PIP ELIMTD00 Motor Installation Details for Class I, Division 1 Areas [Complete Revision]

standard by Process Industry Practices, 09/01/2014

Full Description

This Practice describes the requirements for installing circuits for power and control to AC squirrel cage induction motors (600 volts and below, 60 hp maximum), located in Class I, Division 1 areas. This Practice tabularizes the basic assumptions used in developing these details and provides guidelines for their application. These details were originally published in ELIMT000 which was withdrawn May 2008.

Product Details

Published: 09/01/2014 Number of Pages: 13 File Size: 1 file , 850 KB
