PIP ELSSG02 Design and Fabrication of Medium Voltage Metal-Clad Switchgear from 4.76 kV to 38 kV (Complete Revision)

standard by Process Industry Practices, 09/01/2006

Full Description

This Practice provides requirements for the design and fabrication of metal-clad switchgear.

This Practice covers minimum requirements for design, fabrication, inspection, testing, shipment, and documentation, for metal-clad switchgear containing insulated buses, draw-out power circuit breakers, control, instrumentation, and metering, for indoor installation in unclassified areas. This Practice also covers remote monitoring and control requirements.
