IPC 2152 Standard for Determining Current Carrying Capacity in Printed Board Design

standard by Association Connecting Electronics Industries, 08/01/2009

Full Description

The sole industry standard for determining appropriate internal and external conductor sizes on printed boards as a function of the current carrying capacity required and the acceptable conductor temperature rise. This document provides guidance on how thermal conductivity, vias, copper planes, power dissipation and printed board material and thickness all factor into the relationship between current, conductor size, and temperature.

Product Details

Published: 08/01/2009 Number of Pages: 108 File Size: 1 file , 8.3 MB
