IEEE C57.12.23-2009 IEEE Standard for Submersible Single-Phase Transformers: 167 kVA and Smaller; High Voltage 25 000 V and Below; Low Voltage 600 V and Below

standard by IEEE, 04/30/2009

Full Description

Scope

This standard covers certain electrical, dimensional, and mechanical characteristics and takes into consideration certain safety features of single-phase, 60 Hz, liquid-immersed, self-cooled, submersible distribution transformers with separable insulated high-voltage connectors. These transformers are rated 167 kVA and smaller, with high voltages of 25 000 V and below and with low voltages of 600 V and below. These transformers are generally used for step-down purposes from an underground primary cable supply. These transformers are typically installed in an enclosure below ground level, operated from above and suitable for submerged operation.This standard does not cover the electrical and mechanical requirements of any accessory devices that maybe supplied with the transformer.

Purpose

This standard is intended for use as a basis for determining performance, interchangeability, and safety of the equipment covered, and to assist in the proper selection of such equipment.

Abstract

Revision Standard - Superseded.This standard covers certain electrical, dimensional, and mechanical characteristics and takes into consideration certain safety features of single-phase, 60 Hz, liquid-immersed, self-cooled, submersible distribution transformers with separable insulated high-voltage connectors.

Product Details

Published: 04/30/2009 ISBN(s): 9780738159348, 9780738159331, 9780738170619 Number of Pages: 18 File Size: 1 file , 780 KB Redline File Size: 2 files , 1.7 MB Product Code(s): STDSU95921, STDSURL95921
