IEEE 690-2004 IEEE Standard for the Design and Installation of Cable Systems for Class 1E Circuits in Nuclear Power Generating Stations

standard by IEEE, 02/18/2005

Full Description

Scope

This standard provides direction for the design and installation of safety related electrical cable systems, including associated circuits, in nuclear power generating stations. Also provided is guidance for the design and installation of those non-safety related cable systems that may effect the function of safety related systems.

Purpose

The purpose of this standard is to identify existing standards and to establish requirements pertaining to safety related cable systems in nuclear power generating stations. Solutions are recommended for areas of concern such as fire protection, raceways, separation, cable performance requirements, and installation acceptance testing and documentation. The purpose of the proposed revision is to update references and requirements.

Abstract

Revision Standard - Superseded.Direction for the design and installation of safety related electrical cable systems, including associated circuits, in nuclear power generating stations is provided. Guidance for the design and installation of those nonsafety related cable systems that may affect the function of safety related systems is also provided.

Product Details

Published: 02/18/2005 ISBN(s): 0738144622, 9780738144634 Number of Pages: 18 File Size: 1 file , 130 KB Product Code(s): STDSU95266
