WRC 408 Bolted Flange Assembly: Preliminary Elastic Interaction Data and Improved Bolt-Up Procedures

Bulletin / Circular by Welding Research Council, Inc., 1996

G. Bibel, R. Ezell

Full Description

Design bolt loading in a bolted flange connection is difficult to obtain because of elastic interaction. Elastic interaction data is presented for two different pipe flanges, three different gasket styles and two different bolting patterns. An algorithm that compensates for elastic interaction is given. Uniform bolt preload (2%) is obtained in a single pass bolt-up operation. The algorithm is based on experimentally obtained interaction coefficients.

Product Details

Published: 1996 Number of Pages: 35 File Size: 1 file , 3.2 MB
