IEEE 1534-2009 IEEE Recommended Practice for Specifying Thyristor-Controlled Series Capacitors

standard by IEEE, 11/20/2009

Full Description

Scope

This recommended practice specifies thyristor-controlled series capacitor (TCSC) installations used in series with transmission lines. The document addresses issues that consider ratings for TCSC thyristor valve assemblies, capacitors, and reactors as well as TCSC control characteristics, protective features, cooling systems, testing, commissioning, operation, and maintenance.

Purpose

This document provides assistance and guidance to planning, substation, commissioning, and operation engineers in the course of specifying TCSC installations. Users of this document should tailor these recommendations to their specific project requirements.

Abstract

Revision Standard - Inactive-Reserved.Recommended practices for specifying Thyristor-Controlled Series Capacitor (TCSC) installations used in series with transmission lines are provided. Ratings for TCSC thyristor valve assemblies, capacitors, and reactors as well as TCSC control characteristics, protective features, cooling systems, testing, commissioning, training, documentation, operation, and maintenance are addressed in this standard.

Product Details

Published: 11/20/2009 ISBN(s): 9780738160610, 9780738169439, 9780738160603 Number of Pages: 98 File Size: 1 file , 1.6 MB Redline File Size: 2 files , 3.3 MB Product Code(s): STDRES95968, STDSURL95968
