IEEE C57.12.40-2006 IEEE Standard for Requirements for Secondary Network Transformers, Subway and Vault Types (Liquid-Immersed)

Amendment by IEEE, 09/15/2006

Full Description

Scope

This standard is intended for use as a basis for establishing the performance, interchangeability, and safety of the equipment covered and to assist in the proper selection of such equipment.

Purpose

This standard covers certain electrical, dimensional, and mechanical characteristics and takes intoconsideration certain safety features of three-phase, 60 Hz, liquid-immersed, secondary networktransformers with a three-position grounding switch, subway and vault types, rated 2500 kVA and smaller; primary 34 400 V and below; secondary 216Y/125 V and 480Y/277 V.A subway-type network transformer is one that is suitable for frequent or continuous submerged operation.A vault-type network transformer is one that is suitable for occasional submerged operation.

Abstract

Revision Standard - Superseded.This standard is intended for use as a basis for establishing the performance,interchangeability, and safety of the equipment covered and to assist in the proper selection of such equipment.

Product Details

Published: 09/15/2006 ISBN(s): 0738149640, 9780738149653 Number of Pages: 25 File Size: 1 file , 600 KB Product Code(s): STDSU95536
