IEEE 286-1975 [ Withdrawn ] IEEE Recommended Practice for Measurement of Power-Factor Tip-Up of Rotating Machinery Stator Coil Insulation

standard by IEEE, 07/23/1975

Full Description

Purpose

The purpose of this recommended practice is to describe the power-factor tip-up of coil insulation and to establish preferred procedures for its measurement. This recommended practice applies to stator coils of rotating machinery operating at 6600 V or higher. the coil Insulation under consideration is principally the major ground-wall insulation which is external to the conductor structure. Only that part of the strand and turn insulation which dielectrically in series with the ground-wall insulation enters into the measurements.

Abstract

Revision Standard - Inactive-Withdrawn.

Product Details

Published: 07/23/1975 ISBN(s): 9780738184784 Number of Pages: 12 File Size: 1 file , 490 KB Product Code(s): STDWD02865
