WRC 102 State Of Stress In A Circular Cylindrical Shell With A Circular Hole

Bulletin / Circular by Welding Research Council, Inc., 1965

A.C. Eringen, A.K. Naghdi, C.C. Thiel

Full Description

Analytical solutions are presented for the determination of the state of stress in a circular cylindrical, thin elastic shell having a circular hole on its lateral surface. The problems treated include the following cases of applied loads: (I) A uniform bending moment is applied to the edge of the hole. (II) The shell is subjected to a uniform axial tension. (III) The shell is subjected to internal presswe balanced by a uniformly distributed shear along the hole. (IV) The shell is subjected to a torque at its ends. By superposition of these results one may obtain the solution of various other technically important cases, e.g., pressurized cylinder intersected by a circular cylindrical membrane with closed ends. For each of the cases enumerated above, stresses and stress concentration factors are plotted against a natural parameter which involves dimensional ratios and Poisson's ratio. Formulas are presented for the calculation of membrane stress concentrations in the case of a small hole.

Product Details

Published: 1965 Number of Pages: 27 File Size: 1 file , 710 KB
