IEEE 205-1958 [ Withdrawn ] IEEE Standards on Television: Measurement of Luminance Signal Levels

standard by IEEE, 11/30/1957

Full Description

Scope

This Standard is a revision of Part 1 of Standard 50 IRE 23. S1 and replaces in all respects this previously issued part of the Standard. The need for the revision stems from the standardization of color television signals in the USA, and the inadequacy of the earlier Standard in providing methods of measuring the luminance component of the color signal. The revision consists primarily of a change in the response characteristics of the oscilloscopes to insure adequate suppression of the color subcarrier. Other minor changes in wording and in the associated figures have been made to bring the standard into accord with present terminology and practice.

Abstract

New IEEE Standard - Inactive-Withdrawn.A method of measuring the amplitude levels of an SMPTE 170M-1994; NTSC color or monochrome television video signal is described. It is concerned with luminance measurements at various points in transmission systems where the signals are at video frequencies. The methods described are limited to the use of waveform monitors, software video processing for amplitude assessment, or suitable oscilloscopes, and are primarily directed to specifying means of measuring television signal levels for operating purposes.

Product Details

Published: 11/30/1957 ISBN(s): 9780738141817 Number of Pages: 11 File Size: 1 file , 430 KB Product Code(s): STDWD01248
