IEEE 518-1977 IEEE Guide for the Installation of Electrical Equipment to Minimize Electrical Noise Inputs to Controllers from External Sources

standard by IEEE, 04/29/1977

Full Description

Purpose

The purpose of this standard is to develop a guide for the installation and operation of industrial controllers to minimize the disturbing effects of electrical noise on these controllers.

Abstract

- Superseded.The rapidly expanding use of solid-state controllers requires consideration of many factors notpreviously important in the design, installation, and operation of other forms of controllers. Manyportions of the control circuits of solid-state controllers designed for operation at low-energy low voltage signal levels are susceptible to disturbances by excessive electrical noise. Erratic controller operation may result unless suitable precautions are taken. The following recommendations are intended as an installation guide for industrial controls involving low-energy level equipment to minimize electrical noise inputs from external sources.The electrical noise guide is comprised of six sections. Sections 1 and 2 state the scope and service conditions. Sections 3 through 5 provide the technical foundation for the recommendations given in Section 6. Section 6 is intended to stand alone as the working section of the electrical noise guide.

Product Details

Published: 04/29/1977 ISBN(s): 9781504403795 Number of Pages: 70 File Size: 1 file , 91 MB Product Code(s): STDSU06296
