ISO 8048:1984 Technical drawings -- Construction drawings -- Representation of views, sections and cuts

standard by International Organization for Standardization, 12/01/1984

Full Description

General rules are layed down for marking, designation, placing and orientation and the position of text in relation to figures. For all general rules reference is made to ISO 128. As regards relative positions of views, the method using reference arrows according to ISO 128 is applied.
