IPC 7525 Stencil Design Guidelines

Handbook / Manual / Guide by Association Connecting Electronics Industries, 05/01/2000

Full Description

This new document provides guides for the design and fabrication of stencils for solder paste andsurface-mount adhesive. This is the first time this important information has been collected andpublished in an industry consensus document. Stencil design for various surface-mounttechnology, as well as mixed technology with through-hole or flip chip components is discussed;this includes overprint, two-print and step stencil designs. A sample order form and a userinspection checklist are also included.

Product Details

Published: 05/01/2000 Number of Pages: 20 File Size: 1 file , 330 KB Product Code(s): 7525(D)1
