WRC 521 Development of Design Rules for Conical Transitions in Pressure Vessels for the ASME B&PV Code, Section VIII, Division 2

Bulletin / Circular by Welding Research Council, Inc., 2009

J.C. Sowinski, Z. Cao, D.A. Osage, N.A. Carr, J. E. Brubaker

Full Description

The technical background behind the new ASME Bapplicable loadings were to include pressure, axial forces, and net-section bending moments;reinforcement area must be integral; applicable to cone half apex angles ranging from 0 to 60 degrees; determination of the stress state developed at the cylinder-to-cone/knuckle/flare junction; a concise self-contained procedural layout; andvalidation using finite element analysis. For cylinder-to-cone transitions without knuckles or flares, the design rules were developed based on thin shell theory and are an extension of the rules in ASME B

Product Details

Published: 2009 Number of Pages: 176 File Size: 1 file , 4.8 MB
