice for Measurement of Power-Factor Tip-Up of Rotating Machinery Stator Coil Insulation

standard by IEEE, 07/31/1968

Full Description

Scope

The procedures described in this Recommended Practice are applicable to stator coils designed for use in rotating machinery which operates at a system voltage of 6600 volts or higher. 2.2 The coil insulation under consideration is principally the major ground-wall insulation which is external to the conductor structure. Only that part of the strand and turn insulation which is dielectrically in series with the ground-wall insulation enters into the measurements

Purpose

The purpose of this Recommended Practice is to describe the power-factor tip-up of coil insulation and to establish preferred procedures for its measurement.

Abstract

- Superseded.

Product Details

Published: 07/31/1968 ISBN(s): 9781504402699 Number of Pages: 6 File Size: 1 file , 5.1 MB Product Code(s): STDSU20584
