IEEE C57.12.20-2017 IEEE Standard for Overhead-Type Distribution Transformers 500 kVA and Smaller; High Voltage, 34 500 V and Below; Low Voltage, 7970/13 800Y V and Below

standard by IEEE, 11/30/2017

Full Description

Scope

This standard covers certain electrical, dimensional, and mechanical characteristics and safety features of single- and three-phase, 60 Hz, liquid-immersed, self-cooled, overhead-type distribution transformers 500 kVA and smaller, high voltages 34 500 V and below, and low voltages 7970/13 800Y V and below.

Purpose

This standard is intended for use as a basis for determining the performance, interchangeability, and safety of overhead-type distribution transformers and to assist in the proper selection of this equipment.

Abstract

Revision Standard - Active.Certain electrical, dimensional, and mechanical characteristics and safety features of single- and three-phase, 60 Hz, liquid-immersed, self-cooled, overhead-type distribution transformers 500 kVA and smaller, high voltages 34 500 V and below, and low voltages 7970/13 800Y V and below are covered in this standard.

Product Details

Published: 11/30/2017 ISBN(s): 9781504443111, 9781504443128, 9781504445443 Number of Pages: 52 File Size: 1 file , 5.1 MB Product Code(s): STD22768, STDPD22768, STDPL22768
